Help CenterDouble-effect Falling Film Evaporator for Food Processing, 500kg/h, Steam Heated, Sanitary Design
Product Spotlights
Related Products
-
Double-effect Falling Film Evaporator, 24/7 Technical Support, Mill Test Report Provided, Standard CompliantUS$ 6150 - 948000MOQ: 1 Combo -
304 Stainless Steel Double-effect Falling Film Evaporator With PLC Control for 380VUS$ 6150 - 948000MOQ: 1 Combo
-
Double-effect Falling Film Evaporator With 1-Year Warranty, Free Installation and CommissioningUS$ 6150 - 948000MOQ: 1 Combo
-
Double-effect Falling Film Evaporator With 1000L/h Capacity, 304 Stainless Steel, Energy SavingUS$ 6150 - 948000MOQ: 1 Combo
-
Plate Type Heat Exchanger for HVAC Heat Recovery Energy EfficientUS$ 2480 - 87900MOQ: 1 Combo
Qingdao Conqinphi Environmental Technology Group Co., Ltd., a professional manufacturer established in 2015 with a factory area of 10,000–30,000 square meters and an annual export value of US$10–50 million, proudly presents our Double-effect Falling Film Evaporator for Food Processing, 500kg/h, Steam Heated, Sanitary Design. This advanced evaporator combines high thermal efficiency with strict hygiene standards, making it an ideal solution for concentrating fruit juices, dairy products, extracts, and other liquid foods. Our team of 201–300 experienced employees ensures every unit meets rigorous quality control, delivering reliable performance for global food processors.
The double-effect falling film design maximizes energy utilization by using vapor from the first effect to heat the second effect, reducing steam consumption by up to 40% compared to single-effect units. With a capacity of 500 kg/h of water evaporation, this evaporator is well-suited for medium-scale production lines. The sanitary design features smooth surfaces, no dead corners, and easy CIP cleaning, fully complying with food industry requirements.
Key Features & Technical Specifications
- Double-Effect Energy Saving: Two-stage evaporation reduces steam consumption; vacuum operation lowers boiling point for heat-sensitive products.
- Sanitary Design: All product contact parts are made of stainless steel 304 or 316L, with polished surfaces (Ra ≤ 0.5 μm) and no crevices to prevent bacterial growth.
- Steam Heated: Uses saturated steam as heating medium, with automatic pressure control for stable operation.
- Gentle Evaporation: Falling film principle ensures short residence time (typically 2–5 minutes) at low temperature, preserving product flavor, color, and nutrients.
- PLC Control System: Touch screen interface monitors temperature, pressure, flow rate, and concentration; data logging and alarm functions available.
- Compact Footprint: Vertical design saves floor space; easy to install and integrate into existing production lines.
- Customizable Options: Additional features like MVR integration, CIP nozzles, or automatic cleaning can be provided upon request.
| Parameter | Specification |
|---|---|
| Evaporation Capacity | 500 kg/h (water evaporation) |
| Heating Steam Consumption | Approx. 280–320 kg/h (depends on product) |
| Steam Pressure | 0.3–0.6 MPa (adjustable) |
| Evaporation Temperature | First effect: 60–80°C; Second effect: 45–60°C (vacuum adjustable) |
| Material | Stainless Steel 304/316L (product contact) |
| Power Supply | 380V / 50Hz (or customized) |
| Dimensions (L×W×H) | Approx. 2.5m × 1.8m × 4.5m (varies by configuration) |
Benefits for Your Food Processing Line:
- Higher Product Quality: Low-temperature evaporation prevents thermal degradation of flavors, vitamins, and colors.
- Energy Cost Reduction: Double-effect design significantly lowers steam consumption per kilogram of water evaporated.
- Easy Cleaning & Maintenance: Sanitary design allows quick CIP cleaning; parts are easily accessible for inspection.
- Scalable Production: 500 kg/h capacity is ideal for mid-sized operations; multiple units can be combined for larger throughput.
- Long Service Life: High-quality stainless steel construction and robust welding ensure durability under continuous operation.
At Qingdao Conqinphi, we understand that every food processing application has unique requirements. Our engineering team can customize the evaporator with additional features such as automatic density control, multi-effect configurations, or integration with your existing control system. All units undergo strict factory testing before shipment.
Why Choose Qingdao Conqinphi?
With over 8 years of manufacturing experience, a 10,000–30,000 m² factory, and an annual export value exceeding US$10 million, we are a trusted partner for food processors worldwide. Our products are shipped from Qingdao Port to markets across North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East. We have a dedicated team of 201–300 skilled employees, many with years of expertise in evaporation technology. Our commitment to quality is reflected in our adherence to multiple management system standards, including ISO9001, ISO14000, HACCP, and OHSAS18001 (available upon request for specific projects).
We offer competitive pricing, prompt delivery, and comprehensive after-sales support including installation guidance, commissioning, and spare parts supply. Our customers consistently report high satisfaction with the performance and reliability of our evaporators. Contact us today to discuss your specific product concentration needs and request a customized quotation. Let Qingdao Conqinphi be your partner in efficient, sanitary food processing.
Frequently Asked Questions (FAQ)
-
Q: What types of food products can be processed with this evaporator?
A: It is suitable for clear liquids, fruit juices, milk, whey, sugar solutions, vegetable extracts, and other heat-sensitive liquid foods. For viscous or particulate-containing products, please consult our engineering team for feasibility. -
Q: What is the maximum concentration ratio achievable?
A: The concentration ratio depends on the product properties. Typically, fruit juices can be concentrated to 65–72°Brix, and milk to 45–50% total solids. We recommend pilot testing for your specific product. -
Q: How is the sanitary design validated?
A: The evaporator is designed with continuous welds, polished surfaces, and no dead legs. All seals are FDA-grade. CIP spray balls are optional. We can provide surface finish certificates and material certificates upon request. -
Q: Does the evaporator come with a vacuum system?
A: Yes, a vacuum pump and condenser are included. The vacuum level is adjustable to control the evaporation temperature. -
Q: What is the typical delivery time?
A: Standard delivery time is 30–45 days after confirmation of order and technical specifications. Customized units may require 45–60 days. -
Q: Can the evaporator be automated?
A: Yes, a PLC-based control system with touch screen is standard. Options include remote monitoring, automatic concentration control, and data recording. -
Q: What after-sales support do you provide?
A: We provide installation drawings, online guidance, and on-site commissioning support (travel expenses at buyer's cost). Spare parts are available for quick delivery. -
Q: Is there a minimum order quantity?
A: No minimum order quantity for standard models. For custom configurations, we typically require a minimum of 1 unit.
