Help CenterMulti Layered Elastomeric Seismic Isolation Bearing for Bridges High Damping Rubber
Product Spotlights
Related Products
-
PTFE Pot Spherical Rubber Bearing for Bridge Seismic Resistance Low Friction SlidingNegotiableMOQ: 1 Piece -
Laminated Rubber Bridge Bearing High Load Capacity Structural Support for BridgesNegotiableMOQ: 1 Piece
-
Lead Rubber Bearing for Building and Bridge Seismic Isolation Shock Absorption DampingNegotiableMOQ: 1 Piece
-
Elastomeric Bearing Pad PTFE Faced to Adapt Longitudinal Thermal DisplacementNegotiableMOQ: 1 Piece
-
Steel Insert Neoprene Bridge Elastomeric Bearing Pad - Durable and High LoadNegotiableMOQ: 1 Piece
Hengshui Ruibin New Materials LLC, a professional manufacturer established in 2019 with a 1,000–3,000 m² factory and ISO9001/ISO9000 certified, proudly presents our Multi Layered Elastomeric Seismic Isolation Bearing for Bridges High Damping Rubber. This advanced bearing is engineered to protect bridge structures from earthquake damage by absorbing and dissipating seismic energy. With over 101–200 skilled employees and an annual export value of US$2.5–5 million, we deliver reliable, cost-effective solutions to markets worldwide including North America, Europe, and Southeast Asia. Our product combines multi-layer elastomer design with high damping rubber to provide superior stability, durability, and isolation performance.
This bearing consists of alternating layers of high-damping rubber and steel plates, vulcanized together to form a compact unit. The rubber layers provide flexibility and energy dissipation, while the steel plates ensure vertical load capacity. The high damping rubber compound offers excellent damping characteristics (typically 10–20%), reducing the transmission of horizontal seismic forces to the superstructure. Ideal for bridges, viaducts, and elevated highways, this product enhances structural safety and extends service life even under extreme seismic events.
Key Features & Technical Specifications
- Multi-Layered Construction: Alternating rubber and steel plates for optimal load distribution and flexibility.
- High Damping Rubber: Proprietary compound with high energy dissipation capacity (equivalent damping ratio up to 20%).
- Excellent Horizontal Displacement Capacity: Accommodates large lateral movements (up to ±200 mm or more) without damage.
- Superior Vertical Load Capacity: Supports heavy bridge loads with minimal vertical deformation.
- Temperature Resistance: Functions reliably in extreme climates from -40°C to +60°C.
- Long Service Life: Designed for 50+ years with minimal maintenance.
- Customizable Sizes: Available in various dimensions to match specific bridge design requirements.
- Easy Installation: Compact design simplifies handling and mounting on site.
| Parameter | Typical Value |
| Horizontal Stiffness | 0.5 – 5.0 kN/mm |
| Vertical Stiffness | 50 – 500 kN/mm |
| Damping Ratio | 10% – 20% |
| Max Horizontal Displacement | ±200 mm (customizable) |
| Operating Temperature | -40°C to +60°C |
| Standard | ISO9001, ISO9000 compliant |
Advantages for Your Bridge Projects
Our Multi Layered Elastomeric Seismic Isolation Bearing offers significant benefits over conventional bearings:
- Enhanced Seismic Protection: Reduces peak acceleration and base shear forces by up to 60%, protecting both structure and occupants.
- Cost-Effective: Lower life-cycle cost due to reduced maintenance and longer service life compared to other isolation systems.
- Proven Performance: Extensively tested in our in-house lab and field-validated in multiple seismic zones.
- Versatile Application: Suitable for new bridges as well as retrofitting existing structures.
- Environmental Resistance: Ozone, UV, and aging resistant rubber compound ensures long-term reliability.
- Quick Delivery: Our streamlined production capacity supports orders of any scale, with lead times as short as 15–30 days.
Why Choose Hengshui Ruibin New Materials LLC?
As a manufacturer with ISO9001/ISO9000 certification, we control every stage of production—from raw material selection to final inspection—ensuring consistent quality. Our factory spans 1,000–3,000 m² and employs 101–200 experienced workers, enabling us to produce over 10,000 units annually. We have shipped products to customers in North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, the Middle East, and many other regions. Our annual export value of US$2.5 million–US$5 million reflects the trust our global clients place in us. We ship from the Port of Tianjin and Port of Qingdao, providing flexible logistics options. Contact us today for a quote or technical consultation—we are ready to support your bridge isolation needs with professional engineering and reliable products.
Frequently Asked Questions (FAQ)
-
What is the typical lifespan of your seismic isolation bearing?
Our bearings are designed for a service life of 50 years or more under normal conditions, thanks to the high-quality rubber compound and durable steel plates. -
Can you provide custom sizes for specific bridge projects?
Yes, we offer customizable dimensions, stiffness, and damping ratios to meet your project requirements. Please provide your design parameters for a tailored solution. -
How does the high damping rubber compare to lead rubber bearings?
High damping rubber bearings provide inherent damping without lead, making them more environmentally friendly and easier to handle. They offer similar isolation performance with lower maintenance. -
What certifications do your products have?
Our factory is ISO9001 and ISO9000 certified, and our products are manufactured in compliance with international standards. Specific third-party testing reports are available upon request. -
What is the maximum horizontal displacement your bearing can accommodate?
Depending on the size and design, our bearings can accommodate lateral displacements up to ±200 mm or more. Custom designs for larger displacements are available. -
Do you offer installation support or technical guidance?
Yes, we provide installation manuals, technical drawings, and remote support. For complex projects, on-site guidance can be arranged. -
What is the minimum order quantity (MOQ)?
Our MOQ is typically 10 pieces for standard sizes, but we can discuss smaller quantities for sample or trial orders. -
How long does delivery take?
Standard lead time is 15–30 days after order confirmation, depending on quantity and customization. We ship from Tianjin or Qingdao ports.
