Lightweight FRP Grating for Easy Installation - Long-Lasting Industrial Walkway and Platform
Product Spotlights
Lightweight FRP grating reduces installation time and labor costs by 50%, while offering superior corrosion resistance, non-conductive safety, and a 20+ year lifespan. Customizable sizes, multiple resin options, and slip-resistant surfaces make it ideal for industrial walkways, platforms, and catwalks. ISO9001 certified factory with global shipping.
Negotiable
MOQ: 50 Square Meters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Fiberglass Reinforced Plastic (FRP)
Surface Type:
Concave/convex, grit top
Weight:
Lightweight (approx. 30-60% lighter than steel)
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin/Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Chemical Proof FRP Grating for Effluent Channel Cover - Corrosion Resistant IndustrialNegotiableMOQ: 50 Square Meters -
Corrosion Resistant FRP Grating Board for Sidewalk Floor - Durable Fiberglass CompositeNegotiableMOQ: 50 Square Meters
-
FRP/GRP Grating With Gritted or Concave Surface - Fiberglass Glassfiber CompositeNegotiableMOQ: 50 Square Meters
-
Molded FRP Grating With Concave Surfaces - Slip Resistant and Durable for FlooringNegotiableMOQ: 50 Square Meters
-
High Quality FRP GRP Fiberglass Grating With Clips - Durable Industrial Flooring SolutionNegotiableMOQ: 50 Square Meters
Material
Fiberglass Reinforced Plastic (FRP)
Surface Type
Concave/convex, grit top
Weight
Lightweight (approx. 30-60% lighter than steel)
Load Capacity
High load capacity (customizable)
Color
Yellow, gray, green, custom colors available
Resin Type
Polyester, vinyl ester, phenolic (optional)
Panel Size
Customizable sizes (e.g., 1220×3660mm)
Application
Industrial walkways, platforms, catwalks
Standard
ISO9001, ISO9000 certified
As a leading manufacturer from Hengshui Ruibin New Materials LLC (established 2019, 101-200 employees, ISO9001/ISO9000 certified), we are proud to introduce our Lightweight FRP Grating for Easy Installation – a durable, corrosion-resistant solution designed specifically for industrial walkways and platforms. Our grating is engineered to reduce installation time and labor costs while providing long-lasting performance in harsh environments. With a factory size of 1,000-3,000 sqm and annual export value of US$2.5M-US$5M, we ship globally via Tianjin and Qingdao ports, serving markets across North America, South America, Europe, Africa, and more.
Key Features & Technical Specifications
- Lightweight Construction: 30-60% lighter than traditional steel grating, making transportation and handling effortless.
- Easy Installation: Pre-cut panels and snap-fit clips allow quick assembly without welding or heavy equipment.
- High Load Capacity: Engineered to support heavy loads (customizable up to 1000 kg/m²).
- Corrosion Resistance: Impervious to moisture, chemicals, and UV, ideal for wastewater plants, chemical plants, and offshore platforms.
- Slip Resistance: Available with grit-top surface or concave/convex pattern for enhanced safety.
- Non-Conductive & Non-Magnetic: Safe for electrical environments and MRI suites.
- Low Maintenance: No painting, rust-proofing, or coating required.
- Color Options: Standard yellow, gray, green; custom colors available upon request.
- Resin Choices: Polyester (standard), vinyl ester (chemical resistance), or phenolic (fire retardant) – optional per application.
Technical Specifications Table
| Parameter | Value |
|---|---|
| Standard Panel Size | 1220×3660mm (custom sizes available) |
| Mesh Size | 38×38mm, 50×50mm, 25×100mm (optional) |
| Load Capacity | Up to 1000 kg/m² (depending on thickness and span) |
| Thickness | 25mm, 30mm, 38mm (or custom) |
| Weight | Approx. 8-15 kg/m² (varies by design) |
| Service Temperature | -40°C to +80°C (higher with phenolic resin) |
| Fire Rating | Class 1 / Class B (depending on resin) |
Benefits for Your Business
- Reduced Labor Costs: Lightweight panels cut installation time by up to 50% compared to steel grating.
- Longer Service Life: FRP grating lasts 20+ years in corrosive environments, eliminating frequent replacements.
- Enhanced Safety: Slip-resistant surface and non-conductive properties protect workers.
- Eco-Friendly: FRP is recyclable and requires no chemical coatings, reducing environmental impact.
- Versatile Use: Suitable for industrial walkways, platforms, catwalks, trench covers, stair treads, and more.
Frequently Asked Questions (FAQ)
-
Q: Is this FRP grating suitable for outdoor use in extreme weather?
A: Yes, our grating is UV-stabilized and resistant to rain, snow, and sun. Optional phenolic resin provides higher temperature tolerance. -
Q: How do I install the grating without welding?
A: Panels are designed with interlocking clips or snap-fit systems. You can also use stainless steel bolts and clips – no welding or hot work required. -
Q: Can I get custom sizes for my project?
A: Absolutely. We offer custom panel sizes, mesh patterns, and thicknesses based on your load and span requirements. -
Q: What is the load capacity for a standard 25mm thick panel?
A: For a 38×38mm mesh, 25mm thick panel can support up to 400 kg/m² (safe working load). Higher capacities available with thicker panels or smaller mesh. -
Q: Do you provide sample pieces for testing?
A: Yes, we can send small samples (e.g., 300×300mm) for evaluation. Contact our sales team for details. -
Q: What is the lead time for mass production?
A: Typical lead time is 15–25 days after order confirmation, depending on quantity and customization. -
Q: Is this product fire-retardant?
A: Standard polyester resin is self-extinguishing. For higher fire safety, we recommend vinyl ester or phenolic resin (optional). -
Q: How do I clean the grating?
A: Routine cleaning with water and mild detergent is sufficient. For oil or chemical spills, use appropriate solvents that won't damage the resin.
With ISO9001 and ISO9000 certifications, our factory in Hengshui, Hebei ensures consistent quality control. Our team of 101-200 skilled workers and modern 1,000-3,000 sqm facility produce grating that meets international standards. We have exported to over 20 countries, with annual export value of US$2.5M-US$5M. Choose Ruibin for a reliable, cost-effective, and long-lasting FRP grating solution. Contact us today for a quote or technical consultation!
