Henan San Kuang Machinery Technology Co., Ltd. proudly presents our Semi-Automatic Coal Slurry Dehydration Coal Slime Dewatering Press, designed for efficient solid-liquid separation in the coal processing industry. With over a decade of manufacturing experience since 2014, we have delivered reliable dewatering solutions to clients across North America, South America, Europe, Southeast Asia, Africa, and beyond. This press operates on a 3-Phase 380V power supply, ensuring stable performance in industrial environments. Its semi-automatic design balances productivity with operator control, making it ideal for medium to large-scale coal preparation plants seeking to reduce moisture content in coal slime and slurry.
Key Features & Benefits:
- High Dehydration Efficiency: Achieves low moisture content (typically 15-25%) in coal slime, reducing transportation costs and improving calorific value.
- Robust Construction: Main frame made of high-strength steel with optional stainless steel filter plates, ensuring long service life under harsh conditions.
- Energy-Saving Design: Optimized hydraulic system reduces power consumption; semi-automatic control minimizes manual intervention while maintaining flexibility.
- Easy Maintenance: Quick-release filter cloth and modular plate design allow fast replacement and cleaning, reducing downtime.
- Customizable Parameters: Filter area, pressure, and cycle time can be adjusted to suit different feed materials (e.g., coal slurry, coal slime, tailings).
- Safety Features: Emergency stop, overload protection, and pressure relief valves ensure operator safety.
Technical Specifications (Typical Model):
| Parameter | Value |
|---|---|
| Power Supply | 3-Phase 380V, 50/60Hz |
| Filter Area | 200 - 500 m² (customizable) |
| Filter Plate Size | 1000×1000 mm / 1250×1250 mm (optional) |
| Max Working Pressure | 1.6 MPa |
| Cycle Time | 20-45 minutes (adjustable) |
| Motor Power | 7.5 - 15 kW |
| Overall Dimensions | Varies by configuration |
How It Works: The coal slurry (or slime) is fed into the press via a pump. Under hydraulic pressure, the filter plates close, and liquid is forced through filter cloth, leaving solids trapped in the chambers. After dewatering, the plates open automatically, and the cake discharges. The semi-automatic system allows operators to monitor and adjust parameters such as pressing time and pressure, ensuring optimal performance for varying feed conditions.
Application Scenarios:
- Coal washing plants – dewatering of fine coal slime to reduce moisture content.
- Tailings treatment – recovery of water from coal slurry, minimizing environmental impact.
- Mining operations – processing of coal slime for reuse or disposal.
Why Choose Henan San Kuang Machinery? With a factory spanning 10,000-30,000 square meters and a dedicated team of 51-100 employees, we have achieved annual export values between US$2.5 Million and US$5 Million. Our products are shipped from major ports including Shanghai, Lianyungang, Qingdao, and Tianjin, ensuring timely delivery worldwide. We hold multiple management system certifications such as ISO9001, ISO14001, OHSAS18001, and others (available upon request), reflecting our commitment to quality and safety. Our semi-automatic coal slime dewatering press is built to deliver consistent performance, backed by our responsive after-sales support and spare parts availability.
Frequently Asked Questions (FAQ):
-
Q: What is the moisture content of the final cake?
A: Typically between 15% and 25%, depending on feed characteristics and pressure settings. Our equipment can be optimized for your specific material. -
Q: Is this press suitable for other materials besides coal slime?
A: Yes, it can be used for dewatering various slurries such as tailings, kaolin, or chemical sludge, provided the particle size and pH are compatible. We recommend a test with your material. -
Q: What is the power consumption per cycle?
A: Power consumption varies with model and cycle time. For a typical 300 m² press, the motor runs about 10-15 minutes per cycle, consuming approximately 2-4 kWh per cycle. -
Q: How long is the delivery time?
A: Standard models are shipped within 30-45 days after order confirmation. Customized units may require 45-60 days, depending on complexity. -
Q: Do you provide installation and training?
A: Yes, we offer on-site installation guidance and operator training as part of our service package. Remote support is also available. -
Q: What is the warranty period?
A: We provide a 12-month warranty from the date of shipment, covering manufacturing defects. Wear parts (filter cloth, seals) are excluded but available at competitive prices. -
Q: Can the press be upgraded to fully automatic?
A: Yes, we offer optional PLC and remote monitoring upgrades. Please contact our sales team for details. -
Q: What certifications does your factory have?
A: Our factory is certified with ISO9001, ISO14001, OHSAS18001, and others. Certificates can be provided upon request.
Contact us today to discuss your coal slurry dewatering requirements! Our team at Henan San Kuang Machinery Technology Co., Ltd. is ready to provide a tailored solution with competitive pricing and reliable after-sales support. We look forward to partnering with you for efficient and sustainable coal processing.
