As a trusted manufacturer since 2018, Shandong Sino Steel Co., Ltd. specializes in high-quality steel products. Our Electrolytic Tinplate Sheets 0.23mm Thickness, 900x1800mm Size, Passivation Treatment are engineered to meet the rigorous demands of packaging and industrial applications. With our ISO9000 certified production processes and factory spanning 10,000–30,000 square meters, we ensure every sheet delivers consistent thickness, excellent corrosion resistance, and superior formability.
These tinplate sheets are ideal for manufacturing food cans, aerosol containers, battery shells, and other deep-drawn products. The precise 0.23mm thickness and 900x1800mm dimension offer a perfect balance between strength and workability, while the passivation layer enhances rust protection and improves lacquer adhesion. Below, we detail the key attributes that make our product a reliable choice for global buyers.
Key Features & Benefits
- Precise Thickness Tolerance: ±0.005mm ensures uniform forming and stacking.
- Passivation Treatment: Chemical passivation (often dichromate or cathodic) provides a stable oxide layer, preventing tin oxidation and extending shelf life.
- Excellent Solderability & Weldability: Suitable for high-speed can seaming lines.
- Food-Grade Safety: Tin coating meets FDA and EU food contact standards (upon request).
- Customizable Supply: Available in different coating weights, temper grades, and edge trimming options.
- Eco-Friendly Production: Our factory uses low-emission processes, and the tinplate is 100% recyclable.
Technical Specifications
| Property | Value |
| Thickness | 0.23 mm (0.0091 inch) |
| Sheet Size | 900 mm × 1800 mm (35.4″ × 70.9″) |
| Tin Coating Weight | 2.8/2.8 g/m² (standard), other options available |
| Temper Grade | T2, T3, T4, T5 (customizable) |
| Surface Finish | Bright or Stone finish (optional) |
| Passivation Type | Dichromate or cathodic (upon request) |
| Oil Coating | DOS (dioctyl sebacate) applied, 2–5 mg/m² |
| Packing | Skid pack with steel straps, waterproof paper, and plywood (for export) |
Why Choose Our Tinplate Sheets?
Our 0.23mm passivated tinplate sheets offer distinct advantages over standard grades:
- Enhanced Corrosion Resistance: The passivation layer prevents tin oxidation even in humid environments, ensuring longer storage life for your products.
- Consistent Quality: Strict quality control during rolling, annealing, and electroplating processes guarantees uniform mechanical properties across every sheet.
- Cost-Effective: Optimized 0.23mm thickness reduces material usage while maintaining structural integrity for can manufacturing.
- Global Logistics: We ship from Qingdao, Tianjin, and Shanghai ports, with an annual export value of US$2.5–5 million, serving markets in North America, Europe, Southeast Asia, Africa, and the Middle East.
- Technical Support: Our 101-200 employees include experienced engineers who can assist with forming, welding, and printing processes.
Trusted by Global Customers
Shandong Sino Steel Co., Ltd. has been a reliable supplier since 2018. Our ISO9000 and ISO19011:2000 certified management systems ensure traceability and continuous improvement. With a factory area of 10,000–30,000 square meters and an overseas office for efficient communication, we are equipped to handle large-volume orders with short lead times. We invite you to contact us for a quotation or to request samples. Let us support your next project with high-quality electrolytic tinplate sheets.
Frequently Asked Questions
Q1: What is the thickness tolerance for these sheets?
A: The standard tolerance is ±0.005mm. For tighter tolerances, please discuss with our sales team.
Q2: Can you supply different sizes or cut-to-length sheets?
A: Yes, we offer customized sizes. The minimum order quantity for non-standard dimensions may vary.
Q3: Is the passivation treatment safe for food contact?
A: Our standard passivation is dichromate-based, which is acceptable for food cans under international regulations. We can also provide cathodic passivation upon request.
Q4: What is the minimum order quantity (MOQ)?
A: For standard 0.23mm, 900x1800mm sheets, the MOQ is typically 5 metric tons. Smaller trial orders are negotiable.
Q5: How long is the lead time for production?
A: Usually 15–20 days after receiving the order and down payment. Urgent orders may be expedited.
Q6: Do you provide free samples?
A: Yes, we can offer A4-sized samples free of charge, but the buyer pays for shipping. Please contact us to arrange.
Q7: What certifications do you hold?
A: Our company is ISO9000 and ISO19011:2000 certified. We can also provide mill test certificates and third-party inspection reports.
Q8: How do you pack the sheets for export?
A: Sheets are packed in wooden pallets with steel straps, waterproof paper, and protective corner boards to prevent damage during transit.
