As a leading manufacturer from Henan San Kuang Machinery Technology Co., Ltd., we proudly present our Planetary Gear Reducer with a precise 5:1 ratio, robust 200 Nm output torque, and IP65 protection in a compact design. This gear reducer is engineered to deliver high performance in demanding industrial environments, combining reliability, efficiency, and space-saving features. With over a decade of experience since 2014, our factory spanning 10,000–30,000 square meters ensures strict quality control and advanced manufacturing capabilities.
Our planetary gear reducers are designed for applications requiring high torque density and smooth operation. The 5:1 reduction ratio provides an optimal balance between speed reduction and torque multiplication, making it ideal for conveyors, packaging machines, robotics, and automation systems. The IP65 rating guarantees protection against dust ingress and water jets, ensuring long service life even in harsh conditions. The compact form factor allows easy integration into tight spaces without compromising performance.
Key Features & Benefits
- High Torque Capacity: 200 Nm output torque with low backlash, suitable for precise positioning and heavy loads.
- IP65 Protection: Fully sealed construction prevents ingress of dust and water, ideal for washdown environments.
- Compact & Lightweight: Space-saving design reduces overall system footprint and weight.
- Quiet Operation: Helical planetary gears (optional) ensure smooth and low-noise performance.
- High Efficiency: Up to 96% efficiency reduces energy loss and heat generation.
- Versatile Mounting: Available in flange or foot mounting options, customizable to your application.
- Durable Materials: Housing made of high-strength aluminum alloy (optional steel) and hardened steel gears for long life.
- Easy Maintenance: Lubricated for life; no frequent oil changes required.
Technical Specifications
| Parameter | Value |
|---|---|
| Reduction Ratio | 5:1 |
| Output Torque (Nominal) | 200 Nm |
| Max Input Speed | 3000 rpm |
| Protection Class | IP65 |
| Efficiency | Up to 96% |
| Backlash | ≤ 10 arcmin (standard) |
| Operating Temperature | -20°C to +60°C |
| Housing Material | Aluminum Alloy (optional steel) |
| Weight | Approx. 2.5 kg |
| Mounting Options | Flange / Foot / Custom |
This planetary gear reducer is designed to meet the needs of various industries, including automation, material handling, food processing, and packaging. Its compact size allows for direct integration with servo motors and stepper motors, reducing system complexity. The IP65 protection ensures reliable operation in wet or dusty environments, such as washdown applications in food and beverage plants.
Trusted by Global Customers
Henan San Kuang Machinery Technology Co., Ltd., established in 2014, operates a state-of-the-art factory covering 10,000–30,000 square meters with a dedicated team of 51–100 employees. Our annual export value reaches US$2.5–5 million, serving markets across North America, South America, Europe, Southeast Asia, Africa, and Oceania. We ship from major ports including Shanghai, Lianyungang, Qingdao, and Tianjin, ensuring timely delivery worldwide.
We hold multiple certifications such as ISO9001, ISO14000, OHSAS18001, and others, reflecting our commitment to quality, environmental management, and occupational health. Our products undergo rigorous testing to ensure consistent performance and durability. With a strong focus on customer satisfaction, we offer customization options and technical support to meet your specific requirements.
Frequently Asked Questions
-
Q: What is the backlash of this gear reducer?
A: The standard backlash is ≤ 10 arcmin. For higher precision applications, a low-backlash version (≤ 5 arcmin) is available upon request. -
Q: Can this gear reducer be used with a servo motor?
A: Yes, it is designed for direct mounting with standard servo motors. An input flange adapter kit can be provided for different motor brands. -
Q: Is the IP65 rating suitable for outdoor use?
A: Yes, IP65 protects against dust and water jets, making it suitable for outdoor installations where rain or washdown is expected. However, for prolonged submersion, a higher IP rating may be needed. -
Q: What lubricant is used? Is it maintenance-free?
A: The gearbox is factory-filled with synthetic grease and sealed for life, requiring no regular maintenance. For extreme operating conditions, periodic inspection is recommended. -
Q: What is the maximum input speed?
A: The maximum input speed is 3000 rpm. For higher speeds, please consult our engineering team for a customized solution. -
Q: Can I get a custom mounting configuration?
A: Yes, we offer flange, foot, and custom mounting options. Please provide your specific dimensions and requirements for a tailored solution. -
Q: What is the warranty period?
A: Our standard warranty is 12 months from the date of shipment. Extended warranty options are available upon request. -
Q: How do I select the right gear reducer for my application?
A: We recommend considering output torque, speed, duty cycle, and environmental conditions. Our technical team can assist you with sizing calculations and selection.
Experience the reliability and performance of our Planetary Gear Reducer. Contact us today for a quotation or technical consultation. We are committed to providing high-quality, cost-effective solutions tailored to your industrial needs.
