As a leading manufacturer from Qingdao Conqinphi Environmental Technology Group Co., Ltd., we proudly present our Energy-Saving Large Triple-Effect Evaporator, designed to meet the rigorous demands of industrial wastewater treatment and concentration processes. With over 9 years of expertise and a factory spanning 10,000-30,000 square meters, we integrate advanced PLC touch screen control, premium 304 stainless steel construction, and 380V power supply to deliver a reliable, efficient, and low-maintenance evaporation solution. Our triple-effect design significantly reduces energy consumption while maximizing throughput, making it a cost-effective choice for global clients in North America, South America, Europe, and beyond.
This evaporator system is engineered for long-term operation in harsh environments, featuring corrosion-resistant 304 stainless steel that ensures durability and compliance with food-grade and pharmaceutical standards. The intuitive PLC touch screen interface allows operators to monitor and adjust parameters in real time, optimizing performance without extensive training. Whether you are concentrating waste liquids, recovering valuable by-products, or reducing disposal volumes, our triple-effect evaporator offers a sustainable and profitable solution.
Key Features & Technical Specifications
- Triple-Effect Design: Utilizes three stages of evaporation to maximize heat recovery, reducing steam consumption by up to 50% compared to single-effect units.
- Energy Saving: Integrated heat exchanger and vapor recompression system minimize operational costs.
- 304 Stainless Steel Construction: All wetted parts are made of high-grade 304 stainless steel, offering excellent corrosion resistance and easy cleaning.
- PLC Touch Screen Control: User-friendly HMI with programmable logic controller for automated start-up, shutdown, and alarm management.
- 380V Power Supply: Standard three-phase industrial voltage, compatible with most global electrical grids (customizable upon request).
- Large Processing Capacity: Suitable for high-volume applications, with customizable feed rates from 500 L/h to 10,000 L/h.
- Low Maintenance: Self-cleaning design and durable components reduce downtime and service intervals.
- Compact Footprint: Vertical or horizontal configuration options to fit existing plant layouts.
| Parameter | Specification |
| Model | QCP-TEE-3000 (example) |
| Evaporation Capacity | 3,000 L/h (customizable) |
| Operating Temperature | 60°C – 100°C (first effect) |
| Power Consumption | ~15 kW (excluding pumps) |
| Steam Consumption | 0.4 kg steam per kg water evaporated |
| Material of Construction | 304 Stainless Steel (316L optional) |
| Control System | PLC + 7-inch Touch Screen |
| Power Supply | 380V / 50Hz / 3 Phase (customizable) |
| Dimensions (L×W×H) | 8m × 3m × 4m (approx.) |
| Certifications | ISO9001, HACCP, OHSAS18001, others |
Advantages for Your Business
- Reduce Operating Costs: The triple-effect energy recovery system cuts steam usage dramatically, lowering your utility bills. Many clients report a payback period of less than 18 months.
- Increase Productivity: High evaporation rates and automated operation allow continuous processing with minimal operator intervention.
- Improve Product Quality: Gentle evaporation at controlled temperatures preserves heat-sensitive compounds, ideal for food, pharmaceutical, and chemical industries.
- Environmental Compliance: Efficient concentration reduces waste volume, helping you meet discharge regulations and reduce hauling costs.
- Global Support: With an annual export value of US$10–50 million and a team of 201–300 employees, we provide after-sales service, spare parts, and technical support worldwide.
Our factory is located in Qingdao, Shandong, China, a major port city that facilitates fast and cost-effective shipping to all main markets. We have served clients in over 30 countries across North America, South America, Europe, Africa, Oceania, and Asia, consistently delivering reliable equipment that exceeds expectations. Our production lines are equipped with advanced welding and testing facilities, and each evaporator undergoes rigorous quality inspection before shipment.
We understand that every project has unique requirements. That’s why we offer customization options for capacity, material grade (304/316L), control system complexity, and auxiliary components (e.g., heat exchangers, vacuum pumps, condensers). Our engineering team works closely with you to design the optimal solution for your specific feed composition and target concentration.
Trust is built on performance and reliability. With certifications including ISO9001, HACCP, OHSAS18001, and more, we adhere to strict quality management standards. Our commitment to innovation and customer satisfaction has made us a preferred partner for many Fortune 500 companies and mid-sized enterprises alike. Contact us today to discuss your evaporation needs and discover how our Energy-Saving Large Triple-Effect Evaporator can transform your operation.
Frequently Asked Questions
-
Q: What is the typical processing capacity of this evaporator?
A: The standard model processes up to 3,000 L/h, but we can customize capacities from 500 L/h to 10,000 L/h based on your requirements. Please provide your feed rate and target concentration for a tailored design. -
Q: Can this evaporator handle corrosive or viscous liquids?
A: Yes, the 304 stainless steel construction offers good corrosion resistance for many chemicals. For highly corrosive fluids, we recommend upgrading to 316L stainless steel or other alloy options. Viscous liquids can be handled with appropriate pump and heat exchanger modifications. -
Q: How much energy does it save compared to a single-effect evaporator?
A: Our triple-effect design typically reduces steam consumption by 50–60% per kilogram of water evaporated, resulting in significant energy cost savings. Exact savings depend on feed temperature and composition. -
Q: Is the PLC touch screen difficult to operate?
A: No, the interface is designed for ease of use. It provides real-time data display, alarm history, and parameter adjustment. We provide operator training manuals and remote support. Most users become proficient within a few hours. -
Q: What maintenance is required?
A: Routine maintenance includes periodic cleaning of the heat exchanger surfaces and inspection of seals and pumps. The self-cleaning design reduces fouling, and the PLC system alerts you when maintenance is needed. Spare parts are readily available from our Qingdao factory. -
Q: Do you offer installation and commissioning services?
A: Yes, we can provide on-site supervision by our experienced engineers or remote guidance. We also offer complete turnkey solutions including piping, electrical integration, and startup support. -
Q: Can the 380V power supply be adapted to other voltages?
A: Absolutely. We can customize the electrical components for 220V, 440V, 600V, or other frequencies (50/60 Hz). Please specify your local power supply when ordering. -
Q: What is the warranty period?
A: We offer a standard 12-month warranty from the date of commissioning, covering manufacturing defects. Extended warranties are available upon request. Our after-sales team responds within 24 hours.
Company Profile: Qingdao Conqinphi Environmental Technology Group Co., Ltd. (Est. 2015) is a professional manufacturer with 201–300 employees, a 10,000–30,000 m² factory, and annual export value of US$10–50 million. We hold multiple certifications and have shipped to over 30 countries. Contact us for a quote or technical consultation.
