Hengshui Ruibin New Materials LLC is a dedicated manufacturer of fiberglass cable management solutions, and our Fiberglass Cable Ladder 2.5m Section 150mm Width UV Resistant for Outdoor Use is engineered to meet the demanding requirements of modern outdoor installations. With over 6 years of industry experience, we have refined our production processes to deliver a product that combines exceptional durability, lightweight handling, and long-term reliability. This cable ladder section is specifically designed to withstand harsh sunlight, moisture, and temperature fluctuations, making it an ideal choice for telecom, power, and industrial projects where metal alternatives would corrode or degrade.
Our fiberglass cable ladder offers a non-conductive, corrosion-proof solution that significantly reduces maintenance costs and extends service life. The 150mm width provides ample space for routing multiple cables while maintaining structural integrity. Each 2.5m section is precision-molded with UV-stabilized resin, ensuring color retention and mechanical performance even after years of direct exposure to sunlight. Whether you are building a new outdoor cable tray system or upgrading an existing one, this product delivers consistent performance and easy installation.
Key Features & Technical Specifications
- UV-Stabilized Construction: Special additives in the resin system prevent degradation from ultraviolet radiation, ensuring the ladder remains strong and weather-resistant over decades of outdoor use.
- Corrosion & Chemical Resistance: Unlike steel or aluminum, fiberglass does not rust or react with most chemicals, making it perfect for coastal, industrial, or wastewater treatment environments.
- Lightweight & High Strength: At only a fraction of the weight of metal ladders, this section reduces transportation and installation labor costs while maintaining load-bearing capacity comparable to steel.
- Non-Conductive & Safe: The dielectric properties of fiberglass eliminate the risk of electrical shock, providing added safety for workers and equipment in high-voltage areas.
- Modular Design: Each 2.5m section features standard coupling points for quick and secure connection to adjacent sections, allowing for flexible system layouts.
- Low Maintenance: No painting, coating, or periodic rust treatment is required — simply clean with water if needed.
| Parameter | Specification |
|---|---|
| Material | Fiberglass Reinforced Polyester (FRP) with UV stabilizers |
| Section Length | 2.5 meters (custom lengths available upon request) |
| Width | 150 mm (other widths customizable) |
| Rung Spacing | Standard 250 mm (adjustable per design) |
| Load Capacity | Up to 75 kg/m (depending on design configuration) |
| Fire Resistance | Self-extinguishing (UL 94 V-0 equivalent optional) |
| Color | Standard gray, yellow, or custom RAL colors |
| Operating Temperature | -40°C to +80°C (higher range on request) |
Benefits for Your Project: By choosing our fiberglass cable ladder, you gain a product that not only meets but exceeds the expectations of outdoor cable management. The UV-resistant formulation ensures that the ladder does not become brittle or discolor over time, maintaining its appearance and structural integrity. Additionally, the lightweight nature reduces the need for heavy lifting equipment, speeding up installation and cutting project costs. The non-conductive property eliminates the need for grounding in many applications, simplifying design and reducing material expenses.
Our manufacturing facility in Hengshui, Hebei, China, operates under strict quality control procedures, and we hold ISO9001 & ISO9000 certifications to guarantee consistent product quality. With an annual export value of US$2.5 million to US$5 million and a team of 101–200 experienced employees, we have the capacity to fulfill large orders while maintaining fast lead times. Our products are shipped from the Port of Tianjin or Port of Qingdao to major markets worldwide, including North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East.
Trust & Reliability: Since our establishment in 2019, we have built a reputation for delivering durable, cost-effective cable management solutions. Our fiberglass cable ladder has been tested in diverse outdoor environments — from humid coastal regions to arid desert climates — and consistently performs. We work closely with clients to customize dimensions, load ratings, and accessories to match specific project requirements. Contact us today to discuss your needs and experience the quality that comes from a dedicated manufacturer.
Frequently Asked Questions
-
Q: Is this cable ladder truly UV resistant for long-term outdoor use?
A: Yes, we use UV-stabilized resin formulations that have been tested to withstand continuous exposure to sunlight without significant degradation. The material retains its mechanical properties and color for many years, making it suitable for outdoor installations. -
Q: Can I get custom lengths or widths?
A: Absolutely. While our standard section is 2.5m long and 150mm wide, we offer customization. Please provide your specific requirements, and we will manufacture accordingly. -
Q: What is the load capacity of this 150mm wide ladder?
A: The load capacity depends on the rung spacing, side rail thickness, and overall design. Typically, it can support up to 75 kg/m for standard configurations. For precise load data, please contact us with your project details. -
Q: Is this product fire-resistant?
A: Our standard fiberglass resin is self-extinguishing. For applications requiring specific fire ratings, such as UL 94 V-0, we can produce a special formulation upon request. -
Q: How do I connect multiple sections together?
A: Each section is designed with coupling points and we provide matching splice plates and fasteners. The connection is quick and secure, ensuring a continuous cable pathway. -
Q: Do you offer any accessories like covers, bends, or dividers?
A: Yes, we manufacture a full range of accessories including covers, 90-degree bends, T-pieces, reducers, and divider strips. These are also available in UV-resistant fiberglass. -
Q: What is the typical lead time for an order?
A: For standard sizes, lead time is approximately 15–25 working days depending on quantity. Custom orders may require additional time. We can expedite for urgent projects. -
Q: How do you ensure quality consistency?
A: Our factory is ISO9001 and ISO9000 certified. We conduct raw material inspection, in-process checks, and final product testing (including UV resistance, load tests, and dimensional verification) to ensure every batch meets specifications.
