Product Spotlights

Full-automatic PLC control with touchscreen; 8-12 bar pressure for efficient pretreatment; corrosion-resistant SS316L/duplex materials; energy consumption as low as 0.3 kWh/m³; customizable capacity up to 100 m³/h; global certifications (ISO9001, HACCP) and worldwide after-sales support.
US$ 8460 - 8840000 MOQ: 1 Combo
Key Specifications
Get Latest Price
Voltage:
220V/380V
Operating Pressure:
8-12 Bar
Material:
Stainless Steel 316L / Duplex Stainless Steel
Contact Supplier Request Quote Chat Now
Qingdao Conqinphi Environmental Technology Group Co., Ltd.
Gold Verified Supplier
1Yr
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
50 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Voltage 220V/380V
Operating Pressure 8-12 Bar
Material Stainless Steel 316L / Duplex Stainless Steel
Automation Fully Automatic PLC Control
Capacity Customizable (1-100 m³/h)
Application Seawater Desalination, Industrial Water Treatment
Certification ISO9001, HACCP, OHSAS18001
Power 3-15 kW (Optional)

As a leading manufacturer from Qingdao Conqinphi Environmental Technology Group Co., Ltd., we present our Fully Automatic Seawater Desalination Pretreatment Evaporation System — a robust solution designed to remove impurities and protect downstream reverse osmosis membranes. Operating at 220V/380V with 8-12 bar pressure, this system ensures high efficiency and long service life. Built with over 8 years of industry expertise, our equipment serves clients across 5 continents, combining advanced automation with reliable pretreatment technology.

Key Features & Technical Specifications

  • Fully Automatic PLC Control — Touchscreen interface with real-time monitoring, automatic backwash, and alarm functions, reducing manual intervention.
  • High Operating Pressure (8-12 Bar) — Ensures effective removal of suspended solids, colloids, and organic matter, optimizing feed water quality for RO systems.
  • Corrosion-Resistant Materials — Constructed from 316L stainless steel or duplex stainless steel, suitable for harsh seawater environments.
  • Energy-Efficient Design — Low power consumption (3-15 kW) with variable frequency drive options, reducing operational costs.
  • Compact Footprint — Skid-mounted or containerized design, easy to install and integrate into existing desalination plants.
  • Multi-Stage Filtration — Includes sand filter, carbon filter, cartridge filter, and optional UV sterilization for complete pretreatment.
  • Customizable Capacity — Available from 1 m³/h to 100 m³/h, tailored to specific project requirements.

Technical Parameters

Parameter Specification
Model CQ-EDP-Series
Rated Voltage 220V / 380V, 50/60Hz, 3-Phase
Operating Pressure 8-12 Bar (Adjustable)
Max Flow Rate Up to 100 m³/h
Filtration Accuracy 5-50 µm (Customizable)
Material of Construction SS316L / Duplex SS / FRP
Control System Siemens PLC + HMI Touch Screen
Certification ISO9001, HACCP, OHSAS18001, etc.

Client Benefits

  • Extended RO Membrane Life — Effective pretreatment reduces fouling, scaling, and chemical cleaning frequency.
  • Lower Maintenance Costs — Automatic backwash and self-cleaning features minimize downtime and labor.
  • Stable Water Quality — Consistent SDI (Silt Density Index) below 3, meeting RO feed water standards.
  • Flexible Installation — Skid-mounted or containerized, suitable for offshore platforms, ships, or coastal plants.
  • Global Support — Our team provides installation guidance, commissioning, and after-sales service worldwide.

Why Choose Qingdao Conqinphi?

Founded in 2015, our factory spans 10,000-30,000 m² and employs 201-300 skilled workers. With annual export value exceeding US$10 million, we have delivered equipment to North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East. Our products are certified under ISO9001, HACCP, OHSAS18001, and multiple other quality standards. We are committed to providing reliable, sustainable water treatment solutions. Choosing our Fully Automatic Seawater Desalination Pretreatment Evaporation System means investing in proven technology and long-term partnership. Contact us today for a tailored quotation!

Frequently Asked Questions

  1. Q: What is the working principle of this system?
    A: It uses multi-media filtration, activated carbon adsorption, and precision filtration to remove suspended solids, organic matter, and chlorine from seawater, followed by evaporation concentration for brine treatment. The PLC automates backwash cycles.
  2. Q: Can this system handle high-salinity seawater?
    A: Yes, it is designed for Total Dissolved Solids (TDS) up to 45,000 ppm. For higher salinity, we can upgrade the material to duplex stainless steel.
  3. Q: What is the typical warranty period?
    A: Standard warranty is 12 months from commissioning or 18 months from shipment, whichever comes first. Extended warranty options are available upon request.
  4. Q: Does the system require special installation conditions?
    A: It requires a flat concrete foundation, 220V/380V power supply, and raw water inlet/outlet connections. We provide free layout drawing and installation manual.
  5. Q: What is the energy consumption per cubic meter of treated water?
    A: Typically 0.3-0.8 kWh/m³ depending on feed water quality and flow rate. Our system uses energy-efficient pumps and VFD to minimize costs.
  6. Q: Can I integrate this system with an existing RO plant?
    A: Absolutely. The system is designed as a drop-in pretreatment solution. We can customize the inlet/outlet flanges to match your existing piping.
  7. Q: Do you provide spare parts and after-sales service?
    A: Yes, we stock common spare parts and offer remote technical support. Our service team can visit your site for commissioning and training.
  8. Q: How long does delivery take?
    A: Standard delivery time is 30-45 days after order confirmation. For urgent projects, we can expedite within 20 days.
Product Tags: Seawater Desalination Pretreatment System , Automatic Evaporation System , Reverse Osmosis Pretreatment Equipment
