As a trusted supplier based in Xi'an, Shaanxi, China, Xi'an Fengyao Technology Co., Ltd. is proud to offer our premium Gr23 Titanium Wire ASTM B863 Straightened 0.8mm Diameter with Tight Tolerance. With over 5,000 square meters of production space and a dedicated team of 5-10 experienced professionals, we ensure every batch meets rigorous quality standards. Our ISO9001 and ISO14000 certifications underscore our commitment to excellence and environmental responsibility. This Gr23 titanium wire is specifically engineered for applications demanding exceptional strength, corrosion resistance, and biocompatibility, making it an ideal choice for medical implants, aerospace components, and high-performance chemical processing equipment.
Our straightened titanium wire is manufactured under strict control of the ASTM B863 standard, ensuring consistent mechanical properties and dimensional accuracy. The 0.8mm diameter with tight tolerance (±0.02mm) allows for precise fit in intricate assemblies. We have an annual export value of US$2.5 to US$5 million, serving markets across North America, South America, Europe, Asia, Africa, and Oceania. Our products are shipped from major ports like Tianjin and Shanghai, ensuring timely delivery worldwide.
Key Features & Technical Specifications
Material Grade: Gr23 (Ti-6Al-4V ELI) – Extra Low Interstitial for superior ductility and fracture toughness.
Standard Compliance: ASTM B863 – covers titanium and titanium alloy wire for cold heading, fasteners, and general applications.
Diameter: 0.8 mm (0.0315 inch) with tight tolerance of ±0.02 mm, ensuring uniform cross-section.
Condition: Straightened – wire is mechanically straightened to achieve excellent straightness, reducing springback and facilitating automated feeding.
Surface Finish: Available in bright (pickled), polished, or as-rolled finish. Optional oxide coating for enhanced corrosion resistance.
Mechanical Properties: Tensile strength: 900–1100 MPa; Yield strength: 830–1000 MPa; Elongation: ≥10%.
Length: Supplied in coils (standard 5–50 kg) or cut-to-length straight rods up to 3 meters.
Packaging: Securely wound on spools or packed in wooden crates to prevent damage during transit.
Product Advantages
Compared to standard titanium wire, our Gr23 grade offers enhanced fracture toughness and lower impurity levels, making it indispensable for medical implant devices (e.g., bone screws, surgical wires) and aerospace fasteners. The tight tolerance eliminates the need for secondary machining in many applications, saving time and cost. The straightened condition ensures consistent feeding into CNC machines, improving production efficiency. Additionally, the wire exhibits excellent weldability and formability, allowing for complex bends and shapes without cracking.
Typical Applications
| Industry | Application |
|---|---|
| Medical | Orthopedic implants, dental wires, surgical sutures, bone fixation devices |
| Aerospace | Fasteners, springs, structural components, rivets |
| Chemical Processing | Heat exchangers, filtration screens, electrode wires |
| Automotive | High-performance springs, exhaust system components |
| Marine | Underwater connectors, sensor housings, cable sheathing |
Quality Assurance & Trust
Every spool of our Gr23 titanium wire is subjected to strict quality control including chemical composition analysis, tensile testing, and dimensional inspection. Our factory is ISO9001 and ISO14000 certified, ensuring consistent quality and environmental management. We have served clients in over 30 countries since 2022, with a strong reputation for on-time delivery and product reliability. Our annual export value of US$2.5–5 million reflects the trust our customers place in us. We also offer customized packaging, third-party inspection, and sample testing upon request. Choose Xi'an Fengyao Technology Co., Ltd. for your critical titanium wire needs – contact us today for a quote or technical consultation.
Frequently Asked Questions (FAQ)
What is the difference between Gr23 and Gr5 titanium wire?
Gr23 (Ti-6Al-4V ELI) has lower oxygen and iron content than Gr5, resulting in improved fracture toughness and ductility, making it more suitable for medical implants and critical aerospace applications.Can you supply the wire in different lengths or custom diameters?
Yes, we offer customization. Standard diameters range from 0.1mm to 5.0mm, and lengths can be tailored to your requirements. Please contact our sales team with your specifications.What is the typical lead time for this product?
For standard 0.8mm wire, lead time is 7–15 working days depending on order quantity. Custom orders may require additional time.Is the wire annealed or cold-drawn?
Our wire is cold-drawn and then straightened. It can be supplied in an annealed condition if required for improved formability.Do you provide certificates of analysis (COA) and material test reports?
Absolutely. We provide a full Mill Test Certificate (MTC) with each shipment, including chemical composition and mechanical properties.What packaging options are available?
We offer spools (1kg, 5kg, 10kg), coils, or straight cut lengths in bundles. Export-grade wooden crates are used for ocean freight.Can I get a sample before placing a bulk order?
Yes, samples are available for evaluation. We may charge a nominal fee, which is refundable upon bulk order.What is the minimum order quantity (MOQ)?
For standard 0.8mm wire, MOQ is 10kg. For custom sizes, MOQ may be higher. Contact us for details.
