Welcome to Hemaokang Steel (Shandong) Co., Ltd. We are a trusted manufacturer of high-quality steel building materials, serving global markets with an annual export value of US$50 million to US$100 million. Our Durable Pre Coated Corrugated Board for Industrial Warehouse Construction (0.5mm thickness) is engineered to provide superior strength, corrosion resistance, and aesthetic appeal for demanding industrial environments. This product is the ideal choice for warehouses, factories, and large-scale storage facilities that require long-lasting roofing and cladding solutions.
Why choose our pre-coated corrugated board? It combines the durability of a robust steel substrate with a factory-applied protective coating, ensuring resistance to rust, UV radiation, and harsh weather conditions. The 0.5mm thickness offers an optimal balance between weight and structural integrity, making it easy to handle during installation while providing reliable load-bearing capacity. Our advanced production line, located in Liaocheng, Shandong, China, ensures consistent quality and tight tolerances.
Key Features & Technical Specifications
- Material Base: High-tensile galvanized or galvalume steel (optional).
- Coating: Pre-coated with premium polyester, PVDF, or HDP (high durability polyester) – customizable per project requirements.
- Thickness: 0.5mm (also available in other gauges upon request).
- Corrugation Profile: Standard wave profiles (e.g., YX28-205-820, YX35-125-750, or custom molds).
- Width: Effective width typically 820mm, 900mm, 1000mm, or 1200mm, with total width slightly larger.
- Length: Cut to order, from 1m to 12m or more, as per your design.
- Color Options: RAL colors, metallic finishes, and wood grain patterns available.
- Corrosion Resistance: Salt spray test up to 500 hours (depending on coating type).
- Fire Resistance: Non-combustible steel core (A2 grade).
| Parameter | Value |
|---|---|
| Base Metal Thickness | 0.5mm ±0.02mm |
| Coating Thickness | 20–40μm (topcoat) + 5–10μm primer |
| Yield Strength | ≥ 350 MPa (depending on steel grade) |
| Zinc Coating Weight (if galvanized) | Z80–Z275 g/m² (optional) |
| Temperature Range | -20°C to +80°C (continuous use) |
Benefits for Your Industrial Warehouse Construction
- Speed of Installation: Lightweight yet strong, reducing labor costs and construction time.
- Long Service Life: Pre-coated finish resists chalking, fading, and corrosion for 20+ years under normal conditions.
- Low Maintenance: No need for repainting or additional surface treatment after installation.
- Energy Efficiency: Reflective coatings can reduce heat absorption, lowering cooling costs.
- Versatility: Suitable for both roofing and wall cladding, with matching accessories (flashings, fasteners).
- Eco-Friendly: Steel is 100% recyclable; our production process complies with environmental standards.
Why Partner with Hemaokang Steel?
Established in 2025, our company has rapidly grown into a reliable supplier with a team of 51–100 experienced professionals. We are ISO9001 certified, ensuring rigorous quality control from raw material procurement to final packaging. With an annual export value exceeding US$50 million, we have successfully shipped our products to over 10 regions worldwide, including North America, South America, Europe, Africa, Southeast Asia, and Oceania. Our factory in Liaocheng, Shandong, is strategically located near Qingdao Port, enabling efficient logistics and timely delivery. We offer flexible customization, competitive pricing, and dedicated after-sales support. Whether you need a small batch for a local project or a large container shipment for a major industrial complex, we are ready to meet your needs.
Frequently Asked Questions (FAQ)
-
Q: What is the minimum order quantity (MOQ) for this product?
A: MOQ varies by specification. For standard 0.5mm pre-coated corrugated board, typical MOQ is 100 square meters. For customized colors or profiles, MOQ may be higher. Please contact us for details. -
Q: Can I get samples before placing a bulk order?
A: Yes, we offer free samples (shipping cost covered by buyer) for quality evaluation. Sample production takes 3–5 working days. -
Q: How long does delivery take?
A: Lead time is usually 15–25 days after deposit confirmation, depending on order quantity and customization. Expedited options are available upon request. -
Q: What kind of coating do you recommend for coastal areas?
A: For high-corrosion environments, we recommend PVDF coating or HDP coating with a thicker zinc layer (Z275 or above). Galvalume base is also an option. -
Q: Do you provide installation instructions or technical support?
A: Yes, we provide basic installation guidelines and can arrange technical consultation via video or email. For large projects, we may offer on-site support (subject to negotiation). -
Q: Are your products certified for fire resistance?
A: Our steel base is non-combustible, achieving Class A2 fire rating according to EN 13501-1. The coating does not contribute to fire spread. Please request the test report if needed. -
Q: Can you match a specific RAL color from my project?
A: Absolutely. We can produce any RAL color, as well as special finishes like metallic, textured, or wood grain. A color sample can be provided for approval before mass production. -
Q: What is the warranty period for this product?
A: We offer a standard warranty of 15 years against peeling, cracking, and excessive chalking, subject to proper installation and environmental conditions. Extended warranty options are available.
Take the Next Step – Contact us today for a quote, sample, or technical consultation. Hemaokang Steel is your reliable partner for durable, pre-coated corrugated board solutions that enhance your industrial warehouse construction. Let us help you build stronger, smarter, and more cost-effective structures.
