Hengshui Ruibin New Materials LLC, a leading manufacturer established in 2019, proudly presents our Lightweight FRP Grating for Easy Installation and Long-Lasting Durability. Engineered from premium fiberglass composites, this grating combines exceptional strength with a weight that is 75% lighter than steel, dramatically reducing transportation and installation costs. Whether you need a reliable solution for industrial platforms, trench covers, or pedestrian walkways, our FRP grating delivers unmatched corrosion resistance, slip safety, and a service life exceeding 20 years in most environments.
Our factory spans 1,000–3,000 square meters with 101–200 skilled employees, ensuring rigorous quality control and efficient production. We export to over 15 markets worldwide, including North America, Europe, and Southeast Asia, with annual export value between US$2.5 million and US$5 million. Every grating panel is manufactured using advanced pultrusion or compression molding processes, and we offer customizable dimensions, colors, and resin formulations to meet your project’s specific requirements.
Key Features & Technical Specifications
- Ultra-Lightweight Design: Weighing only 1/4 of steel, with typical panel weight starting from 8 kg/m² (for 25mm thickness). Reduces structural load and simplifies manual handling.
- Corrosion Resistance: Impervious to moisture, chemicals, saltwater, and UV. Ideal for sewage treatment plants, chemical processing, and offshore platforms.
- High Load Capacity: Available in light, medium, and heavy-duty grades. Can support concentrated loads up to 500 kg/m² (customizable).
- Slip-Resistant Surface: Concave, convex, or grit-top options provide excellent traction even when wet.
- Easy Installation: Can be cut on-site with standard power tools; clip or screw fixing systems available. No welding required.
- Fire-Retardant Option: Resin formulations can achieve Class 1 flame spread rating (ASTM E84) or equivalent upon request.
- Low Maintenance: Non-conductive, non-magnetic, and does not rot or rust. Requires only occasional washing.
- Custom Sizes & Colors: Panel widths up to 1.2m, lengths up to 6.0m, thickness from 20mm to 50mm. Color coding available for safety zones.
Performance Data Table (Typical Values)
| Parameter | Value (Example) |
|---|---|
| Standard Panel Size (mm) | 1220 × 3660 × 25 |
| Weight per m² | ~8 kg (for 25mm thick, light duty) |
| Maximum Span (mm) | 500–1000 (depending on load and thickness) |
| Concentrated Load Capacity | Up to 500 kg (medium duty) |
| Tensile Strength (MPa) | ≥200 (longitudinal) |
| Operating Temperature Range | -50°C to +100°C (standard resin) |
| Color Options | Gray, Yellow, Green, Blue, Orange, Red (custom) |
Benefits for Your Business
- Reduce Total Installed Cost: Lower shipping weight and faster installation mean up to 40% savings compared to steel grating.
- Safer Work Environment: Dielectric properties eliminate electrical shock risk; anti-slip surface prevents falls in wet/oily conditions.
- Zero Corrosion Worries: In harsh environments (e.g., wastewater, marine, chemical), stainless steel may still corrode—FRP grating remains unaffected.
- Eco-Friendly Option: Long lifespan reduces replacement frequency; material is inert and recyclable (consult local facilities).
- Consistent Quality: Our 101–200 employees follow ISO-based procedures (certification available upon request). Every panel is inspected for dimensional accuracy and surface finish.
Trust & Proven Track Record
Hengshui Ruibin New Materials LLC has been serving global clients since 2019, with an annual export value between US$2.5 million and US$5 million. Our products are shipped from the ports of Tianjin or Qingdao to markets including North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, the Middle East, and more. With a dedicated R&D team and a 1,000–3,000 m² factory, we continuously improve our formulations and production processes. Our clients include industrial contractors, EPC companies, and municipal infrastructure projects who rely on the durability and ease of installation of our FRP grating. We invite you to request a quote or ask for a free sample to experience the quality firsthand. Contact our sales team today—we are ready to support your project from design to delivery.
Frequently Asked Questions (FAQ)
Q1: What is the typical lead time for standard FRP grating panels?
A: For standard sizes and colors, lead time is 7–15 working days after order confirmation. Custom orders may require 15–25 working days, depending on quantity and complexity.
Q2: Can the grating be used outdoors in direct sunlight?
A: Yes. Our standard UV-resistant resin formulation prevents yellowing and degradation. For extremely high UV exposure, we recommend adding a UV-stabilized topcoat (available upon request).
Q3: Is this FRP grating suitable for heavy vehicle traffic (e.g., forklifts)?
A: Yes, but you must select a heavy-duty grade with appropriate thickness and bar spacing. Our engineering team can recommend the correct load rating for your application—please provide wheel load and contact area.
Q4: How is the grating installed? Do I need special tools?
A: Installation is straightforward. Panels can be cut using a circular saw with a carbide blade or a handheld grinder. For fixing, use FRP clips, stainless steel bolts, or a simple mechanical fastening system—all available from us. No welding or heavy lifting equipment is needed.
Q5: What is the fire resistance rating?
A: Standard polyester resin has a flame spread index of about 25–50 (Class II). If you require a Class I rating (≤25), we can supply a fire-retardant (FR) resin system. Please specify when ordering.
Q6: Do you provide samples before bulk order?
A: Absolutely. We can send small sample pieces (e.g., 200×200 mm) for testing. Shipping cost is on the buyer’s account, but the sample is free. Contact our sales team to arrange.
Q7: Can you customize the color to match my company’s branding?
A: Yes, we can match most RAL or Pantone colors. Minimum order quantity for custom color may apply (typically 50 m² or more). Please inquire for details.
Q8: What is the warranty on your FRP grating?
A: We offer a limited warranty against manufacturing defects for 5 years under normal use conditions. For specific environmental conditions (e.g., extreme chemicals), we recommend using a custom resin formulation and the warranty period can be discussed on a case-by-case basis.
