Qingdao Conqinphi Environmental Technology Group Co., Ltd. proudly presents our advanced Water Treatment MVR Evaporation System, specifically engineered for pharmaceutical wastewater treatment. Since our establishment in 2015, we have dedicated ourselves to manufacturing high-quality environmental equipment, serving over 200 employees in a 10,000-30,000 sqm factory. This stainless steel MVR system stands out for its exceptional energy efficiency, robust construction, and compliance with international standards, making it the optimal solution for concentrated, high-pollutant wastewater streams in the pharmaceutical industry.
Our MVR (Mechanical Vapor Recompression) evaporation technology utilizes a mechanical compressor to recompress the vapor generated during evaporation, drastically reducing energy consumption compared to traditional multi-effect evaporators. The entire system is constructed from stainless steel to resist corrosion from aggressive pharmaceutical effluents, ensuring long service life and low maintenance.
Below are the key features and technical specifications that distinguish our MVR evaporation system:
- Energy Efficiency: Up to 80% energy savings by recycling latent heat from vapor. The system operates with a specific energy consumption of only 20-60 kWh per ton of water evaporated.
- High Evaporation Capacity: Designed for continuous 24/7 operation with capacities ranging from 1 ton/hour to 50 tons/hour, customizable to your specific volume requirements.
- Advanced PLC Control: Fully automatic operation with real-time monitoring of temperature, pressure, flow rate, and liquid level. Touch screen interface allows for easy parameter adjustment and remote monitoring.
- Stainless Steel Construction: All wetted parts are made of SS304 or SS316L, providing excellent resistance to acids, alkalis, and organic solvents commonly found in pharmaceutical wastewater.
- Low Scaling and Fouling: Specialized design with forced circulation or falling film configuration to minimize scaling and fouling, even with high TDS and sticky materials.
- Compact Footprint: Modular design saves floor space and allows for easy installation and expansion.
- Zero Liquid Discharge (ZLD) Capability: When combined with crystallizer or dryer, the system can achieve near-zero liquid discharge, recovering valuable byproducts and clean water.
| Parameter | Specification |
| Evaporation Temperature | 60-100°C (adjustable) |
| Operating Pressure | Atmospheric or slight vacuum |
| Power Supply | 380V/440V/600V, 50/60Hz, 3-phase |
| Material of Construction | SS304 / SS316L (optional) |
| Control System | PLC + HMI, remote monitoring available |
| Compressor Type | Centrifugal / Roots / Screw (depending on capacity) |
| Pre-treatment Required | Filtration and pH adjustment recommended |
| Certifications | ISO9001, ISO14000, OHSAS18001 |
Our system provides tangible benefits to pharmaceutical manufacturers: reduced operational costs through low energy use, compliance with stringent discharge regulations by producing high-purity distillate, and minimized waste volume that lowers downstream disposal expenses. Additionally, the modular construction allows for easy integration with existing treatment lines.
At Qingdao Conqinphi, we are a trusted manufacturer with an annual export value of US$10-50 million and a factory spanning over 10,000 square meters. We have successfully delivered MVR systems to clients across North America, Europe, Southeast Asia, and the Middle East, among other regions. Our products are certified under ISO9001, ISO14000, and OHSAS18001, ensuring rigorous quality and environmental management. With over 300 employees dedicated to innovation and service, we provide comprehensive technical support from design to commissioning and after-sales maintenance. Choose our MVR Evaporation System for reliable, efficient, and sustainable pharmaceutical wastewater treatment.
Frequently Asked Questions (FAQ)
-
Q: What is the typical payback period for your MVR system?
A: Depending on energy costs and operating hours, most clients achieve payback within 1-3 years due to substantial savings in steam and cooling water. -
Q: Can the system handle pharmaceutical wastewater with high organic content?
A: Yes. Our MVR system is designed to concentrate high-COD wastewater. However, pre-treatment such as filtration and pH adjustment is recommended to protect the compressor and heat exchanger surfaces. -
Q: What stainless steel grade do you recommend for corrosive pharmaceutical effluent?
A: For most applications, SS316L provides superior corrosion resistance. For highly aggressive streams, we can also offer duplex stainless steel or special coatings upon request. -
Q: How is scaling in the heat exchanger prevented?
A: We employ forced circulation or falling film designs with high flow velocity to minimize scaling. Additionally, periodic CIP (Clean-in-Place) systems are integrated for automatic cleaning. -
Q: Do you provide installation and commissioning services?
A: Yes. We offer on-site installation guidance and commissioning by our experienced engineers. Remote support is also available. -
Q: What is the lifespan of the MVR system?
A: With proper maintenance, the system can operate reliably for more than 15 years. The compressor is the key component; we use high-quality brands and provide spare parts easily. -
Q: Can the system achieve zero liquid discharge (ZLD)?
A: Yes. When combined with a crystallizer or dryer module, our MVR system can achieve ZLD, producing solid salts and distilled water for reuse. -
Q: What certifications does your company hold?
A: Our company is certified under ISO9001 (Quality Management), ISO14000 (Environmental Management), and OHSAS18001 (Occupational Health & Safety). Additional certifications are available upon request.
