304 Stainless Steel Long Tube Vertical Evaporator With PLC Control for Efficient Concentration
Product Spotlights
304 stainless steel long tube vertical evaporator with PLC control ensures efficient concentration, energy saving, and easy operation. Customizable capacity, robust construction, and automated control make it ideal for food, chemical, and pharmaceutical industries. Backed by an ISO-certified manufacturer with global export experience and comprehensive after-sales support.
US$ 21200 - 879000
MOQ: 1 Combo
Key Specifications
Get Latest Price
Type:
Other, Long Tube Vertical Evaporator
Material:
304 Stainless Steel
Control System:
PLC with HMI Touch Screen
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
30 days
Related Products
-
Long Tube Vertical Evaporator With 1-Year Warranty and On-Site Installation TrainingUS$ 21200 - 879000MOQ: 1 Combo -
Industrial MVR Sodium Chloride Crystallizer With Forced Circulation, 316L Material, 220V/50Hz Power SupplyUS$ 3220 - 7859000MOQ: 1 Combo
-
Energy Saving 30% MVR Evaporator for NaCl Crystallization With 85°C Operating Temperature and Automatic ControlUS$ 3220 - 7859000MOQ: 1 Combo
-
Mill Test Report Included – MVR Evaporator Crystallizer for Sodium Chloride With After Sales Support and Spare PartsUS$ 3220 - 7859000MOQ: 1 Combo
-
PLC Controlled 500 Kg/h Sodium Chloride MVR Evaporation Crystallization System in 316L Stainless SteelUS$ 3220 - 7859000MOQ: 1 Combo
Type
Other, Long Tube Vertical Evaporator
Material
304 Stainless Steel
Control System
PLC with HMI Touch Screen
Application
Food, Chemical, Pharmaceutical Concentration
Heating Method
Steam / Thermal Oil / Electric (Optional)
Capacity
Customizable (e.g., 500-5000 L/h)
Operating Pressure
Atmospheric or Vacuum (Configurable)
Evaporation Temperature
Adjustable up to 150°C
As a premier manufacturer based in Qingdao, China, Qingdao Conqinphi Environmental Technology Group Co., Ltd. brings over a decade of expertise in industrial evaporation solutions. Our 304 Stainless Steel Long Tube Vertical Evaporator with PLC Control is meticulously designed to deliver efficient concentration for a wide range of liquid products, from fruit juices to chemical solutions. With a factory spanning 10,000–30,000 square meters and a dedicated team of 201–300 employees, we produce robust equipment that meets international quality standards. This evaporator integrates advanced PLC automation with durable 304 stainless steel construction, ensuring precise, energy-saving, and reliable operation for your production line.
Key Features & Technical Specifications
- High-Efficiency Heat Transfer: The long tube vertical design maximizes the heat transfer surface area, significantly improving evaporation rates and reducing energy consumption.
- Fully Automated PLC Control: A user-friendly HMI touch screen allows you to set and monitor temperature, pressure, feed rate, and concentration levels in real time. The system supports automatic startup, shutdown, and alarm notifications.
- Durable 304 Stainless Steel Construction: All wetted parts are made of 304 SS, offering excellent corrosion resistance and compliance with food-grade and pharmaceutical hygiene requirements.
- Flexible Heating Options: Choose from steam heating, thermal oil circulation, or electric heating based on your available utilities and process needs.
- Compact Vertical Layout: The vertical orientation saves valuable floor space while maintaining high throughput capacity.
- Customizable Capacity: Our evaporators are available in various sizes to match your production volume, from small pilot-scale units to large industrial systems.
- Easy Maintenance & Cleaning: The tube bundle is designed for quick disassembly, and the smooth stainless steel surfaces facilitate CIP (Clean-in-Place) procedures.
- Versatile Applications: Ideal for concentrating fruit juices, dairy products, sugar syrups, pharmaceutical extracts, chemical solutions, and wastewater treatment.
| Parameter | Specification |
|---|---|
| Material | 304 Stainless Steel |
| Control System | PLC + HMI Touch Screen |
| Evaporation Capacity | 500 – 5000 L/h (customizable) |
| Operating Temperature | Up to 150°C (adjustable) |
| Heating Medium | Steam / Thermal Oil / Electric (optional) |
| Power Supply | 380V / 50Hz (or as required) |
| Operating Pressure | Atmospheric or Vacuum |
| Dimensions (L×W×H) | Customized based on capacity |
Customer Benefits
- Increased Production Efficiency: Achieve higher concentration levels in less time, reducing batch cycle durations.
- Lower Operating Costs: Energy-efficient design and automated process control minimize steam and electricity consumption.
- Consistent Product Quality: The PLC system maintains stable evaporation parameters, preventing overheating or product degradation.
- Minimized Downtime: Robust construction and easy-to-clean design reduce maintenance stops.
- Compliance & Safety: All components meet international safety standards; the PLC includes emergency stop and over-temperature protection.
Company & Trustworthiness
Since its establishment in 2015, Qingdao Conqinphi Environmental Technology Group Co., Ltd. has grown into a trusted global supplier with an annual export value of US$10 million – US$50 million. Our products are shipped to North America, South America, Europe, Southeast Asia, Africa, Oceania, the Middle East, and domestic markets. We hold comprehensive certifications including ISO9001, ISO14000, OHSAS18001, HACCP, and others, reflecting our commitment to quality, environment, and occupational health. Our experienced R&D team continuously improves the evaporator design to meet evolving industry needs. We offer customizable solutions and provide online technical support for installation, commissioning, and troubleshooting. Choose Conqinphi for reliable, efficient, and cost-effective concentration equipment.
Frequently Asked Questions (FAQ)
-
Q: What is the maximum evaporation capacity you can offer?
A: The standard capacity range is up to 5,000 L/h, but we can customize larger systems upon request. -
Q: Can this evaporator handle viscous liquids like syrup or molasses?
A: Yes, the long tube vertical design is suitable for moderate to high viscosity liquids. For extremely viscous products, we may recommend additional modifications. -
Q: Is the PLC control system user-friendly?
A: Absolutely. It features an intuitive HMI touch screen with menu-driven parameters, automatic data logging, and remote monitoring capability. -
Q: What certifications does the company hold for this equipment?
A: Our company is certified under ISO9001, ISO14000, OHSAS18001, HACCP, and others. Specific product certifications can be provided upon request. -
Q: What is the typical lead time for delivery?
A: Lead time depends on configuration and order quantity, generally 30–45 working days. -
Q: Can you customize the evaporator for my specific process?
A: Yes, we offer tailored designs including different tube lengths, heating methods, and control features to match your requirements. -
Q: How do you ensure the quality of the equipment?
A: We conduct strict incoming material inspection, in-process quality checks, and final performance testing before shipment. -
Q: What after-sales support do you provide?
A: We provide installation manuals, remote technical assistance, spare parts supply, and optional on-site commissioning support.
