Hengshui Ruibin New Materials LLC, a dedicated manufacturer since 2019, offers high-quality Fiberglass Pultruded Planks and Profile Shapes designed for demanding industrial and construction applications. As a reliable supplier with an annual export value of US$2.5–5 Million and a team of 101–200 skilled professionals, we bring expertise and consistency to every batch. Our pultruded fiberglass products combine outstanding mechanical strength with excellent corrosion resistance, making them an ideal lightweight alternative to steel and wood in harsh environments. With customizable dimensions and multiple profile options, these planks and shapes meet diverse structural needs while ensuring long service life and minimal maintenance.
Product Overview: Fiberglass pultruded planks and profile shapes are manufactured through a continuous pultrusion process using high-quality E-glass fibers and thermosetting resins (polyester, vinyl ester, or epoxy). This results in a uniform, void-free composite with high strength-to-weight ratio and excellent dimensional stability. They are widely used in industrial flooring, walkways, platforms, handrails, cable trays, trench covers, and construction frames, especially where corrosion, moisture, or electrical conductivity is a concern.
| Property | Typical Value / Range |
| Density | 1.7–2.2 g/cm³ |
| Tensile Strength (longitudinal) | 200–350 MPa |
| Flexural Strength | 250–500 MPa |
| Fire Resistance (when specified) | Class A or B (optional) |
| Dielectric Strength | Excellent (non-conductive) |
| Operating Temperature | -40°C to +80°C (up to +120°C for special resins) |
Key Features and Benefits:
- Corrosion Resistance: Impervious to salts, acids, alkalis, and UV exposure – ideal for chemical plants, water treatment, and coastal constructions.
- Lightweight yet Strong: Reduced weight (approx. 1/4 of steel) lowers transportation and installation costs while maintaining high load-bearing capacity.
- Electrical Insulation: Non-conductive and non-magnetic, perfect for electrical substations and telecom structures.
- Low Maintenance: No need for painting, coating, or galvanizing; resistant to rot and insect damage.
- Customizable Shapes: We offer I-beams, channels, angles, flat sheets, square tubes, and specialty profiles to match your project requirements.
- Long Service Life: With proper resin selection, service life can exceed 20 years in aggressive environments.
Our manufacturing facility spans 1,000–3,000 square meters in Hengshui, Hebei, China, and we export to major markets across North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East. With port of shipment options from Tianjin or Qingdao, we ensure efficient logistics. Our products are manufactured under strict quality control (non-certified, but available upon request for specific standards). We welcome inquiries for custom sizes, colors, and fire-retardant or UV-stabilized grades. Choose Hengshui Ruibin New Materials LLC for durable, cost-effective fiberglass solutions that stand the test of time.
FAQ:
- Q: Are these planks suitable for outdoor use? A: Yes, they are UV-resistant and can be manufactured with a UV-stabilized surface layer. They perform well in direct sunlight without significant degradation.
- Q: Can I get custom lengths or profiles? A: Absolutely. We offer customized sizes and cross-sectional shapes. Please provide your drawings or specs for a tailored quotation.
- Q: What is the maximum load capacity? A: Load capacity depends on the profile, span, and resin system. We can provide engineering data and recommend the appropriate profile for your application.
- Q: How do I cut or drill these fiberglass planks? A: They can be cut with standard carbide-tipped saw blades, and drilled with HSS or carbide drills. Use proper dust collection and safety gear.
- Q: Do you have fire-retardant options? A: Yes, we can incorporate fire-retardant additives or use phenolic resin to achieve Class A or B fire ratings. Please specify your requirement.
- Q: What is the typical lead time for a standard order? A: For standard profiles and quantities, lead time is 15–25 days. Custom orders may take 25–35 days depending on complexity.
- Q: Are these products recyclable? A: Fiberglass composites are generally not biodegradable, but they can be ground and used as filler in some applications. We advise checking local recycling options.
- Q: What certifications do you have? A: While we do not hold formal third-party certifications by default, we can perform tests per ASTM or ISO standards upon request. Our quality system follows in-house procedures.
