Help CenterHot Dipped Galvanized Platform Grating Heavy Load Welded Steel Bar Grating for Industrial Walkway
Product Spotlights
Related Products
-
Custom Size Welded Platform Grating Metal Bar Grating for Chemical Factory Operation PlatformNegotiableMOQ: 300 Square Meters -
Heavy Duty Platform Grating Hot Dip Galvanized Steel Grating for Offshore Industrial PlatformNegotiableMOQ: 300 Square Meters
-
Welded Serrated Carbon Steel Grating – Hot DIP Galvanized for Walkway, Platform, Trench Drain and Gutter CoverNegotiableMOQ: 300 Square Meters
-
Anti-Slip Perforated Heavy Duty Stainless Steel Grating for Stairs and Platform Safety TreadsNegotiableMOQ: 300 Square Meters
-
Galvanized Steel Grating for Mezzanine Platforms and Stair Treads With High Load CapacityNegotiableMOQ: 300 Square Meters
Hengshui Ruibin New Materials LLC, a professional manufacturer established in 2019 with a 1,000-3,000 sqm factory and over 101-200 skilled employees, presents our Hot Dipped Galvanized Platform Grating Heavy Load Welded Steel Bar Grating. Designed for demanding industrial environments, this grating combines superior strength with long-lasting corrosion resistance, making it the ideal choice for heavy-duty walkways, platforms, and trench covers. Our grating is exported to markets across North America, South America, Europe, Asia, and Africa, with annual export value between US$2.5 million and US$5 million, reflecting the trust of global clients.
Key Features & Benefits
Superior Load-Bearing Capacity: Welded construction with heavy-duty bearing bars ensures the grating can withstand extreme weights, ideal for industrial walkways and platforms that support machinery, equipment, or high foot traffic.
Hot Dipped Galvanized Finish: Each grating is fully galvanized after welding, providing a uniform zinc coating that protects against rust and corrosion even in harsh outdoor or chemical-exposed environments.
Slip-Resistant Surface: Optional serrated (toothed) bearing bars or cross bars enhance anti-slip performance, ensuring worker safety on wet or oily surfaces.
Easy Installation & Low Maintenance: Lightweight yet strong design allows quick installation using standard clips, bolts, or welding. The galvanized coating requires minimal upkeep, reducing long-term costs.
Customizable Dimensions: Available in various panel sizes, bar spacings (e.g., 40mm, 50mm, 60mm), and bearing bar thicknesses (from 25x3mm to 75x6mm) to suit specific project requirements.
Versatile Applications: Suitable for industrial walkways, mezzanine floors, catwalks, drainage covers, trench grates, stair treads, and more.
Technical Specifications (Sample Data)
| Parameter | Typical Value | Custom Options |
|---|---|---|
| Bearing Bar Size | 50x5mm | 25x3mm ~ 75x6mm |
| Center-to-Center Spacing | 50mm | 40mm, 60mm, or custom |
| Cross Bar Spacing | 100mm | 50mm, 75mm, 100mm |
| Panel Width | 1,000mm | Up to 1,500mm |
| Panel Length | 6,000mm | Any length as per request |
| Zinc Coating Thickness | ≥85 μm | Can be adjusted |
Additional Details: Our welded steel bar grating is manufactured with high-quality carbon steel (Q235, SS400, etc.) and undergoes strict quality control during every cutting, welding, and galvanizing process. The hot-dip galvanizing process meets international standards (e.g., ASTM A123, but we can adapt to customer-specific norms upon request). The result is a robust, durable product that provides excellent structural support in factories, refineries, power plants, offshore platforms, and public infrastructure.
Why Choose Hengshui Ruibin New Materials LLC?
As a manufacturer with 101-200 experienced workers and a factory spanning 1,000-3,000 sqm, we have the capacity to handle both small and large orders efficiently.
Our annual export value of US$2.5–5 million demonstrates our strong presence in global markets, including North America, South America, Europe, Southeast Asia, Africa, and Oceania.
We ship from major ports like Tianjin and Qingdao, ensuring timely delivery worldwide.
We offer flexible customization: panel sizes, bar spacing, surface patterns (plain or serrated), and special cutouts (for pipes, bolts, etc.) are all available upon request.
Every batch is inspected to ensure consistent quality; we provide packing solutions such as bundles, pallets, or export-worthy crates to protect goods during transit.
Frequently Asked Questions (FAQ)
Q1: What is the typical load capacity of this heavy-load grating?
A: The load capacity depends on bearing bar size, span, and spacing. For example, a 50x5mm bar at 50mm spacing can safely support concentrated loads up to several tons per square meter. We can calculate specific load ratings for your application upon request.
Q2: Is the galvanized finish suitable for outdoor or corrosive environments?
A: Yes. Hot-dipped galvanizing provides excellent corrosion resistance in outdoor, humid, and mildly chemical-exposed areas. The zinc coating acts as a sacrificial barrier, extending service life significantly compared to painted grating.
Q3: Can I get custom panel sizes and shapes?
A: Absolutely. We can fabricate panels to your exact dimensions, including rectangular, square, or odd shapes with cutouts for pipes, columns, or offsets. Just provide a drawing or specifications.
Q4: How is the grating installed?
A: Typical installation methods include using G-clips, J-bolts, or welding directly to support structures. We can recommend the best fixing method for your project and provide mounting accessories if needed.
Q5: What are the available surface options for anti-slip?
A: We offer plain flat bars (standard) or serrated (toothed) bearing bars to improve slip resistance. Additionally, cross bars can be serrated. Choose based on your safety requirements.
Q6: Do you provide material certificates or test reports?
A: Yes, we can provide mill certificates for the steel and a galvanizing thickness report upon request. Our quality control process ensures compliance with relevant standards.
Q7: What is the lead time for an order?
A: For standard sizes in stock, lead time is 7–15 days. For custom orders, it typically ranges from 15–30 days depending on quantity and complexity. Contact us for a precise schedule.
Partner with Hengshui Ruibin New Materials LLC – With our dedicated team, advanced manufacturing capabilities, and proven track record in exporting to 20+ countries, we are your reliable source for high-quality hot-dipped galvanized steel grating. Whether you need standard panels or custom-engineered solutions, we are ready to support your project from design to delivery. Contact us today for a quote!
