Thin Section Slewing Bearing, 300mm OD, Lightweight, 4-point Contact, for Space-limited Applications
Product Spotlights
Ultra-compact 300mm OD thin section slewing bearing with 4-point contact design, combining lightweight construction (1.5–3 kg) and high load capacity for space-limited applications in robotics, medical, and aerospace. Customizable mounting holes, seals, and materials ensure a perfect fit for your project.
US$ 6000
≥1 Combo
Key Specifications
Get Latest Price
Type:
Other, Thin Section Slewing Bearing
Material:
Other, High-strength steel (customizable on request)
Outer Diameter (OD):
300 mm
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao|tianjin
Delivery Detail:
30 days
Related Products
-
Hydraulic Excavator Slewing Bearing, 45 Ton Class, Long Service Life, Direct ReplacementUS$ 6000MOQ: 1 Combo -
42CrMo4 Forged Steel Single Row Slewing Bearing, 800mm OD, 10 Ton Capacity, With Nylon CageUS$ 6000MOQ: 1 Combo
-
Double Row Ball Slewing Bearing, Internal Gear, Precision P5, 1200mm Pitch DiameterUS$ 6000MOQ: 1 Combo
-
Large Diameter Slewing Ring Bearing, 2000mm OD, 20 Ton Static Load, With Mounting HolesUS$ 6000MOQ: 1 Combo
-
Cross Roller Slewing Bearing, 600mm ID, Preload Adjusted, Low Friction TorqueUS$ 6000MOQ: 1 Combo
Type
Other, Thin Section Slewing Bearing
Material
Other, High-strength steel (customizable on request)
Outer Diameter (OD)
300 mm
Contact Type
4-point contact
Weight
Lightweight design (specific weight varies by model, please inquire)
Application
Space-limited applications (robotics, medical devices, aerospace, etc.)
Precision
Standard precision (higher precision available upon request)
Mounting Holes
Available (customizable pattern and size)
Sealing
Optional (contact or non-contact seals)
Henan San Kuang Machinery Technology Co., Ltd. proudly presents our Thin Section Slewing Bearing with a 300mm outer diameter, designed for applications where space is at a premium. As a dedicated manufacturer since 2022, we leverage our 10,000-30,000 m² factory and experienced team of 51-100 professionals to deliver lightweight, high-precision slewing bearings that excel in demanding environments. This compact 4-point contact bearing combines reduced weight with robust performance, making it the ideal solution for robotics, medical equipment, satellite systems, and other space-limited installations.
Key Features & Technical Specifications
- Ultra-Compact Profile: Thin cross-section design saves valuable axial and radial space, allowing integration into tight assemblies.
- Lightweight Construction: Engineered with optimized materials and geometry to minimize weight without sacrificing load capacity.
- 4-Point Contact Design: Handles combined axial, radial, and moment loads with a single bearing, simplifying system design.
- High Rotational Accuracy: Precision-ground raceways ensure smooth, low-friction rotation with minimal runout.
- Corrosion Resistance: Available with anti-corrosion coating or stainless steel options for harsh environments.
- Customizable Mounting Holes: Bolt patterns and hole sizes can be tailored to your specific interface requirements.
Technical Specifications (Typical for 300mm OD Model)
| Parameter | Value |
|---|---|
| Outer Diameter (OD) | 300 mm |
| Inner Diameter (ID) | Varies by model (customizable) |
| Section Height | Typically 15–30 mm (depends on design) |
| Contact Angle | 45° (4-point contact) |
| Dynamic Axial Load | ~15 kN (varies by cross-section) |
| Dynamic Radial Load | ~10 kN |
| Weight | Approx. 1.5–3 kg (lightweight design) |
| Operating Temperature | -30°C to +80°C (standard) |
Advantages for Space-Limited Applications
- Robotics & Automation: Ideal for joint actuation where every millimeter counts; reduces overall robot arm mass.
- Medical Devices: Used in CT scanners, surgical robots, and diagnostic equipment that demand precision and compactness.
- Aerospace & Defense: Suitable for satellite positioning systems, gimbals, and radar platforms requiring high reliability and low weight.
- Optical & Measurement Systems: Enables smooth rotation for laser trackers, telescopes, and camera mounts with minimal space consumption.
- Packaging & Printing Machinery: Fits into narrow frames while maintaining load capacity for indexing tables and rotary units.
Our thin section slewing bearings undergo rigorous quality control during manufacturing, including 100% dimensional inspection and rotation torque testing. We offer optional seals (contact or non-contact) to protect against dust and moisture, and we can supply grease-filled or oil-lubricated variants. Henan San Kuang also supports custom modifications such as special coatings, custom IDs, and non-standard bolt patterns to meet unique design constraints.
Why Choose Henan San Kuang Machinery Technology?
- Dedicated Manufacturing Facility: Our 10,000–30,000 m² factory in Luoyang, Henan is equipped with advanced CNC turning, grinding, and assembly lines.
- Experienced Team: With 51–100 skilled employees, we combine craftsmanship with modern technology to ensure consistent quality.
- Global Reach: Our annual export value of US$2.5–5 million reaches markets across North America, Europe, Asia, Africa, and Oceania, shipped from major ports including Shanghai, Qingdao, and Tianjin.
- Responsive Support: We provide fast technical quotations and engineering guidance, helping you select or customize the right bearing for your space-limited project.
Contact us today to request a quote or discuss your specific requirements. Our team is ready to deliver a lightweight, high-performance thin section slewing bearing that fits your application perfectly. With Henan San Kuang, you gain a reliable partner for precision rotation solutions.
Frequently Asked Questions (FAQ)
-
What is the typical load capacity of a 300mm OD thin section slewing bearing?
Dynamic axial load capacity typically ranges around 15 kN, and radial capacity around 10 kN, but exact values depend on the specific cross-section and material choice. Contact our engineers for a detailed calculation based on your load conditions. -
Can the mounting hole pattern be customized for my existing flange?
Yes, we can produce bearings with custom bolt circle diameters, hole sizes, and number of holes to match your interface. Provide a drawing or specifications for a no-obligation quotation. -
Are these bearings suitable for outdoor or washdown environments?
Standard bearings are made of steel; for outdoor or washdown applications, we recommend adding a protective coating (e.g., zinc or nickel plating) or ordering a stainless steel variant. Seals are also available upon request. -
What is the maximum operating speed for this bearing?
Thin section bearings are not typically designed for high speeds; maximum rotational speed depends on lubrication and load. For guidance, please provide your application RPM, and we will recommend a suitable design. -
Does the bearing come pre-lubricated?
Standard bearings are supplied with a lithium-based grease; alternative greases or oil lubrication can be specified. We also offer options for relubrication holes or grease nipples. -
How do you ensure the bearing's precision and quality?
Every bearing undergoes 100% inspection of dimensions, raceway hardness, and rotation torque. Our quality management system follows ISO 9001 principles (certification available upon request). -
What is the lead time for a standard 300mm OD thin section slewing bearing?
Lead time for standard models is typically 15–25 working days. For custom designs, please allow 25–40 days depending on complexity. -
Can I get a sample bearing for testing before placing a bulk order?
Yes, we accept sample orders. Minimum order quantity for samples may apply; contact our sales team for details.
