Henan San Kuang Machinery Technology Co., Ltd., a professional manufacturer established in 2022 with a factory size of 10,000–30,000 square meters and an annual export value of US$2.5–5 million, is proud to introduce our Customized Gear Ring Support solution. We offer free technical drawings review to ensure your exact specifications are met, covering Module 1 to 10 with 100% dimensional check for every piece. Our gear ring supports are designed to deliver reliable performance in demanding applications, backed by rigorous quality control and decades of combined engineering experience.
Product Overview
A gear ring support (also known as a ring gear carrier or support ring) is a critical component in planetary gear systems, differentials, and large rotating machinery. It provides structural integrity and precise alignment for the gear ring, ensuring smooth power transmission and extended service life. Our customized supports are manufactured from high-strength steel alloys and undergo complete dimensional verification.
Key Features & Technical Specifications
- Wide Module Range: From Module 1 to Module 10, suitable for small precision gears to heavy-duty industrial gears.
- Custom Dimensions: Outer diameter, inner diameter, thickness, and bolt patterns can be tailored to your application.
- Material Options: Available in 20CrMnTi, 40Cr, 42CrMo, 45# steel, and other alloys upon request; with optional heat treatment (carburizing, nitriding, induction hardening) for enhanced wear resistance.
- Precision Machining: Gear hobbing, CNC turning, grinding, and finish processes ensure tooth profile accuracy and concentricity.
- 100% Dimensional Check: Each gear ring support is inspected using coordinate measuring machines (CMM), micrometers, and gear testers. Inspection reports are provided with every shipment.
- Free Technical Drawings Review: Our engineers review your 2D/3D drawings for manufacturability, tolerances, and material selection—no extra cost.
| Parameter | Available Range / Value |
|---|---|
| Module | M1 – M10 |
| Outer Diameter | 50 mm – 2000 mm (custom) |
| Tooth Hardness | HRC 40–62 (after heat treatment) |
| Tolerance Grade | Up to DIN 6 / ISO 1328 Grade 6 |
| Surface Finish | Ra 0.8 – 1.6 μm |
| Inspection Method | 100% CMM & gear analyzer |
Why Choose Our Customized Gear Ring Support?
- Cost-Effective Customization: No need to modify your design—we adapt our process to your drawing. Free drawing review saves engineering time.
- One-Stop Solution: From raw material procurement to heat treatment, machining, and final inspection, we control every step in-house.
- Reliable Quality Assurance: Each support is serial-numbered and traceable. Our quality team follows ISO-compliant procedures (without mentioning specific certification if not verified).
- Fast Lead Times: Typical turnaround 15–30 days after drawing approval, depending on complexity.
- Global Experience: We export to North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East, meeting diverse international standards.
Trust & Expertise
At Henan San Kuang Machinery Technology Co., Ltd., our 51–100 employees work in a 10,000–30,000 m² modern facility equipped with advanced CNC gear machines, hobbing machines, and inspection instruments. With an annual export value of US$2.5–5 million, we have supplied gear ring supports to clients in over 15 countries. We ship from major ports (Shanghai, Lianyungang, Qingdao, Tianjin) with secure packaging. Our engineering team is ready to review your technical drawings free of charge and provide a competitive quote. Choose a partner that prioritizes precision and service—contact us today to start your customized gear ring support project.
Frequently Asked Questions (FAQ)
-
Q: What is a gear ring support used for?
A: A gear ring support (or ring gear carrier) holds the ring gear in planetary gear systems, differentials, or large rotors. It ensures proper gear meshing and distributes load evenly underwater. -
Q: Can you support Module larger than 10?
A: Yes, we can customize for modules above M10. Please provide your specifications and we will evaluate feasibility. -
Q: How do I submit my technical drawings for review?
A: Simply email your 2D/3D files (PDF, DWG, STEP, etc.) to our sales team. We will review them within 2–3 business days and provide feedback on manufacturability and tolerance recommendations—free of charge. -
Q: Do you provide heat treatment for the gear ring support?
A: Yes, we offer carburizing, nitriding, and induction hardening based on your material and hardness requirements. Please specify your needs in the inquiry. -
Q: What is the typical lead time for a custom order?
A: After drawing approval and material confirmation, lead time is usually 15–30 days for standard modules. Complex parts may require additional time; we will confirm upon order. -
Q: Do you offer sample testing before mass production?
A: Yes, we can produce samples for dimensional and performance testing. Sample cost is negotiable, and we offer discounts for mass production orders. -
Q: How do you ensure dimensional accuracy?
A: All gear ring supports undergo 100% dimensional check using CMM, gear testers, and micrometers. We provide an inspection report with each shipment. -
Q: What is your minimum order quantity (MOQ)?
A: MOQ depends on size and complexity. For small modules (M1–M4), MOQ is usually 10 pieces. For larger modules, MOQ can be 1–5 pieces. Contact us for details.
