XiAn Wisdom Computer Info&tech Co., Ltd proudly presents the Cost-Effective 6-Axis Industrial Welding Robot, a precision-engineered solution designed to transform small to medium production lines. With our company’s global reach—serving markets across North America, South America, Europe, Southeast Asia, Africa, and Oceania—and our commitment to quality backed by ISO9001, ISO9004, and ISO14000 certifications, this robot delivers reliable performance at an accessible price point. Since 2015, our 51–100 skilled employees have focused on bridging advanced automation with cost efficiency, making high-quality welding robots available for workshops and factories seeking to scale up without prohibitive investment.
The robot’s core advantage lies in its 6-axis kinematic structure, which provides exceptional dexterity and reach for complex welding paths. Whether you are working with steel, aluminum, or stainless steel, the robot ensures consistent weld quality with high repeatability (±0.05 mm) and smooth motion control. Designed specifically for small to medium production lines, it occupies a compact footprint yet offers a working radius of up to 1400 mm, allowing it to handle parts of various sizes. The integrated welding software simplifies programming through intuitive teach pendants or offline simulation, reducing setup time and enabling quick changeover between jobs.
Key Features & Technical Specifications
- 6-Axis Flexibility: Full articulated motion for complex weld seams and tight spaces.
- High Precision: Repeat positioning accuracy of ±0.05 mm ensures uniform bead appearance.
- User-Friendly Programming: Hand-held teach pendant with graphical interface; optional offline simulation software (RoboDK compatible).
- Durable Construction: Cast aluminum body with IP54 protection rating, suitable for industrial environments.
- Energy Efficiency: Servo motor system with regenerative braking reduces power consumption by up to 30% compared to older models.
- Compact Design: Base footprint of only 800×800 mm, ideal for space-constrained layouts.
- Versatile Welding Modes: Supports MIG/MAG, TIG, and spot welding with optional torch cleaning station.
- Safety Package: Collision detection, emergency stop, and light curtain interface (optional).
| Parameter | Value |
|---|---|
| Number of Axes | 6 |
| Maximum Load Capacity | 10 kg (optional up to 12 kg) |
| Working Radius | 1400 mm |
| Repeatability | ±0.05 mm |
| Protection Class | IP54 |
| Power Supply | 380V / 50Hz (3-phase) |
| Controller Type | Advanced DSP motion controller with Ethernet/IP connectivity |
| Welding Torch Interface | Standard Euro connector; air/water-cooled options |
Why This Robot Is Ideal for Small to Medium Production Lines
Small and medium enterprises often face the challenge of balancing automation costs with production flexibility. Our robot addresses this by offering a modular, scalable platform that can be deployed for a single welding cell or integrated into a multi-station line. The low initial investment (typically 30–50% less than comparable models from major brands) does not sacrifice quality—the robot is built with high-grade Japanese servo motors and harmonic drives from certified suppliers, ensuring a service life exceeding 80,000 hours under normal operation.
Operators can easily switch between different workpiece geometries using the quick-change tooling system (optional), and the robot’s built-in seam tracking sensor (available as an option) adjusts the welding path in real time to compensate for part tolerances. This reduces scrap rates and rework, directly improving overall equipment effectiveness (OEE). Additionally, the robot supports Industry 4.0 connectivity via standard protocols (Modbus TCP, Profinet), allowing you to monitor production data, schedule maintenance, and integrate with MES systems.
Our dedicated service team at XiAn Wisdom Computer Info&tech Co., Ltd provides comprehensive after-sales support: one-year warranty, remote diagnostics, and spare parts availability from our overseas office. We have a proven track record of delivering robots to customers in over 16 regions worldwide, from automotive subcontractors in Eastern Europe to metal furniture manufacturers in South America. With our factory’s ISO-certified quality management system, every robot undergoes rigorous testing before shipping from Shanghai port.
Take the Next Step in Automation – Contact us today for a personalized quotation or to schedule a live demonstration. Our engineers can help you calculate ROI based on your specific welding volume and part complexity. Join hundreds of satisfied clients who have boosted their production efficiency by 40–60% while reducing labor dependency.
Frequently Asked Questions (FAQ)
1. How difficult is it to program this robot for new welding jobs?
The robot comes with an intuitive teach pendant that uses a graphical icon-based interface. Most operators with basic welding knowledge can learn to program simple paths within two days. We also provide offline programming software (optional) for complex 3D models.
2. What is the maximum workpiece weight the robot can handle during welding?
The robot's wrist load capacity is up to 10 kg (including torch and sensor), but the arm can handle workpieces fixed on a positioner. For moving parts, we recommend using an external servo positioner (available as an option).
3. Can this robot weld aluminum or only steel?
Yes, with the appropriate MIG pulse welding source and wire feeder, the robot can weld aluminum alloys. We offer optional push-pull torch systems for aluminum applications to ensure stable wire feeding.
4. What is the typical lead time for this robot?
Standard configurations are usually shipped within 15–20 working days after order confirmation. Customized versions (e.g., with special torch or sensor) may take 25–30 working days. We ship from Shanghai port via FOB or CIF terms.
5. How much floor space is required for installation?
The robot base requires approximately 0.64 m² (800×800 mm). The controller cabinet is separate (400×400×800 mm) and can be placed up to 10 m away. We recommend a total cell area of at least 4 m² for a single robot with a welding table.
6. What warranty and after-sales service do you provide?
We provide a one-year full warranty covering parts and labor. Remote technical support is available via phone or video call. Our overseas office can dispatch on-site engineers within 48 hours for critical issues (travel expenses may apply).
7. Is the robot compatible with existing welding power sources?
Yes, it accepts standard analog (0–10V) or digital interface (e.g., Ethernet/IP) from most major welding power source brands like Fronius, Lincoln, Miller, and Panasonic. Please confirm the interface type when ordering.
8. Can I integrate this robot into an existing production line with conveyors?
Absolutely. The controller has multiple digital I/O and fieldbus options (EtherCAT, Profibus, Devicenet) to synchronize with conveyors, turntables, and other automation equipment. Our engineers can assist with the integration design.
