Industry Pain Points and Solutions
The popularization of small household swimming pools has long been troubled by pain points such as low equipment integration, high operating noise, and high energy consumption. Traditional swimming pools require separate purchases of multiple sets of equipment such as circulation pumps, sand filters, disinfectors, and heating devices. Not only do they take up space, but the pipeline connections between the devices are also complex, resulting in high installation and maintenance costs. At the same time, traditional swimming pool pumps often generate noise above 60dB during operation, seriously affecting the quietness and comfort of the home living environment. And the system lacking energy-saving design has high monthly electricity bills, which has become the main reason for household users to abandon installing swimming pools.
Beijing Yongao Sports Technology Co., Ltd. has been deeply involved in the fields of water treatment, energy conservation, and environmental protection for many years. Relying on rich experience in technology development and technology transfer, it has developed this set of one-stop full-set swimming pool equipment for household scenarios. This product highly integrates all core functional modules into a compact cabinet. It uses a silent and energy-saving circulation water pump and variable frequency control technology to fundamentally solve the problems of noise and energy consumption. Through pre-installed interfaces and modular design, users can achieve a full set of functions such as filtration, circulation, disinfection, and constant temperature with just one purchase. The installation time is shortened by 70%, truly achieving "ready-to-use, quiet, and power-saving".
- Integrated design: It integrates circulation filtration, ultraviolet disinfection, auxiliary chlorine tablet disinfection, and automatic backwashing, eliminating the need to purchase additional equipment.
- Ultra-silent operation: It uses a fully enclosed shielded motor and flow channel optimization technology. The whole machine noise is ≤45dB(A), equivalent to the environment in a library, ensuring that it does not disturb others even when operating at night.
- High efficiency and energy saving: It is equipped with an intelligent variable frequency pump that can automatically adjust the power according to water resistance. The comprehensive energy consumption is 30%~45% lower than that of similar products.
- Compact size: It only occupies an area of 0.6m² (height: 1.2m × width: 0.6m × depth: 0.8m) and can be flexibly installed in outdoor or indoor corners.
| Parameter items | Technical specifications |
| Applicable swimming pool water volume | ≤40m³ (Typical household swimming pool) |
| Circulating flow | 8m³/h |
| Rated power | 0.75kW (Variable frequency adjustable) |
| Noise level | ≤45dB(A) (At a distance of 1m) |
| Filtration accuracy | 10μm (Multi - layer composite filter element) |
| Disinfection method | Ultraviolet + Slow - release chlorine tablets (Double) |
| Backwashing method | Automatic timing / Differential pressure trigger |
| Power supply requirements | 220V/50Hz, Single - phase |
| Protection level | IP54 (Splash - proof) |
Detailed explanation of working mechanism and advantages
Inside the equipment, the pool water is pumped in by a low - head and high - efficiency circulating pump, and then passes through a hair collector and a multi - layer composite filter element (non - woven fabric + activated carbon + diatomite composite layer) for physical filtration to remove impurities such as suspended solids and algae. Then the water flows through the ultraviolet disinfection chamber, where the 253.7nm wavelength ultraviolet rays are used to destroy the DNA of microorganisms. At the same time, slow - release chlorine tablets are used to supplement the residual chlorine to achieve continuous antibacterial effect. The filtered clean water is adjusted by the intelligent constant - temperature module (heating components can be optionally configured) and then returned to the pool. The variable frequency controller adjusts the pump speed in real - time according to the actual water resistance to ensure the best energy - saving point.
Compared with traditional split - type equipment, this system does not require additional installation of a control box and pipeline tee. All electrical and fluid connections use quick - plug connectors, and users can complete the installation by themselves. The built - in intelligent backwashing function is automatically activated after detecting that the differential pressure of the filter element is too high or the equipment has run for 72 hours. It uses clean water to flush the filter element in the reverse direction, extending the service life of the filter element to 6 - 12 months. The silent design is due to the fully enclosed perfusion of the motor stator, the optimization of the impeller dynamic balance, and the wrapping of the shell with sound - insulating cotton. The measured noise at a distance of 1 meter from the equipment is only 42 - 45dB, which is far lower than the 60dB requirement for water pump products in the national "Noise limits for household and similar electrical appliances".
Trust Endorsement and Company Advantages
Since its establishment, Beijing Yongao Sports Technology Co., Ltd. has always been dedicated to technology development and services in the fields of water treatment, energy conservation, and environmental protection. The company has over 10 years of industry experience and has cumulatively provided equipment and technical support for more than 500 household swimming pool projects across the country. All the products sold have passed strict internal quality control tests, including a 48 - hour continuous operation aging test, a pressure test (1.5 times the working pressure), and a salt - fog corrosion test. In terms of energy conservation, the equipment has passed the energy - efficiency test by a nationally recognized third - party laboratory. The actual operation data shows that under the same filtration conditions, this system saves about 35% of the electricity cost compared with the traditional single - speed pump combination.
We not only offer standard products but also provide non - standard customization according to the specific dimensions of the customer's swimming pool (such as irregular shapes and special water levels). We also provide installation guidance, remote debugging, and one - year free warranty for the whole machine. If you are worried about the selection, noise, or operating cost of your household swimming pool, welcome to contact us for a technical selection solution. Our engineers will recommend the most suitable configuration based on your swimming pool's volume, usage frequency, and water source conditions and provide a detailed power consumption calculation. Choosing Yongao means choosing professionalism and peace of mind.
