Industry Pain Points and Solutions
Traditional swimming pool water treatment systems often suffer from pain points such as separate procurement of equipment, complex pipeline connections, long installation cycles, and poor compatibility of accessories. Especially for demountable swimming pools (such as steel structure swimming pools and frame swimming pools), their temporary and rapid - assembly characteristics pose higher requirements for equipment. Many users experience low filtration efficiency, frequent water leakage, or high long - term maintenance costs due to improper equipment selection. Beijing Yongao Sports Technology Co., Ltd., relying on years of technological accumulation in energy conservation and environmental protection, has conducted in - depth research on the usage scenarios of demountable swimming pools and launched the "One - Stop Complete Set of Swimming Pool Equipment". It integrates core components such as filtration sand tanks, circulating pumps, disinfection systems, pipes, and quick connectors into a standardized kit, solving the industry's chronic problems of difficult accessory matching and long installation time from the root. Through modular design and glue - free quick - installation technology, the equipment installation time is reduced by more than 60%, while ensuring the long - term stable operation of the system and truly achieving the convenient experience of "plug - and - play".
Working Mechanism and Technical Specifications
This set of equipment follows the classic water circulation treatment process: Pool water enters the hair collector through the overflow/return port via the pipeline, then is pumped into the quartz sand filtration sand tank under pressure, and the filtered clean water is sterilized by the disinfection device (optional: ultraviolet, chlorine generator, or ozone) before returning to the pool through the water distribution port. The entire system is provided by the same supplier, and the pipeline interfaces use internationally standard clamp - type quick connectors, which can be connected without tools.
Core components include:
- Top - Outlet Multi - Way Valve Filtration Sand Tank: With a pressure resistance of 0.4MPa, the tank body adopts the reinforced glass fiber winding process, and is filled with quartz sand filter media (particle size 0.5~1.0mm), with a filtration accuracy of up to 10~15μm.
- Self - Priming Circulating Pump: Equipped with a high - efficiency motor, the flow - through parts are made of engineering plastics, and the impeller adopts a hydraulic balance design. Under normal operating conditions, the noise is lower than 60dB (A).
- UV - Ozone Combined Disinfector: The lifespan of the ultraviolet lamp tube is ≥8000 hours, and the ozone generation amount is adjustable, ensuring that the water quality meets the GB 9667 - 1996 standard.
- Complete Set of Quick - Installation Pipeline Accessories: Including expansion joints, elbows, straight - throughs, reducers, tees, etc., all made of UPVC material, and the sealing rings are made of EPDM, resistant to acid and alkali corrosion.
The following is a typical configuration parameter table:
| Project | Specification Value |
| Applicable pool water volume | 30m³ ~ 150m³ |
| Diameter of filter sand tank | 400mm / 500mm / 600mm |
| Circulating pump flow rate | 15m³/h ~ 40m³/h |
| Pump head | 8m ~ 15m |
| UV lamp power | 55W / 110W |
| Power supply requirements | 220V/50Hz or 380V/50Hz (optional) |
| Connection pipe diameter | DN50 / DN63 / DN75 |
| Quick-connect fitting standard | ISO 228 / Clamp type |
Core Advantages of the Product
- One-stop delivery: All products from filtration, circulation, disinfection to pipeline accessories are uniformly produced and quality - controlled by Beijing Yongao Sports Technology Co., Ltd., avoiding the compatibility risks caused by multi - supplier procurement.
- Quick installation: All connections use glue - free quick - connect fittings. With the preset expansion compensation design, ordinary workers can complete the installation of the whole system within 4 hours without special tools.
- Modular expandability: The filtration units can be flexibly increased or decreased according to the size of the pool. It supports parallel combination to meet the water volume requirements from 50m³ to 300m³.
- Energy - saving and low - noise: The water pump adopts a variable - frequency optional configuration. It automatically reduces the speed under low load, saving more than 25% energy compared with traditional fixed - frequency pumps. The noise of the whole machine meets the sound environment requirements of sports venues.
- Durable protection:The service life of UPVC pipelines and EPDM sealing rings in a chlorine/ozone environment exceeds 5 years. The sand filter tank has passed the pressure test at 1.5 times the rated pressure.
Taking the disassembly and assembly swimming pool project of a certain university sports center as an example, the equipment installation team only took 3.5 hours to complete the docking of all pipelines. After commissioning, the circulation flow reached 102% of the design value, and the effluent turbidity was stably below 0.3NTU, which was highly recognized by the customer's technical acceptance team.
Company Strength and Trust Endorsement
Beijing Yongao Sports Technology Co., Ltd. has long been focusing on the fields of water treatment equipment and energy - saving and environmental protection technologies, and has complete qualifications such as technology development, technology transfer, and technical services. The company's products have been widely used in the renovation projects of disassembly and assembly swimming pools in many primary and secondary schools in Haidian District, Beijing, the temporary swimming pool in the Chaoyang District Sports Center, and sports venue projects in multiple provinces and cities. Each set of equipment undergoes a 48 - hour full - load water circulation test before leaving the factory to ensure no leakage and no abnormal vibration. We have an independent pre - sales technical consulting team, which can provide customized configuration solutions according to the actual size (length × width × depth) of your swimming pool, usage frequency, water quality requirements and other working conditions. And we provide on - site installation guidance services nationwide (appointment in advance is required).
Professional Consultation and Suggestions
We understand that the operators of disassembly and assembly swimming pools are extremely sensitive to the construction period and cost. Therefore, before purchasing equipment, it is recommended that you first provide information such as the swimming pool volume, the estimated number of daily users, and the on - site power supply conditions. Our engineers will issue a calculation sheet for equipment and pipeline selection for free to avoid frequent replacement of accessories in the later stage. If you need to further understand product details or obtain typical project cases, please contact our technical service department through the official website or phone. We will answer your questions with a professional and objective attitude.
-
Q: Is this set of equipment suitable for all types of disassembly and assembly swimming pools?
A: This kit is suitable for standard disassembly and assembly steel - structure swimming pools, aluminum - alloy frame swimming pools, and inflatable swimming pools (the water inlet and outlet interfaces need to be confirmed). The product is equipped with telescopic joints of various specifications, which can compensate for an installation error of ±5mm. However, extremely irregularly shaped swimming pools need to be evaluated separately. -
Q: Is a professional plumber required for installation?
A: No. The quick - connect joints use screw - on clamps and do not require hot - melting or glue. With the attached illustrated installation manual and video guidance, generally 2 workers can complete the installation by referring to the instructions. Our company also provides paid on - site supervision services. -
Q: How often does the filter sand tank need to be cleaned?
Answer: According to the water quality, generally perform backwashing through the multi-way valve every 7 - 15 days (the operation is simple, just rotate the handle). It is recommended to replace the quartz sand in the sand filter every 2 - 3 years. -
Question: Does the disinfection device produce any odor?
Answer: The standard UV - ozone combined disinfection device has an adjustable ozone output. The factory setting is within the safe concentration range (≤0.05ppm), which is harmless to the human body and will not produce a chlorine smell. If you are sensitive to odors, you can choose the pure ultraviolet solution. -
Question: Can the equipment be used outdoors in cold regions?
Answer: The working environment temperature of the equipment is 0 - 40℃. When the equipment is not in operation in winter, the water in the pipes and the sand filter should be drained to prevent freezing and cracking. You can purchase our matching anti - freezing package or outdoor insulation cover. -
Question: What is the warranty period of the equipment?
Answer: The standard warranty period for the whole machine is 12 months (starting from the delivery date). The vulnerable parts such as the water pump motor and UV lamp tube have a 6 - month warranty. If you purchase the extended warranty service, it can be extended to 24 months. -
Question: If expansion is needed in the future, can this set of equipment be expanded?
Answer: Yes. Our multi - way integrated design supports parallel installation of filtration units. You can easily improve the processing capacity by simply adding the corresponding number of sand filters, water pumps and pipe tees without discarding the original equipment. -
Question: Are the accessories universal? Is it convenient for subsequent procurement?
Answer: The quick - connect fittings adopt the standard ISO interface, and common accessories in the market can be matched. At the same time, we always keep a stock of common pipe fittings and will ship them within 48 hours after receiving the order.
