Help CenterComplete One-stop Swimming Pool Equipment Including Hair Strainer and Circulation Pump
Related Products
-
One-stop Complete Set of Swimming Pool Equipment, Automatic Dosing, Constant Temperature Control, in StockNegotiableMOQ: 0 -
Swimming Pool Purification Equipment, Full Set and One-stop Service, Including Filter Sand Tank and Automatic Dosing MachineNegotiableMOQ: 0
-
One-stop Swimming Pool Equipment, Integrated Water Treatment System, Easy to InstallNegotiableMOQ: 0
-
Swimming Pool Water Circulation Equipment, Full Set One-stop Solution, Including Disinfection Salt Chlorine SystemNegotiableMOQ: 0
-
Swimming Pool Water Treatment Equipment, Medium-pressure Ultraviolet Disinfection System, Specially Designed for Hotel Swimming PoolsNegotiableMOQ: 0
Industry Pain Points and Solutions
Traditional swimming pool water treatment systems have long suffered from pain points such as decentralized equipment procurement, mismatched equipment selection, cumbersome installation, and high maintenance costs. In particular, debris such as hair and fibers can easily enter the circulating water pump, causing impeller entanglement, wear of seals, and even motor burnout, directly affecting the water quality and operational stability of the pool. Beijing Yongao Sports Technology Co., Ltd., with more than a decade of experience in swimming pool equipment R & D, has launched a complete set of one - stop swimming pool equipment (including hair filters and circulating water pumps), which completely solves the above problems with an integrated design. By pre - matching and assembling the hair filter with the circulating water pump, and using anti - corrosion materials and high - efficiency energy - saving motors, it effectively reduces the installation complexity, improves the operational reliability, and at the same time reduces energy consumption and maintenance frequency, helping customers achieve cost reduction and efficiency improvement.
Working Principle and Product Features
This system is designed according to the standard swimming pool water circulation process: The backflow water from the pool enters the hair filter through pipelines. The built - in precision stainless - steel or engineering plastic filter basket can efficiently intercept impurities such as hair, leaves, and fibers with a diameter of more than 2mm. The filtered clean water enters the circulating water pump. The pump pressurizes the water and delivers it to the subsequent filter sand tank or disinfection equipment. After purification, the water returns to the pool.
Core Product Features:
- Integrated Design: The hair filter and the pump are directly connected with a special bracket. The water pressure test is completed before leaving the factory. On - site installation only requires connecting the inlet and outlet pipes, greatly shortening the installation time.
- High - Efficiency Filtration: The filter basket is made of corrosion - resistant and high - strength materials. It can be taken out for cleaning by simply opening the lid without disassembling the pipes, making maintenance convenient.
- Energy - Saving Motor: It uses an IE3 or higher - efficiency motor, reducing energy consumption by 10% - 15% compared with traditional products. The water pump impeller is hydraulically optimized, with high efficiency and low noise.
- Corrosion - Resistant Materials: The filter shell and the pump's flow - through components are all made of UPVC or enhanced polypropylene, which can withstand long - term immersion in chlorinated pool water and avoid rusting.
- Overload Protection: It is standardly equipped with a thermal overload relay and a water - shortage protection function. When the pump runs dry without water or the current is abnormal, it will automatically shut down to ensure the safety of the equipment.
Technical Specifications and Parameters
The following are the typical configuration parameters. The specific values can be customized according to the pool volume and circulation period:
| Parameter Item | Typical Value |
| Model | YW-30 (Example) |
| Maximum Flow Rate | 30 m³/h |
| Rated Head | 15 m |
| Motor Power | 2.2 kW (380V/50Hz) |
| Inlet and Outlet Diameter | DN80 |
| Filter Volume | 3 L (Effective Volume of Filter Basket) |
| Filtration Precision | ≤2 mm |
| Shell Material | UPVC |
| Operating Temperature | 5~40℃ |
The above parameters are for regular configurations. When selecting the actual model, it is necessary to comprehensively consider the pool area, pipeline length, and local climate conditions. Beijing Yongao Sports Technology Co., Ltd. provides free model selection and calculation services.
Trust Endorsement and Company Advantages
As a professional water treatment equipment supplier, Beijing Yongao Sports Technology Co., Ltd. has provided pool equipment and technical services for hundreds of domestic hotels, stadiums, community clubs, and schools in total. The company's technical team has many years of industry experience and can provide full - process support from equipment selection, installation guidance to after - sales maintenance. Taking this project as an example, the integrated design can reduce the on - site installation man - hours by about 30% and effectively avoid faults such as cavitation and overload caused by equipment mismatch. We always pay attention to the durability and economy of products. All equipment is subject to strict quality inspection before leaving the factory and comes with a clear warranty commitment (one - year warranty for the whole machine and two - year warranty for the motor).
Consultation Advice
If you are planning to build or renovate a pool water system, it is recommended to first clarify the pool volume, usage frequency, and local water quality characteristics. Our technical staff can quickly provide accurate equipment configuration plans and quotations based on this information. Welcome to contact the Beijing Yongao team through the official website or phone to obtain customized product information and application cases. Choose one - stop equipment and let professionals do professional things to help you save time and reduce comprehensive costs.
- Does this set of equipment include a sand filter tank? This set of products only includes a hair strainer and a circulation pump, and does not include a sand filter tank. However, we can provide a matching sand tank or filtration system to form a complete water treatment solution.
- How to determine if the pump flow is appropriate? Generally, it is calculated based on completely circulating the pool water once every 6 - 8 hours. For example, for a 50m³ pool, a flow rate of about 8.3m³/h is required for a 6 - hour circulation. Considering the pipeline resistance, it is recommended to choose a pump with a flow rate of 10 - 12m³/h and a head of about 15m. Beijing Yongao Sports Technology Co., Ltd. can provide free model - selection services.
- How often should the hair strainer be cleaned? Depending on the frequency of use and water quality, it is recommended to clean it 1 - 2 times a week. When cleaning, unscrew the upper cover, take out the filter basket, and rinse it with clean water. The operation is simple.
- Is the equipment material corrosion - resistant? The main components are made of UPVC or reinforced engineering plastics, which have good corrosion resistance to chlorinated disinfected water and acid - base chemicals, do not rust, and are suitable for the pool environment.
- What should be noted during installation? The pump should be installed in a well - ventilated and dry place. A bottom valve or check valve must be installed on the intake pipe to prevent air from entering. The filter is recommended to be installed horizontally, and sufficient maintenance space should be reserved. We provide installation diagrams and video instructions.
- Is the noise of the circulation pump loud? With a closed silent motor and an optimized impeller design, the operating noise is controlled below 55 decibels, which will not cause interference to the surrounding environment.
- What is the warranty period? How to handle failures? The whole machine is under warranty for 1 year, and the motor is under warranty for 2 years. During the warranty period, non - human - made damages will be repaired or replaced for free; parts supply and technical support are provided for life.
- Can it be used for seawater pools? The standard material of this set of equipment is UPVC, which is suitable for freshwater pools. If it is to be used in seawater or high - salinity water bodies, a customized version made of stainless steel or special plastics needs to be selected. Please specify in advance.
