Industry Pain Points and Solutions: In pool operation, turbid water quality, algae growth, and excessive bacteria are the core problems that have long troubled managers. Traditional water treatment equipment often has problems such as insufficient filtration accuracy, serious disinfection residues, high energy consumption, and complex maintenance, resulting in a low water quality compliance rate and high operating costs. Beijing Yongao Sports Technology Co., Ltd. has been deeply involved in the water treatment field for many years. Relying on technology development and energy - saving and environmental - protection technology accumulation, it has launched an integrated solution for swimming pool water treatment equipment · circulating filtration system · swimming pool disinfection equipment · swimming pool equipment accessories to address the above - mentioned pain points. By optimizing the combination of filter media, introducing high - efficiency disinfection modules, and integrating intelligent circulation control, the company achieves stable purification of the whole process from water intake to water output, and can meet the requirements of the "Swimming Pool Water Quality Standard" CJ/T 244 - 2016 without adding a large amount of additional chemical agents. This solution not only effectively reduces energy consumption by more than 30%, but also significantly reduces the frequency of manual intervention, making pool management easier and more economical.
Working Mechanism and Technical Features: This system consists of circulating filtration unit, disinfection unit, circulation power unit and intelligent control unit. Its working principle is as follows: The pool water enters the circulation pump through the return water pipe. After being pressurized, it is sent to the filter sand tank. The quartz sand or diatomaceous earth medium intercepts suspended solids and colloidal particles. The filtered water flows through the disinfection unit (ultraviolet/ozone/automatic chlorine dosing) to inactivate bacteria, viruses and algae. Finally, it returns to the pool through the water outlet, forming a continuous cycle. The core features include:
- High - efficiency Filtration: Adopting multi - media layered filling technology, the filtration accuracy can reach 5 - 10μm, effectively removing impurities such as hair, dust and grease.
- Multiple Disinfection: Optional ultraviolet, ozone, and sodium hypochlorite dosing systems can be combined as needed to avoid by - products generated by single disinfection.
- Intelligent Control: Standard - equipped with a PLC or microcomputer controller, it supports timed circulation, backwashing, and automatic adjustment of disinfection dosage, achieving unmanned operation.
- Energy Saving: Using high - efficiency and energy - saving water pumps and cooperating with frequency conversion technology, it automatically adjusts the flow according to the actual load, saving up to 40% of electricity costs.
- Modular Design: Each unit is independently integrated and can be flexibly selected according to the pool volume and water quality conditions, supporting expansion and upgrading.
| Parameter Name | Specification Range |
| Diameter of Filter Sand Tank | 400 - 1800mm |
| Weight of Filter Medium | 50 - 1500kg |
| Flow Rate of Circulation Pump | 10 - 200m³/h |
| Power of Disinfection Unit | 40 - 800W |
| Working Pressure | ≤2.5kg/cm² |
| Applicable Pool Volume | 50 - 2000m³ |
| Power Supply Requirement | AC 380V/50Hz |
Product Advantages and Trust Endorsement: Since its establishment, Beijing Yongao Sports Technology Co., Ltd. has always been focused on the R & D and sales of water treatment equipment. It has served more than 200 swimming pool projects in total, covering schools, hotels, stadiums and private villas. The company has a professional technical service team that can provide full - cycle support from equipment selection, installation guidance to after - sales maintenance. All equipment uses high - quality raw materials, and key components have passed international certifications such as CE and ISO (Note: The certification information shall be subject to the actual product, and this is a general industry expression). The company adheres to the concept of "energy - saving and environmental protection, technology first" and continuously optimizes product performance to help customers reduce operating costs. If you are planning a swimming pool water treatment system, we recommend that you comprehensively consider the pool volume, usage frequency, water quality requirements and budget to select the most suitable configuration plan. Our technical consultants can provide free plan design and quotation. Welcome to call or consult online. We will serve you whole - heartedly.
FAQ (Frequently Asked Questions)
-
Q: How often does the filtration system need to be backwashed?
A: The backwashing frequency depends on the water quality and usage load. It is generally recommended to perform backwashing every 3 - 7 days or when the pressure gauge reading rises by 0.5 - 1kg/cm². The system supports manual and automatic backwashing. The automatic mode can be set to trigger by time or pressure difference, reducing manual operation. -
Q: Which is better, ultraviolet disinfection or chlorine dosing disinfection?
A: Ultraviolet disinfection has no chemical residues and is highly effective against bacteria and viruses, but it has no continuous disinfection ability; Chlorine dosing disinfection can maintain residual chlorine, but it may produce by-products. It is usually recommended to combine the two, with ultraviolet as the main disinfection method and low-dose chlorine dosing to maintain residual chlorine, taking into account both safety and health. -
Q: How to select the circulating water pump?
A: The flow rate of the water pump needs to be determined according to the pool volume and the number of circulation times. The standard swimming pool requires one circulation every 6 - 8 hours. For example, for a 500m³ swimming pool, the circulation flow rate needs to be about 62 - 83m³/h. At the same time, the head and pipeline resistance need to be considered. It is recommended to be calculated by a professional engineer. -
Q: What infrastructure is needed for equipment installation?
A: It is necessary to reserve an equipment room or machine room, lay the inlet and return water pipelines, and configure the power supply and grounding protection. The equipment foundation needs to be flat and have sufficient bearing capacity. At the same time, drainage and ventilation need to be considered. Beijing Yongao Sports Technology Co., Ltd. can provide installation drawings and on-site guidance. -
Q: How often should the quartz sand filter medium be replaced?
A: The normal service life of quartz sand is about 3 - 5 years. It needs to be replaced when it becomes hardened, broken, or the filtration effect significantly declines. Regular backwashing and chemical cleaning can extend the service life. -
Q: Can the system be used for seawater swimming pools?
A: Seawater swimming pools need to use corrosion-resistant materials (such as stainless steel 316L and fiberglass), and the disinfection unit needs to adapt to the high-salt environment. Beijing Yongao Sports Technology Co., Ltd. can provide special models for seawater. Please contact the sales department for confirmation. -
Q: How reliable is the automatic control system?
A: The control system uses industrial-grade PLC or microcomputer, and has overload protection and fault alarm functions. Key components are selected from brands such as Schneider and Siemens, which have been verified by the long-term market and are stable and reliable. -
Q: What are the equipment warranty period and after-sales service?
A: The standard warranty period is 1 year, and it can be extended. Free repair or replacement is provided within the warranty period, and technical support is provided for life. On-site service can be arranged nationwide, and the response time does not exceed 48 hours.
