Help CenterHigh Energy Efficiency Plate Heat Exchanger, Semi-Auto Cleaning Design, 220V Circulation Pump Included
Product Spotlights
Related Products
-
Stainless Steel Heater/Water Heat Exchanger/Plate Type Heat Exchanger ManufacturerNegotiableMOQ: 1 Combo -
Water-Water / Steam-Water Plate / All-Welded / Flue Gas Heat ExchangerNegotiableMOQ: 1 Combo
-
High Pressure Steam-Water Water-Water Plate Heat ExchangerNegotiableMOQ: 1 Combo
-
Pharmaceuticals/Pesticides/Fine Chemicals Wastewater Plate Heat ExchangerNegotiableMOQ: 1 Combo
-
High Pressure Steam-Water Water-Water Plate Heat ExchangerUS$ 100 - 800MOQ: 1 Combo
Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. – a trusted manufacturer with over 9 years of experience in heat exchange solutions. Our High Energy Efficiency Plate Heat Exchanger with Semi-Auto Cleaning Design and 220V Circulation Pump is engineered to deliver outstanding thermal performance while significantly reducing maintenance downtime. Whether you need to heat, cool, or recover energy in industrial processes, this plate heat exchanger offers a compact footprint, easy operation, and long-term reliability. Backed by our ISO9001-certified production facility and a team of 200+ skilled professionals, we ensure every unit meets the highest standards of quality and efficiency.
Key Features & Technical Specifications
- High Energy Efficiency: Patented plate corrugation design maximizes heat transfer coefficient, achieving up to 95% thermal recovery in suitable applications.
- Semi-Auto Cleaning Design: Integrated cleaning ports and a backflush mechanism allow partial disassembly for quick maintenance without full shutdown – ideal for food, dairy, and chemical processes where hygiene is critical.
- Complete Circulation System: Comes with a 220V circulation pump (power rating customizable from 0.75kW to 2.2kW) to ensure stable flow rates and optimal pressure drop.
- Durable Construction: AISI 304 or 316L stainless steel plates and frame, with EPDM or Viton gaskets for temperatures up to 180°C.
- Compact & Modular: The plate pack can be easily expanded or reconfigured to adjust heat transfer capacity, providing flexibility for evolving process requirements.
- User-Friendly Control: Optional PLC integration for automated temperature and flow monitoring.
Typical Technical Parameters (Example Configuration)
| Parameter | Value |
| Heat Transfer Area | 50 m² (customizable) |
| Design Pressure | 1.0 MPa / 10 bar |
| Max. Operating Temperature | 180°C |
| Flow Rate (Primary/Secondary) | Up to 100 m³/h |
| Voltage / Frequency | 220V / 50Hz (other options available) |
| Pump Power | 1.1 kW (standard) |
| Connection Size | DN80 (flanged) |
Customer Benefits
- Reduced Operating Costs: Higher heat recovery directly lowers energy consumption – many clients report 20–30% savings compared to traditional shell-and-tube exchangers.
- Minimized Downtime: The semi-auto cleaning design allows cleaning in place (CIP) or quick manual access, cutting maintenance hours by up to 50%.
- Versatile Application: Suitable for liquid-to-liquid and liquid-to-vapor duties in industries such as food & beverage, pharmaceutical, chemical, HVAC, and renewable energy.
- Easy Installation: Compact footprint with pre-assembled pump and piping – just connect utilities and start operation.
Why Choose Qingdao Conqinphi?
Our company, founded in 2015, operates a modern factory spanning over 10,000 square meters with a dedicated R&D team and full quality control system. We have shipped products to over 30 countries across North America, Europe, Southeast Asia, and Africa, with an annual export value exceeding US$10 million. Our certifications including ISO9001, ISO14000, HACCP, and OHSAS18001 reflect our commitment to quality and safety. Every plate heat exchanger undergoes rigorous pressure testing and performance verification before shipment. We provide 12-month warranty and lifelong technical support. Contact us today for a customized solution that meets your exact process parameters!
Frequently Asked Questions
Q1: What type of fluids can this heat exchanger handle?
A: It is compatible with most clean liquids, including water, oil, glycol, acidic or alkaline solutions (within material limits), and food-grade fluids. For abrasive or heavy-fouling media, consult our engineers for special plate coatings or gasket materials.
Q2: How does the semi-auto cleaning design work?
A: The unit is equipped with dedicated cleaning ports and a bypass line. By closing inlet/outlet valves and connecting a CIP (Clean-in-Place) system, you can circulate cleaning solution through the channel without removing the plates. Alternatively, partial disassembly of the tie bolts allows manual access to selected plates for spot cleaning.
Q3: Can I customize the heat transfer area or number of plates?
A: Absolutely. Our plate heat exchangers are modularly designed. The plate count can be increased or reduced to match your required duty. We also offer different plate corrugation patterns (herringbone, chevron) for optimized performance.
Q4: What is the maximum operating pressure?
A: The standard design pressure is 1.0 MPa (10 bar). For higher pressure applications (up to 2.5 MPa), heavy-duty frames and reinforced gaskets are available as options.
Q5: Do you provide the circulation pump separately or is it included?
A: As indicated in the title, a 220V circulation pump is included with the standard package. The pump is pre-installed on a base frame with all necessary piping and valves, making the system ready to connect.
Q6: What certifications does your factory hold?
A: Our factory is ISO9001, ISO14000, and OHSAS18001 certified. Additionally, we have product-specific approvals such as HACCP for food contact and various industry standards. Certificates are available upon request.
Q7: How long is the delivery time?
A: For standard configurations with 220V pump, delivery is typically 15–25 working days after order confirmation, depending on quantity. Customized units may require 30–40 days.
Q8: What is your after-sales service policy?
A: We offer a 12-month warranty covering manufacturing defects. Our technical team provides online support and can arrange on-site commissioning if needed. Spare parts (gaskets, plates, pump) are available from our Qingdao warehouse.
Ready to upgrade your heat exchange process? Contact us for a detailed proposal and competitive pricing! Your inquiry will be answered within 24 hours.
