Hengshui Ruibin New Materials LLC, a professional manufacturer established in 2019, proudly presents our Fiberglass Floor Grating with 1.5-inch Grid. This product is engineered to deliver high tensile strength and exceptional corrosion resistance, making it an ideal flooring solution for wet areas, chemical plants, and industrial environments. With a factory spanning 1,000–3,000 square meters and an annual export value of US$2.5–5 million, we combine advanced production technology with strict quality control to ensure every grating meets your project requirements.
Our fiberglass floor grating is manufactured through a molded process using high-quality unsaturated polyester resin and continuous glass fiber roving. The 1.5-inch grid pattern provides a balanced combination of open area for drainage and solid surface for safe walking. The material is inherently non-conductive, non-magnetic, and lightweight, offering easy installation compared to traditional steel grating.
Below is a summary of key technical specifications for our standard 1.5-inch grid fiberglass floor grating:
| Property | Value |
| Grid Size | 1.5 inch × 1.5 inch (38.1 mm × 38.1 mm) |
| Bar Thickness | 1/4 inch to 1/2 inch (6.35–12.7 mm) customizable |
| Panel Thickness | 1/2 inch to 2 inches (12.7–50.8 mm) |
| Open Area | Approximately 50–60% |
| Tensile Strength | ≥300 MPa (typical, varies by resin system) |
| Temperature Range | -40°C to +100°C (standard resin) |
Key Features and Benefits:
- Exceptional Corrosion Resistance: Resistant to a wide range of chemicals, moisture, and saltwater, ensuring long service life in wastewater treatment plants, marine environments, and food processing facilities.
- High Tensile Strength: The continuous glass fiber reinforcement provides excellent structural integrity, supporting heavy loads without permanent deformation.
- Lightweight & Easy Installation: Weighs only about one-third of steel grating, reducing transportation costs and requiring minimal lifting equipment during installation.
- Slip-Resistant Surface: Available with a grit-embedded top surface (optional) for enhanced safety in wet or oily conditions.
- Low Maintenance: No need for painting, coating, or cathodic protection; simply wash with water to remove dirt.
- Customizable Dimensions: We can cut panels to your exact size, and offer various thicknesses, colors, and resin types (including fire-retardant and UV-stabilized).
Applications: Our 1.5-inch grid fiberglass floor grating is widely used for industrial flooring, catwalks, trench covers, platforms, stair treads, and drainage systems in: chemical plants, oil & gas facilities, pulp & paper mills, water/wastewater treatment, food & beverage processing, marine docks and shipbuilding, and commercial wet areas such as pool surrounds.
Why Choose Hengshui Ruibin New Materials LLC?
Since 2019, we have served customers across North America, South America, Europe, Asia, Africa, and Oceania. Our dedicated team of 101–200 employees ensures efficient production and timely delivery from the ports of Tianjin and Qingdao. With a strong commitment to quality, we have earned the trust of global buyers. Our annual export value of US$2.5–5 million reflects our ability to handle large-volume orders consistently. Every grating panel undergoes dimensional inspection and load testing before shipment. We offer flexible packaging options (plywood pallets, bundles with protection) and can provide third-party loading supervision upon request.
Frequently Asked Questions (FAQ):
- Does fiberglass grating conduct electricity? No, it is non-conductive and non-magnetic, making it safe for electrical substations and sensitive areas.
- Can this grating be used outdoors? Yes, we offer UV-stabilized resin options to prevent degradation from prolonged sunlight exposure.
- What is the maximum span for a 1.5-inch grid grating? It depends on load requirements and thickness; for pedestrian loads, typical spans range from 24–36 inches. Contact our engineers for specific calculations.
- Is the grating fire-resistant? Standard resin is not fire-rated, but we can supply fire-retardant grades (e.g., to ASTM E84 Class I) on request.
- How do I cut fiberglass grating on site? It can be cut with a circular saw or angle grinder using a diamond or abrasive blade. We also provide factory-cut panels for a precise fit.
- What colors are available? Common colors are yellow, gray, green, and safety orange. Custom colors can be matched to your specifications with a minimum order quantity.
- Does the product include anti-slip features? A grit-top surface is an optional add-on. By default, the surface is smooth but still provides good traction in dry conditions.
- How is the grating packaged for export? Panels are stacked and strapped on plywood pallets, wrapped with waterproof film to prevent moisture damage during transit.
Ready to upgrade your flooring system? Contact us today for a quote or technical consultation. Our experienced team will help you select the optimal thickness, resin, and surface finish for your specific environment. With our global shipping network, your order can be delivered to major ports worldwide within 30–45 days. Experience the reliability of Hengshui Ruibin New Materials LLC – your trusted partner in fiberglass composite solutions.
