Home > Construction & Decoration > Decoration Materials > Sandwich Panel > Stainless Steel 316 Floor Grating, 20x100mm Bearer Bar, 3mm Mesh, Suitable for Food Processing Areas
Stainless Steel 316 Floor Grating, 20x100mm Bearer Bar, 3mm Mesh, Suitable for Food Processing Areas
Product Spotlights
Premium SS316 floor grating with 20x100mm bearer bar and 3mm mesh – engineered for food processing hygiene. Resists chlorides, acids, and cleaning chemicals. Open mesh design ensures drainage and slip prevention. Customizable sizes and anti-slip options. Direct manufacturer with global export experience.
Negotiable
MOQ: 300 Square Meters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Stainless Steel 316
Bearer Bar Size:
20x100mm
Mesh Thickness:
3mm
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Heavy Duty Floor Grating for Industrial Mezzanine, 40x100mm Grid, Load Capacity 10kN/m²NegotiableMOQ: 300 Square Meters -
Hot-Dip Galvanized Steel Floor Grating, 25x100mm Grid, 5mm Bar Thickness Load Capacity 5kN/m²NegotiableMOQ: 300 Square Meters
-
1 Year Warranty Floor Grating, Mill Test Report Included, Carbon Steel Hot-Dip Galvanized PanelsNegotiableMOQ: 300 Square Meters
-
Welded Steel Floor Grating, 40x40mm Aperture, 6mm Flat Bar, 1000mm x 3000mm Panel for DrainageNegotiableMOQ: 300 Square Meters
-
24-Month Service Promise on Floor Grating, Free Replacement for Defects, Standard Compliant SizesNegotiableMOQ: 300 Square Meters
Material
Stainless Steel 316
Bearer Bar Size
20x100mm
Mesh Thickness
3mm
Surface Finish
Mill finish (anti-slip optional)
Application
Food processing areas, industrial flooring
Load Capacity
Customizable upon request
Panel Size
Custom sizes available
Corrosion Resistance
High resistance to acids, alkalis, chlorides
As a direct manufacturer from Hengshui Ruibin New Materials LLC (established 2019), we specialize in producing premium Stainless Steel 316 Floor Grating with 20x100mm bearer bars and 3mm mesh, specifically engineered for demanding environments like food processing areas. Our team of over 100 skilled workers operates in a 1,000–3,000 square meter factory, delivering consistent quality for global clients across North America, Europe, Southeast Asia, and beyond. This grating combines the exceptional corrosion resistance of SS316 with a robust open-grid design, ensuring both hygiene and heavy-duty performance.
Key Features & Benefits
- Superior Material: Grade 316 stainless steel provides excellent resistance to chlorides, acids, and cleaning chemicals commonly used in food plants, preventing rust and pitting even in wet or salty conditions.
- Optimized Bearer Bar: 20x100mm bearer bars offer high load-bearing capacity while maintaining a lightweight structure, reducing installation effort and supporting heavy equipment.
- Fine Mesh Openings: 3mm mesh aperture effectively traps debris while allowing liquids and small particles to pass through, promoting drainage and preventing slip hazards.
- Hygienic Design: Smooth, non-porous surface inhibits bacterial growth and is easy to clean with high-pressure washers or steam, meeting HACCP and food safety standards.
- Customizable Options: Available in various panel sizes, surface finishes (including anti-slip serrated or plain), and load ratings to match your specific floor plan and traffic requirements.
- Long Service Life: With proper maintenance, SS316 grating can last decades in food processing environments, reducing replacement costs and downtime.
Technical Specifications (Typical) – Table
| Parameter | Value / Range |
|---|---|
| Material Grade | AISI 316 (UNS S31600) |
| Bearer Bar Dimensions | 20mm (height) × 100mm (depth) |
| Mesh Wire Thickness | 3mm (Ø3.0) |
| Open Area Percentage | Approx. 65–70% (standard) |
| Standard Panel Size | 1220 × 2440 mm (or custom) |
| Surface Finish | Mill finish (matte); serrated/anti-slip optional |
| Load Capacity (Uniform) | Up to 5 kN/m² (customizable) |
Why Choose Our Grating for Food Processing?
- Compliance with Food Safety: Our grating meets rigorous industry requirements for food contact surfaces—non-absorbent, corrosion-proof, and easy to sanitize.
- Enhanced Worker Safety: The open mesh design reduces standing water and grease buildup, lowering slip risks. Optional serrated surfaces provide extra grip in wet zones.
- High Chemical Resistance: Resistant to cleaning agents like chlorine, caustic soda, and phosphoric acid, ensuring no degradation or leaching into food products.
- Easy Installation & Maintenance: Lightweight panels can be cut and fitted on-site with standard tools. No painting or coating needed—just occasional wash-down.
Since 2019, Hengshui Ruibin New Materials LLC has exported over US$2.5 million to US$5 million worth of stainless steel products annually, serving clients in more than 10 major markets including North America, Europe, Africa, and Oceania. Our factory is staffed by 101–200 experienced professionals, operating advanced welding and cutting equipment under strict quality control. We ship from Tianjin Port or Qingdao Port, with flexible lead times and competitive FOB pricing. Whether you need a standard panel or a custom-engineered solution, our team provides responsive support and sample testing upon request.
Frequently Asked Questions (FAQ)
-
Q: Is this grating suitable for direct contact with food?
A: Yes, SS316 is a food-grade stainless steel that is non-toxic and non-reactive. The grating is designed for flooring and drainage, not for direct food contact surfaces, but it meets hygiene requirements for food processing areas. -
Q: Can the grating be cut to specific dimensions?
A: Absolutely. We offer custom panel sizes and shapes. Please provide your drawing or dimensions for a quotation. Standard sheets can also be cut on-site by the installer. -
Q: How does the 3mm mesh compare to larger openings?
A: The 3mm mesh is ideal for catching small debris (e.g., fruit pits, vegetable scraps) while allowing water and fine particles to pass. Larger openings (e.g., 6mm) may be used for general drainage; we can advise based on your application. -
Q: What is the maximum load this grating can support?
A: Standard uniform load capacity is up to 5 kN/m², but heavier-duty designs are available. Load capacity depends on bearer bar spacing, panel size, and support structure. Contact us with your load requirements. -
Q: How do I clean and maintain the grating?
A: Regular washing with hot water and mild detergent is sufficient. For stubborn grease, use a steam cleaner or non-chlorinated cleaner. Avoid abrasive pads that may scratch the surface. -
Q: Is the grating anti-slip?
A: The standard mill finish provides moderate slip resistance in dry conditions. For wet or oily areas, we recommend an optional serrated (toothed) surface or a perforated top plate. -
Q: What is the typical lead time for custom orders?
A: For standard sizes, 15–20 working days. Custom panels may require 25–35 working days, depending on complexity. We offer expedited shipping for urgent needs. -
Q: Do you provide free samples?
A: Yes, samples (e.g., 200×200mm) are available upon request. You only need to cover shipping costs. We also offer sample testing for load and corrosion resistance.
Ready to upgrade your food processing flooring? Contact our sales team at Hengshui Ruibin New Materials LLC for a quote or technical consultation. We look forward to serving you with reliable, hygienic stainless steel solutions.
