Help CenterLightweight Pultruded Fiberglass Profiles for Pedestrian Bridge Deck Construction
Product Spotlights
Related Products
-
Pultruded Fiberglass Profiles for Chemical Plant Structural Beams and GratingNegotiableMOQ: 300 Square Meters -
Pultruded Fiberglass Profiles With 5-Year Warranty and Mill Test Report IncludedNegotiableMOQ: 300 Square Meters
-
Custom-Length Pultruded Fiberglass Profiles With Free Technical Support ServiceNegotiableMOQ: 300 Square Meters
-
Corrosion-Resistant Pultruded Fiberglass Profiles 60% Glass Content Each WarrantedNegotiableMOQ: 300 Square Meters
-
Pultruded Fiberglass Profiles for Structural Use, Fire Rating Class A, UV ResistantNegotiableMOQ: 300 Square Meters
Hengshui Ruibin New Materials LLC is a specialized manufacturer of lightweight pultruded fiberglass profiles, established in 2019 with a factory size of 1,000–3,000 square meters and a dedicated team of 101–200 employees. Our pultruded fiberglass profiles for pedestrian bridge deck construction are engineered to deliver outstanding strength-to-weight ratio, corrosion resistance, and long-term durability. By leveraging advanced pultrusion technology, we produce profiles that are significantly lighter than steel yet strong enough to support pedestrian loads, making them ideal for footbridges, boardwalks, and elevated platforms. With an annual export value of US$2.5–5 million, our products have been shipped to major markets including North America, Europe, Southeast Asia, and Africa via Tianjin and Qingdao ports.
Key Product Highlights
- Ultra-lightweight – Our profiles weigh approximately 70% less than steel equivalents, reducing transportation costs and installation efforts.
- High strength & stiffness – Designed to meet pedestrian live load requirements with minimal deflection.
- Corrosion & chemical resistance – Will not rust, rot, or degrade in humid, coastal, or chemical environments.
- Low thermal conductivity – No condensation issues; comfortable for barefoot walking.
- Non-conductive & non-magnetic – Safe for electrical and sensitive environments.
- UV resistant – Suitable for long-term outdoor exposure with minimal maintenance.
- Customizable shapes & sizes – We can produce profiles per your engineering drawings.
Technical Specifications (Typical Values)
| Parameter | Value |
|---|---|
| Density | 1.7 – 2.0 g/cm³ (adjustable with resin system) |
| Tensile Strength | ≥ 200 MPa (longitudinal direction) |
| Flexural Modulus | ≥ 25 GPa |
| Glass Content | 60% – 75% by weight |
| Max Continuous Temperature | 80°C (standard resin), 150°C (high-temperature resin optional) |
| Water Absorption | |
| Surface Hardness (Barcol) | ≥ 45 |
These profiles can be supplied with an optional anti-slip surface texture for added safety on bridge decks. We also offer fire-retardant resin systems that meet various international standards (please inquire for specific certifications).
Advantages Over Traditional Materials
- vs. Steel: 70% lighter; no rust; no need for painting or galvanizing; longer service life in corrosive environments.
- vs. Aluminum: 30% lighter; higher strength-to-weight ratio; better fatigue resistance; lower coefficient of thermal expansion.
- vs. Wood: No rot, splintering, or insect damage; lasts decades with zero maintenance.
- vs. Concrete: Pre‑fabricated, ready to install; dramatically lower dead load reduces foundation costs.
Benefits for Your Pedestrian Bridge Project
Using our lightweight pultruded fiberglass profiles for deck construction leads to:
- Faster installation – Sections can be handled by small crews without heavy lifting equipment.
- Lower transport costs – More square meters per container load.
- Reduced foundation and support structure requirements – Saving overall project budget.
- Enhanced safety – Non-slip surface options and electrical insulation.
- Long life with minimal maintenance – Typical service life exceeding 20 years under proper design.
Why Choose Hengshui Ruibin New Materials LLC?
As a dedicated manufacturer with over 100 experienced workers and a modern facility, we control every step of production – from raw material selection to final quality inspection. Our annual export value of US$2.5–5 million demonstrates the trust of international customers across all major continents. We ship from the ports of Tianjin and Qingdao, ensuring efficient logistics to global destinations. We provide customized profile designs according to your engineering specifications, with reasonable lead times and competitive pricing. Our team is ready to support you with technical datasheets, sample testing, and project consultation.
Contact us today to discuss your pedestrian bridge deck requirements and request a quotation. Let our lightweight fiberglass profiles help you build safer, longer-lasting, and more cost-effective pedestrian bridges.
Frequently Asked Questions
Q1: What is the typical lifespan of these fiberglass profiles used for pedestrian bridge decks?
A: With proper design and installation, our pultruded fiberglass profiles can last over 20 years in outdoor environments. The UV‑stabilized resin and corrosion resistance ensure minimal degradation. Lifespan may vary based on specific load conditions and environmental exposure.
Q2: Can the profiles be cut or drilled on-site?
A: Yes, fiberglass profiles can be field‑cut, drilled, and machined using standard carbide‑tipped tools. We recommend sealing any cut edges with a compatible resin or paint to prevent moisture ingress.
Q3: Do you offer anti‑slip surfaces for pedestrian safety?
A: Absolutely. We can add a textured surface during pultrusion or apply a non‑slip coating. The standard option is a grit‑embedded top surface that provides excellent traction even when wet.
Q4: Are these profiles fire‑resistant?
A: Our standard polyester resin is classified as self‑extinguishing. For projects requiring specific fire ratings, we offer fire‑retardant resin systems that meet ASTM E84 Class A or similar standards. Please specify your requirements.
Q5: What is the maximum span length possible for a pedestrian bridge deck using your profiles?
A: The span length depends on the profile geometry, load requirements, and support configuration. Typically, our I‑beam profiles can span up to 6–8 meters for pedestrian loads (5 kN/m²). For longer spans, we can design custom optimized sections.
Q6: Do you provide engineering support and load calculations?
A: Yes, our technical team can assist with structural calculations and provide finite element analysis (FEA) data to help you integrate our profiles into your bridge design. Detailed strength tables and design guides are available upon request.
Q7: What are the available colors and surface finishes?
A: Standard color is gray. We can produce profiles in any RAL color with UV‑stable pigment added directly to the resin. For the deck surface, you can choose smooth, textured, or with an anti‑skid coating.
Q8: What is the minimum order quantity (MOQ)?
A: For standard profiles, MOQ is typically 500 kg per shape. For custom molds and R&D projects, we can discuss smaller quantities. We are flexible to meet your project needs.
