Fiberglass Round Tube 76mm OD, 4mm Wall, High Load Capacity 2000kg/m, Non-Conductive
Product Spotlights
This 76mm OD fiberglass round tube with 4mm wall offers a remarkable axial load capacity of 2000kg/m while remaining completely non-conductive. Corrosion-resistant, lightweight (70% lighter than steel), and customizable in length and color. Ideal for structural supports, electrical insulation, and harsh environments. Factory-direct from a reliable Chinese manufacturer with global export experience.
Negotiable
MOQ: 300 Square Meters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Other, Fiberglass Reinforced Plastic (FRP)
Outer Diameter:
76 mm
Wall Thickness:
4 mm
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Glass Fiber Reinforced Plastic Round Tube 100mm OD x 5mm Wall, Heat Resistant Up to 200°CNegotiableMOQ: 300 Square Meters -
FRP Round Tube 4m Length, 50mm OD, 3mm Wall, UV Resistant, Light Weight for Structural SupportsNegotiableMOQ: 300 Square Meters
-
FRP Round Tube for Marine Handrails, Deck Railing, Corrosion Resistant in Salt WaterNegotiableMOQ: 300 Square Meters
-
FRP Round Tube With 5-Year Warranty, Mill Test Report Included, Standard Compliant, Factory DirectNegotiableMOQ: 300 Square Meters
-
Fiberglass Round Tubes for Greenhouse Frame Construction, Lightweight, Weatherproof, Easy InstallNegotiableMOQ: 300 Square Meters
Material
Other, Fiberglass Reinforced Plastic (FRP)
Outer Diameter
76 mm
Wall Thickness
4 mm
Load Capacity
2000 kg/m
Color
Available in custom options (e.g., white, gray, green)
Length
Customizable (standard up to 12m)
Surface Finish
Smooth / UV-resistant coating available
Application
Structural support, electrical insulation, antenna masts, etc.
Conductivity
Non-conductive (electrical insulation)
Certification
Optional upon request (e.g., SGS, TUV)
Welcome to Hengshui Ruibin New Materials LLC, your trusted manufacturer of high-performance fiberglass products since 2019. Our Fiberglass Round Tube 76mm OD, 4mm Wall, High Load Capacity 2000kg/m is designed for demanding applications where strength, durability, and electrical insulation are critical. Engineered with precision pultrusion technology, this tube delivers exceptional load-bearing capability while remaining completely non-conductive, making it the ideal choice for industries ranging from construction to telecommunications.
As a factory with over 100 skilled employees and an annual export value exceeding US$2.5 million, we ensure rigorous quality control at every stage. Our tubes are shipped from major ports like Tianjin and Qingdao to clients across North America, Europe, Southeast Asia, and more. Below we detail the key features and benefits that set our product apart.
Key Features & Technical Specifications
- High Load Capacity: Rated at 2000 kg/m, this tube can support substantial axial loads, ideal for structural columns, beams, and supports in industrial environments.
- Non-Conductive: Made from glass fiber and thermosetting resin, it provides excellent electrical insulation, preventing short circuits and ensuring safety near power lines or in electrical substations.
- Corrosion Resistance: Unlike steel or aluminum, fiberglass does not rust or corrode, making it suitable for chemical plants, marine settings, and outdoor installations.
- Lightweight Yet Strong: Approximately 70% lighter than steel of similar load capacity, reducing transportation and installation costs.
- Dimensional Accuracy: Outer diameter 76 mm ±0.5 mm, wall thickness 4 mm ±0.3 mm, ensuring consistency for custom fittings and assemblies.
- UV Resistance: Optional UV-stabilized coating available for prolonged exposure to sunlight.
- Customizable Lengths: Standard lengths up to 12 meters; custom cuts available upon request.
- Fire Retardant Options: Halogen-free and V-0 rated materials can be specified for fire-sensitive applications.
| Parameter | Value |
|---|---|
| Outer Diameter | 76 mm |
| Wall Thickness | 4 mm |
| Load Capacity (axial) | 2000 kg/m |
| Density | ~1.9 g/cm³ |
| Color | Custom (standard: light gray) |
| Operating Temperature | -40°C to +80°C (continuous) |
| Surface Finish | Smooth matte / UV-resistant coating optional |
| Application Examples | Poles, railing, ladder rails, cable trays, support structures |
Advantages for Your Business
By choosing this fiberglass round tube, you benefit from:
- Reduced Maintenance: No painting, no rustproofing, no periodic coating required. This translates to lower lifetime costs.
- Safe Handling: Non-conductive nature eliminates the risk of electrical shock when used near live wires.
- Easy Installation: Lightweight material reduces need for heavy lifting equipment, speeding up assembly.
- Environmental Resistance: Withstands saltwater, chemicals, UV rays, and extreme temperatures better than most metals.
- Consistent Quality: Our factory employs 101-200 people with dedicated quality inspection, ensuring each tube meets tight tolerances.
Trust & Reliability – Why Choose Hengshui Ruibin?
Established in 2019, Hengshui Ruibin New Materials LLC has grown into a reputable manufacturer with a factory spanning 1,000-3,000 square meters and annual exports exceeding US$2.5 million. Our products are trusted in over 10 global markets including North America, South America, Europe, and Oceania. We maintain strict process controls, from raw fiberglass roving to final pultrusion and packaging. Our team of experienced engineers can assist with custom specifications, such as specific lengths, colors, or load certifications. We pride ourselves on on-time delivery via the ports of Tianjin and Qingdao.
We are confident that our Fiberglass Round Tube 76mm OD, 4mm Wall, High Load Capacity 2000kg/m will meet your most rigorous demands. Contact us today to request a quote, discuss your custom requirements, or place a trial order. Experience the durability and safety of genuine Chinese manufacturing excellence.
Frequently Asked Questions (FAQ)
-
Q: Is this tube truly non-conductive?
A: Yes, fiberglass is an excellent electrical insulator. The tube has been tested for dielectric strength and is suitable for use in electrical environments up to typical low-voltage applications. For high-voltage use, please consult our engineering team for specific ratings. -
Q: Can it be cut to custom lengths?
A: Absolutely. We offer cutting services for any length requirement. Please specify your desired length when placing the order. Standard lengths are 6m and 12m. -
Q: What is the load capacity direction?
A: The rated 2000 kg/m is the axial compression load capacity. Lateral bending load capacity depends on span length; please contact us for detailed load tables for your specific application. -
Q: Does the tube come with any coating?
A: The standard surface is a smooth matte finish. We can add a UV-resistant gel coat or a fire-retardant layer as optional extras. Please inquire for prices and minimum order quantities. -
Q: Can I get a sample before bulk order?
A: Yes, sample orders are welcome. We can provide a sample of 0.5m to 1m length with our standard specs. Shipping cost is usually borne by the customer. -
Q: What is the typical lead time?
A: For standard specifications, lead time is 7-15 working days after deposit. Custom orders may take 15-25 days depending on complexity. -
Q: Are there any certifications available?
A: We can provide test reports from third-party labs (e.g., SGS, TUV) upon request. Our products comply with international quality standards, and we are open to your specific certification needs (additional charges may apply). -
Q: How do I compare this tube with a steel tube?
A: While steel offers higher absolute load capacity, fiberglass is 70% lighter, corrosion-free, non-conductive, and easier to handle. For many applications, the weight and maintenance savings outweigh the initial cost difference.
