Stainless Steel 316 Trench Grating, 25mm Bar Spacing, 3m Length, Flat Surface for Easy Cleaning
Product Spotlights
316 stainless steel trench grating with 25mm bar spacing, 3m length, and flat surface for easy cleaning. Corrosion-resistant, low-maintenance, customizable widths and lengths. Factory-direct from a manufacturer with 100–200 employees and exports worldwide. Ideal for food plants, kitchens, and industrial drains.
Negotiable
MOQ: 300 Square Meters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
material:
Stainless Steel 316
bar_spacing:
25mm
length:
3m
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Locking Trench Grating, 304 Stainless Steel, 1500mm Length, With Hinged Clips for SafetyNegotiableMOQ: 300 Square Meters -
Trench Grating for Parking Lot Drainage, Load Class C250, Steel, 1000x500mm, Easy InstallationNegotiableMOQ: 300 Square Meters
-
Heavy Duty Polymer Concrete Trench Grating, Load Class B125, 1000mm Length, UV ResistantNegotiableMOQ: 300 Square Meters
-
Trench Grating With 1-Year Warranty, Load Class D400 Cast Iron, Technical Drawing Provided for InstallationNegotiableMOQ: 300 Square Meters
-
Trench Grating With 2-Year Warranty, Mill Test Report Provided, 304 Stainless Steel, Custom Length AvailableNegotiableMOQ: 300 Square Meters
material
Stainless Steel 316
bar_spacing
25mm
length
3m
surface_type
Flat Surface
application
Drainage channels, Industrial flooring, Walkways
color
Silver metallic
load_capacity
Customizable (available upon request)
brand
Hengshui Ruibin
model
RTG-316-25-3.0
As an experienced manufacturer from Hengshui Ruibin New Materials LLC, we specialize in producing high-quality Stainless Steel 316 Trench Grating. Our grating features a 25mm bar spacing and a 3-meter length, with a flat surface design that makes cleaning effortless. Since our establishment in 2019, we have served clients across North America, Europe, Asia, Africa, and Oceania, with an annual export value of US$2.5–5 million. This product is engineered for demanding environments where corrosion resistance, hygiene, and durability are critical. Whether used in food processing plants, commercial kitchens, or municipal drainage systems, our trench grating delivers reliable performance with minimal maintenance.
Key Features & Technical Specifications
- Premium 316 Stainless Steel — Superior resistance to chlorides, acids, and harsh chemicals, ideal for coastal or chemical-heavy environments.
- 25mm Bar Spacing — Prevents large debris from entering while allowing efficient water drainage; meets typical safety standards for pedestrian and light vehicle loads.
- 3-Meter Length — Reduces the number of joints and simplifies installation over long spans; customizable lengths are also available upon request.
- Flat Surface Design — Smooth, level profile eliminates dirt traps and allows quick hosing or sweeping; suitable for areas requiring high hygiene levels.
- High Load Capacity — Engineered to withstand heavy foot traffic and occasional light vehicle loading; exact load ratings can be provided for your specific application.
- Easy Installation — Pre-cut and ready to fit into standard trench frames; can be welded or fastened with clamps (hardware available separately).
- Low Maintenance — Rounded bar edges and smooth finish reduce buildup of grime and bacteria; compatible with pressure washers and chemical cleaners.
Product Parameters (Standard)
| Parameter | Value |
|---|---|
| Material | Stainless Steel 316 (UNS S31600) |
| Bar Spacing (center-to-center) | 25mm |
| Overall Length | 3m (custom lengths available) |
| Surface Finish | Flat / mill finish (optional polished or anti-slip coating) |
| Width | Standard widths 100mm–500mm; custom widths upon request |
| Bar Thickness | Typically 3mm–5mm (depending on load requirement) |
| Weight per meter (approx.) | 6–12 kg/m (varies by width and bar thickness) |
Why Choose Hengshui Ruibin as Your Supplier?
Our factory, located in Hengshui, Hebei, China, spans 1,000–3,000 square meters and employs 101–200 skilled workers. We control every step of production — from raw material sourcing to final inspection — ensuring consistent quality. With an annual export value of US$2.5–5 million and shipments through Port of Tianjin and Port of Qingdao, we have the capacity to fulfill both small trials and large container orders. Our products have been trusted by clients in North America, South America, Europe, Africa, Oceania, and the Middle East. We provide customizable options such as different widths, anti‑slip treatments, or cut‑to‑length services to match your project requirements. Backed by responsive customer service and technical support, we invite you to contact us for samples or a quotation today.
Frequently Asked Questions
-
What is the difference between 304 and 316 stainless steel for trench grating?
316 stainless steel contains molybdenum, which gives enhanced resistance to pitting and corrosion in chloride‑rich environments (e.g., coastal areas, food processing with salt). 304 is suitable for milder conditions but may not last as long in aggressive settings. -
Can the grating be cut to a different length?
Yes, we offer customizable lengths. Our standard is 3m, but we can produce shorter or longer sections according to your specifications. Please contact us with your desired dimensions. -
What is the maximum load capacity of this grating?
The load rating depends on the bar thickness, width, and support span. For typical pedestrian and light vehicle applications, our standard design supports up to 4–6 kN/m². For heavy‑duty uses, we can increase the bar thickness or reduce the spacing. Exact data will be provided based on your project parameters. -
How should I clean the grating?
Due to the flat surface design, you can simply hose it down with water or use a pressure washer. For stubborn residues, mild detergents or stainless‑steel cleaners are safe. Avoid abrasive pads that may scratch the surface. -
Is the grating suitable for outdoor use in freezing climates?
Yes, 316 stainless steel maintains its strength and corrosion resistance in low temperatures. However, if ice buildup is a concern, we recommend using a proper drainage slope and optional anti‑slip surface treatment. -
Do you provide matching frames or support channels?
Yes, we can supply stainless steel frames, angle bars, or fastening clips to complete your trench system. Please inquire about compatibility with your existing trench dimensions. -
What is the delivery time for a standard order?
For stock sizes, delivery typically takes 15–25 days after order confirmation (depending on quantity). Customized products may require 20–35 days. We ship internationally via sea freight from Tianjin or Qingdao ports. -
Can I get a sample before placing a bulk order?
Absolutely. We offer small samples at a nominal cost plus shipping. Once you confirm the quality and dimensions, we can proceed with mass production. Contact our sales team to arrange a sample.
Contact Hengshui Ruibin New Materials LLC today for a competitive quote. Let us help you find the perfect drainage solution for your project.
