Help CenterCNC Rotary Table for Automotive Cylinder Head Machining: 5-Axis Simultaneous Processing
Product Spotlights
Related Products
-
Semi-Auto CNC Rotary Table With IP65 Protection and ±5 Arcsec Positioning Accuracy 400mmNegotiableMOQ: 1 Set -
Precision CNC Rotary Table for Machining Center With Hardened Steel Worm Gear and 50rpm Max SpeedNegotiableMOQ: 1 Set
-
1-Year Warranty CNC Rotary Table With Free Technical Training and On-Site Installation ServiceNegotiableMOQ: 1 Set
-
0.002mm Repeatability CNC Rotary Table With AC Servo Motor and Brake Lock FunctionNegotiableMOQ: 1 Set
-
CNC Rotary Table Made in China 4th Axis, 0.2° Positioning Accuracy, 24h Free Replacement, 18 Month WarrantyNegotiableMOQ: 1 Set
Suzhou Excellence Intelligent Technology Co., LTD brings you an advanced CNC Rotary Table specifically engineered for automotive cylinder head machining with 5-axis simultaneous processing capability. Since 2013, we have focused on delivering high-precision rotary indexing solutions to global automotive manufacturers, and this model is the result of years of R&D and field feedback. Designed to handle complex aluminum cylinder heads, it ensures tight tolerances, high stiffness, and seamless integration with 5-axis machining centers, significantly reducing cycle times while improving surface finish.
Our rotary table is built with premium materials and advanced harmonic drive technology to provide backlash-free motion and exceptional repeatability. Whether you are milling oil passages, valve seats, or combustion chamber contours, this table delivers the accuracy and durability required for high-volume production lines. Backed by our ISO9001-certified quality management system and a factory spanning 3,000–5,000 sqm, you can trust the consistency of every unit we ship.
Below you will find the detailed specifications, key advantages, and answers to common questions. We encourage you to contact our team for custom configurations tailored to your specific cylinder head models and machining requirements.
Key Specifications
| Parameter | Value |
| Table Diameter | 400mm / 500mm / 630mm (custom sizes available) |
| Axis Configuration | A-axis (tilting) + C-axis (rotary), 5‑axis simultaneous |
| Max Rotation Speed | 50 rpm (synchronized), 10 rpm (indexing) |
| Positioning Accuracy | ±4 arcsec (optional ±2 arcsec) |
| Repeatability | ±1 arcsec |
| Drive Type | Servo motor + harmonic drive (direct drive optional) |
| Max Load Range (Horizontal) | 600 – 800 kg depending on configuration |
| Recommended Machine Interface | Fanuc, Siemens, Heidenhain, Mitsubishi (optional) |
| Lubrication | Automatic grease / oil (maintenance‑free option) |
Product Features & Benefits
- 5‑Axis Simultaneous Machining – Enables complex cylinder head features (valve guides, seat angles, oil galleries) to be completed in a single setup, reducing handling errors and cycle time by up to 40%.
- High Stiffness Structure – Heavy‑duty cast iron housing and pre‑loaded bearings provide vibration damping, essential for achieving tight tolerances on aluminum castings.
- Backlash‑Free Harmonic Drive – Zero lost motion ensures smooth contouring and excellent surface finish, even at high feed rates.
- Sealed Protection – IP67 rated sealing against coolant and chips, suitable for wet machining environments typical of automotive lines.
- Easy Integration – Compatible with most 5‑axis CNC controls; plug‑and‑play electrical interface with encoder feedback.
- Custom Clamping Options – Tailored T‑slot patterns, pneumatic or hydraulic clamping systems can be added for specific cylinder head fixtures.
- Low Maintenance – Long‑life harmonic drive and sealed bearings require infrequent service, maximizing uptime.
Why choose Suzhou Excellence Intelligent Technology?
With an annual export value of US$5–10 million and shipments through major ports (Shanghai, Ningbo, Shenzhen, Qingdao), we have fulfilled orders across North America, Europe, Southeast Asia, and more. Our factory, equipped with modern machining and assembly lines, undergoes rigorous quality control under ISO9001:2015 certification. Every rotary table is tested for runout, backlash, and positioning accuracy before delivery. If you are looking for a reliable partner for your automotive cylinder head production, our proven track record and responsive technical support will give you confidence.
Frequently Asked Questions
- Q1: Can this rotary table handle cylinder heads of different sizes and weights?
- Yes, we offer table diameters from 400mm to 630mm (and custom diameters). Load capacity ranges from 600kg to 800kg, covering most passenger car and light truck cylinder heads. For heavier or larger parts, please provide your specific dimensions and we can recommend a suitable size.
- Q2: Is the table compatible with my existing CNC controller?
- Our rotary table supports common control interfaces such as Fanuc, Siemens 840D, Heidenhain TNC, and Mitsubishi. We also provide an optional analog interface that works with older controllers. Please specify your control model when ordering for a seamless integration.
- Q3: What kind of maintenance does the table require?
- The harmonic drive and bearings are pre‑lubricated and sealed. Under normal operation, we recommend checking the grease condition every 6 months. An optional automatic lubrication system can be added for high‑uptime production. No major maintenance is needed within the first 10,000 hours of operation.
- Q4: Can I use the table for both roughing and finishing operations?
- Absolutely. The high stiffness and zero backlash ensure consistent performance under heavy cuts during roughing, while also delivering the fine positional accuracy required for finishing the cylinder head combustion chamber and valve seats. Many customers use it for both stages in a single machine.
- Q5: What is the typical delivery time?
- For standard configurations (400mm/500mm tables with harmonic drive), lead time is approximately 25–35 working days. Customized solutions may take 40–50 days depending on the complexity. We ship via ports in Shanghai, Ningbo, Shenzhen, or Qingdao.
- Q6: Do you provide installation and training support?
- Yes, our technical team can offer remote or on‑site commissioning support. We also provide a detailed installation manual and parameter settings for your CNC. Custom macro programs for cylinder head machining cycles are available upon request.
- Q7: Is the table suitable for dry machining as well?
- The standard model is designed for wet coolant environments (IP67 seals). For dry machining with MQL (minimum quantity lubrication), we also offer a sealed version with optimized heat dissipation. Please specify your coolant type when ordering.
- Q8: What is the warranty period?
- We provide a standard 12‑month warranty from the date of shipment covering manufacturing defects. Extended warranties up to 24 months are available as an optional service. Our after‑sales team responds within 24 hours for any technical inquiries.
Contact Suzhou Excellence Intelligent Technology today to discuss your cylinder head machining requirements. With decades of experience and a global reach, we are ready to help you boost productivity and precision.
