FRP Round Tube, 60mm OD, 4mm Wall, Corrosion Resistant, Suitable for Chemical Plant Piping Supports
Product Spotlights
60mm OD FRP round tube with 4mm wall, specifically designed for chemical plant piping supports. Offers exceptional corrosion resistance, lightweight strength, and customizable length/color. Manufactured by Hengshui Ruibin New Materials LLC with global export experience and flexible OEM support.
Negotiable
MOQ: 300 Square Meters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Fiberglass Reinforced Plastic (FRP)
Outer Diameter:
60mm
Wall Thickness:
4mm
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
FRP Round Tube, 40mm OD, 5mm Wall, High Modulus Glass Fiber, UV Resistant, 1.8g/cm³ DensityNegotiableMOQ: 300 Square Meters -
FRP Round Tube for Industrial Handrails, 38mm OD, 3mm Wall, Slip-Resistant Surface, Easy InstallationNegotiableMOQ: 300 Square Meters
-
Fiberglass Round Tube for Electrical Insulation, 10mm ID, 2mm Wall, High Dielectric Strength, UL 94 V-0 CompliantNegotiableMOQ: 300 Square Meters
-
Pultruded FRP Round Tube, Factory Direct, Technical Support Provided, Free Samples for Inquiry, DurableNegotiableMOQ: 300 Square Meters
-
FRP Round Tube, 1-Year Warranty, Mill Test Report Included, Custom Lengths Available, Standard CompliantNegotiableMOQ: 300 Square Meters
Material
Fiberglass Reinforced Plastic (FRP)
Outer Diameter
60mm
Wall Thickness
4mm
Color
Customizable
Application
Chemical plant piping supports
Surface Finish
Smooth gel coat
Length
Customizable (up to 6 meters)
Temperature Range
Available upon request
Hengshui Ruibin New Materials LLC, a professional manufacturer established in 2019, proudly introduces our FRP Round Tube with a 60mm outer diameter and 4mm wall thickness. This product is specifically engineered for chemical plant piping supports, where long-term corrosion resistance and structural reliability are critical. Leveraging advanced pultrusion and filament winding technologies, our FRP tubes combine lightweight properties with high strength, making them an ideal replacement for traditional metal supports in harsh chemical environments. Each tube undergoes strict quality control to ensure consistent dimensions and performance, backed by our factory’s 1,000–3,000 square meter production facility and an annual export value of US$2.5–5 million.
Key Features & Technical Specifications:
- Superior Corrosion Resistance: The fiberglass reinforced plastic matrix provides excellent resistance to acids, alkalis, solvents, and other corrosive media commonly found in chemical plants, ensuring a service life significantly longer than coated steel.
- Lightweight & High Strength: With a density only about 1/4 that of steel, our FRP round tube reduces structural load and simplifies installation. Despite its light weight, it offers tensile strength up to 300 MPa (depending on fiber orientation).
- Precise Dimensions: Outer diameter tolerance of ±0.5mm and wall thickness tolerance of ±0.2mm guarantee compatibility with standard pipe clamps and fittings.
- Non-Conductive & Non-Magnetic: Ideal for applications requiring electrical insulation or where spark risks must be avoided.
- UV Resistance: Surface gel coat includes UV stabilizers, preventing degradation from sunlight exposure in outdoor installations.
- Customizable Length & Color: Available in standard 2m, 3m, 4m, 6m lengths, or cut-to-size per your drawings. Color options include green, gray, yellow, orange, or any RAL code upon request.
| Parameter | Value |
|---|---|
| Outer Diameter | 60 mm (2.36 inches) |
| Wall Thickness | 4 mm (0.157 inches) |
| Standard Length | 2m / 3m / 4m / 6m (custom available) |
| Weight per Meter | Approx. 1.75 kg/m (depending on resin system) |
| Tensile Strength | ≥250 MPa (customizable) |
| Operating Temperature | -40°C to +120°C (higher upon request) |
| Color | Green, Gray, Yellow, Orange, or RAL code |
Benefits for Your Chemical Plant:
- Reduced Maintenance: Unlike galvanized steel or aluminum, FRP does not rust or corrode, eliminating the need for periodic painting or replacement.
- Easy Installation: Lightweight tubes can be cut on-site with standard tools, reducing labor and equipment costs.
- Long Service Life: Properly designed FRP supports can last 20+ years in aggressive chemical environments.
- Cost-Effective: Lower total cost of ownership compared to stainless steel or coated metal supports.
- Fire Retardant Options: Halogen-free, flame-retardant resin systems are available to meet specific fire safety standards.
Trusted Manufacturer with Global Reach
Hengshui Ruibin New Materials LLC operates a dedicated 1,000–3,000 m² factory in Hengshui, Hebei, China. With a team of 101–200 experienced employees, we have maintained an annual export value between US$2.5 million and US$5 million, serving markets across North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, the Middle East, East Asia, Western Europe, Central America, Northern Europe, South Asia, and China. Our products are shipped from the ports of Tianjin and Qingdao, with reliable logistics partners ensuring timely delivery. We welcome OEM/ODM orders and provide technical support for custom applications. Contact us today for a competitive quotation or sample request – experience the durability and performance of our FRP round tubes for your chemical plant piping supports.
Frequently Asked Questions (FAQ)
-
Q: Can this FRP tube be used in high-temperature environments?
A: The standard operating temperature range is -40°C to +120°C. For higher temperatures (up to 200°C), we recommend using a phenolic resin system. Please advise your specific temperature conditions for a custom solution. -
Q: Is the tube available in lengths other than standard?
A: Yes, we can cut to any length up to 6 meters per piece. For longer lengths, joints can be designed. Minimum custom quantity may apply. -
Q: How does FRP compare to stainless steel in terms of corrosion resistance?
A: FRP generally outperforms stainless steel in highly acidic or alkaline environments where passivation fails. It is also immune to chloride-induced stress corrosion cracking, making it superior for many chemical plant conditions. -
Q: Can I get samples before placing a bulk order?
A: Absolutely. We offer sample pieces (e.g., 30cm length) for your evaluation. The sample cost can be deducted from your first order. Please contact our sales team. -
Q: What color options are available?
A: Standard colors are green (similar to pultruded profiles), gray, yellow, and orange. Any RAL color can be matched for volume orders. The gel coat also provides UV protection. -
Q: What is the typical lead time?
A: For standard sizes and quantities under 500 pcs, lead time is 15–20 working days. Custom colors or specialty resins may require 25–30 working days. Rush orders can be negotiated. -
Q: How do I install the tube as a pipe support?
A: The tube can be cut, drilled, or machined using carbide-tipped tools. Standard pipe clamps and brackets can be used. We provide installation guidelines upon request. -
Q: Do you provide any warranty?
A: Yes, we offer a 12-month warranty against manufacturing defects. With proper use, the product is designed to last many years. Detailed warranty terms are available in our sales contract.
