Suzhou Excellence Intelligent Technology Co., Ltd. is proud to present our Manual Boring Machine, a dedicated solution for heavy equipment repair workshops that demand precision bore alignment. With a tolerance of 0.02mm, this machine ensures that every repair meets the highest standards of accuracy, reducing downtime and extending equipment life. Backed by our ISO9001-certified quality management system and over a decade of export experience, we deliver reliable performance for workshops worldwide.
Product Overview & Key Features
This manual boring machine is engineered for heavy-duty applications such as repairing engine blocks, gear housings, and large machinery components. Its robust cast iron construction provides exceptional stability, while the hand-scraped ways ensure smooth and precise movement. Key features include:
- High Precision: Consistently achieves 0.02mm tolerance for bore alignment.
- Versatile Boring Range: Capable of handling diameters from 50mm to 500mm.
- Manual Control: Simple, reliable operation with fine feed adjustment for optimal results.
- Durable Construction: Heavy-duty cast iron bed and spindle head for long service life.
- Easy Maintenance: Accessible lubrication points and replaceable guides.
- Safety Features: Emergency stop button and protective covers included.
Technical Specifications
| Parameter | Value |
|---|---|
| Boring Diameter Range | 50 – 500 mm |
| Spindle Speed Range | 60 – 1500 RPM (variable) |
| Feed Rate (Manual) | 0.01 – 0.10 mm/rev (adjustable) |
| Motor Power | 1.5 kW (optional upgrade to 3.0 kW) |
| Table Size | 800 x 400 mm |
| Weight | Approx. 1,200 kg |
| Overall Dimensions (LxWxH) | 2200 x 1200 x 1600 mm |
| Precision Tolerance | ≤ 0.02 mm |
Benefits for Your Workshop
Investing in this manual boring machine brings tangible advantages:
- Reduced Repair Time: Fast setup and reliable alignment minimize downtime.
- Cost Efficiency: Eliminate expensive outsourcing for precision boring tasks.
- Improved Quality: Consistent 0.02mm tolerance ensures parts fit correctly every time.
- Long-Term Durability: Built with high-quality materials to withstand harsh workshop environments.
- Operator Friendly: Intuitive manual controls require minimal training.
Trust & Reliability from Suzhou Excellence
Since 2013, Suzhou Excellence Intelligent Technology Co., Ltd. has been serving global customers with a focus on quality and innovation. Our factory spans 3,000–5,000 square meters, equipped with modern testing facilities. With an annual export value of US$5–10 million, we have shipped to markets across North America, Europe, Southeast Asia, Africa, and the Middle East. Our ISO9001 certification reflects our commitment to consistent quality. Every manual boring machine undergoes rigorous inspection before shipment. We invite you to contact us for more details or a customized solution tailored to your repair needs.
Frequently Asked Questions
-
Q: What types of heavy equipment can this machine repair?
A: It is ideal for repairing engine blocks, transmission casings, hydraulic cylinders, and large machining components commonly found in construction, mining, and agricultural machinery. -
Q: How is the 0.02mm tolerance achieved?
A: The machine features a precision-ground spindle, hand-scraped guideways, and a vernier scale on the manual feed for accurate adjustment. -
Q: Is the machine portable or stationary?
A: This is a stationary workshop model. For on-site repairs, we offer portable boring systems (inquire for details). -
Q: What power supply does it require?
A: Standard configuration is 380V/50Hz three-phase. Other voltages (e.g., 220V/60Hz) are available upon request. -
Q: Do you provide installation and training?
A: Yes, we offer remote guidance and on-site commissioning services for an additional fee. Detailed manuals and video tutorials are included. -
Q: Can the boring diameter range be extended beyond 500mm?
A: Custom modifications for larger diameters are possible. Please contact our sales team with your specific requirements. -
Q: What is the typical delivery time?
A: Standard models are usually shipped within 30–45 days after order confirmation. Custom orders may take longer. -
Q: What warranty do you offer?
A: We provide a 12-month warranty covering manufacturing defects. Extended warranty plans are optional.
Contact Suzhou Excellence Intelligent Technology Co., Ltd. today to learn how our manual boring machine can enhance your workshop's capabilities. We look forward to partnering with you!
