In 35kV and 110kV overhead transmission lines, insulators shoulder the dual mission of electrical insulation and mechanical connection. Since the lines are exposed to outdoor environments for a long time, lightning overvoltage, power-frequency switching overvoltage, industrial pollution, coastal salt spray, temperature variations, conductor tension, and wind vibration impose combined challenges on insulators. If traditional porcelain insulators have improper formulations or unstable manufacturing processes, problems such as glaze damage, shed cracks, internal insulation breakdown, pollution flashover, steel-leg corrosion, and cracking of cement assembly are likely to occur, which in severe cases can lead to conductor drop accidents and large-scale power outages.
Hejian Haokang Electric Co., Ltd. has long focused on the field of insulators and power station electroceramics, with products covering suspension, pin, porcelain crossarm, porcelain tension rod, spool, strain, crane, and line post insulators, as well as indoor/outdoor post insulators, wall bushings, and rod post insulators. In response to the above industry pain points, the company optimized the porcelain body formulation, glaze sintering, cementing process, and piece-by-piece factory testing for suspension porcelain insulators for high-voltage lines, giving 35kV and 110kV disc suspension porcelain insulators reliable performance in mechanical strength, insulation margin, pollution-flashover resistance, and assembly precision, and meeting the different application needs of power line construction, renovation, and emergency repair.
Product Mechanism and Structural Characteristics
Disc suspension porcelain insulators are composed of an iron cap, porcelain body, steel leg, and cement adhesive. In use, multiple insulators are connected in series and suspended between the tower crossarm and the conductor. By utilizing the high insulation resistance of the porcelain and the disc-shaped sheds to increase creepage distance, the line can maintain sufficient insulation level under normal operation, switching overvoltage, and lightning overvoltage conditions. The ball-and-socket or clevis-type connection of each insulator allows a certain range of relative movement, which can absorb dynamic bending moments caused by conductor wind vibration and thermal deformation, preventing the porcelain body from damage due to abnormal stress.
This product is made of high-strength electrical ceramics. The porcelain body is coated with a stable porcelain glaze, providing good pollution-flashover resistance and weather-aging resistance. The iron cap and steel leg adopt metal parts with hot-dip galvanized surface treatment, and the cementing parts use special cement and curing processes to ensure tight assembly and uniform stress distribution. Before leaving the factory, each product is inspected for appearance, dimensions, zinc layer, and cementing quality, and batch sampling tests for electromechanical load and power-frequency withstand voltage are conducted to prevent non-conforming products from entering the line.
Key Technical Features
- Disc-shaped shed structure: longer leakage path, and external insulation performance is significantly superior to a simple pin-type structure.
- Suspension series connection: the number of pieces can be changed according to system voltage, neutral grounding mode, and pollution zone level, offering flexible design.
- High-strength porcelain body: high mechanical strength and high rigidity, with small deformation under conductor self-weight, ice coating, and wind force.
Consultation and Suggestions
Please provide the line voltage level, pollution area level, number of pieces per string or insulator quantity, conductor model, tension conditions, connection hardware types, and installation positions before placing an order. For 35kV and 110kV overhead line renovation or new construction projects, our technicians at Hejian Haokang Electric Co., Ltd. can assist in selecting the specifications, quantity, anti-pollution umbrella type, and matching hardware for disc suspension porcelain insulators. If site conditions are special, we can provide hoisting, acceptance, and maintenance suggestions to ensure the insulator string remains stable and reliable during long-term operation.
