Help CenterHigh-voltage Bird Repeller, Intelligent Rotating Bird Deterrent Device for Power Towers, Bird Damage Prevention for Substations
Related Products
-
Outdoor Composite Insulator Post 110kv Anti-pollution Integral Injection Molding CustomizableUS$ 1.38MOQ: 100 Pieces -
Load Isolating Switch, Small Isolating Switch, 35kv Isolating Switch, Isolating Switch Protective CoverNegotiableMOQ: 0
-
Composite Insulator Tension String With Matching Clamps 220kv Lightweight High Insulation Free DesignUS$ 1.38MOQ: 100 Pieces
-
Insulator Suspension Insulator Pin Insulator Post Insulator Haokang Electric Xl-10/30NegotiableMOQ: 0
-
Lgj Steel-cored Aluminum Stranded Wire for Overhead Transmission Lines, 50 sq Mm, 70 sq Mm, Factory Direct Supply, Customization SupportedUS$ 1.54MOQ: 100 Pieces
Industry Core Pain Points and Solutions
In power systems, bird damage has always been a persistent problem for operation and maintenance personnel. When birds nest, excrete, or fly near poles and towers, their bodies or the twigs, wire scraps, and other debris they carry can easily cause line short circuits, flashover trips, and in severe cases even large-scale blackouts. Traditional manual bird repelling, anti-bird spikes, and ultrasonic devices either have short-lived effects or are easily affected by environmental conditions, with high maintenance costs and limited coverage. To address this industry pain point, Hejian Haokang Electric Co., Ltd., leveraging its deep experience in serving the power transmission and distribution field for many years, has extended its insulator protection expertise to the field of pole and tower bird prevention, and developed this high-voltage bird repeller – intelligent rotating bird repelling device specially for power poles and towers, and substation bird damage prevention equipment. This device adopts intelligent rotating reflection technology, and through continuous light disturbance and physical barriers, effectively drives birds away from power facilities while protecting them, reducing bird-related trip rates from the root and providing reliable protection for safe grid operation.
Working Mechanism and Technical Features
This device consists of a solar power supply system, an intelligent control unit, a rotating reflection assembly, and mounting accessories. Its core working principle is to use natural light reflected by mirrors, with a motor driving the reflection assembly to rotate continuously, generating ever-changing light spots and reflective areas, forming a visual interference zone that keeps birds away. At the same time, the rotation itself produces slight sound waves and air disturbance, further enhancing the repelling effect. The intelligent control unit has a built-in light sensor and delay circuit, and can automatically start or stop according to ambient brightness – it rotates automatically during the day when light is sufficient, and stops at night or on cloudy/rainy days to save power. This design ensures all-weather effective bird repelling while greatly extending the life of the battery and motor.
- Intelligent rotating reflection: A high-precision stepper motor is adopted, and the rotation speed can be automatically adjusted according to season and sunlight intensity (commonly set at 5-15 rpm), ensuring wide coverage of reflected light spots and continuous variation frequency to prevent birds from getting used to it.
- Solar self-powering: Equipped with a polycrystalline silicon solar panel (typical power: 20W) and a lithium iron phosphate battery (capacity: 12V/20Ah), it can continue working for more than 15 days under continuous cloudy/rainy conditions, requiring no external power supply and easy to install.
- All-stainless-steel body: The shell is made of 304 stainless steel + UV-resistant engineering plastic, corrosion-resistant and anti-aging, with a service life of over 8 years in harsh environments such as salt spray, strong winds, and sand dust.
- Electromagnetic compatibility design: The internal circuits use shielding and filtering to avoid interference with power line carrier and communication signals, and comply with electromagnetic compatibility testing standards.
Technical Specifications and Parameters
The following are standard configuration parameters, which can be customized according to the actual tower type and voltage level of the customer:
| Item | Parameter |
|---|---|
| Model | HK-QN-200 |
| Applicable Voltage Level | 10kV ~ 1000kV (AC/DC overhead lines and substations) |
| Rotation Speed | 6~12 rpm (automatic adjustment) |
| Effective Bird Repelling Radius | ≥30m (under clear weather conditions) |
| Solar Panel Power | 20W (polycrystalline silicon) |
| Battery Capacity | 12V / 20Ah (lithium iron phosphate) |
| Endurance on Consecutive Rainy Days | ≥15 days |
| Protection Rating | IP65 (dust-proof and water-jet-proof) |
| Operating Temperature Range | -40℃ ~ +70℃ |
| Weight (Complete Unit) | Approx. 8.5kg |
| Installation method | Clamp fixing with angle steel or round pipe (no drilling required) |
Trust endorsement and consultation advice
Hejian Haokang Electric Co., Ltd. has been deeply engaged in the electric insulator field for many years, and its products have been widely applied in transmission lines and substation projects of the State Grid, China Southern Power Grid, and multiple provincial electric power companies. The company owns CNC machining centers, injection molding workshops, assembly lines, and professional testing equipment, implementing full-process quality control from raw material inspection to finished product delivery. Although this bird deterrent is a newly added product category in recent years, its core components — the motor, solar panel, and control chip — are all sourced from leading domestic suppliers. The complete unit has passed a 72-hour continuous operation aging test and electromagnetic compatibility preliminary test. In actual engineering applications, 104 prototype units deployed in areas with frequent bird-related faults operated continuously for 8 months without a single trip caused by bird-related incidents, verifying the long-term stable performance of the equipment.
We recommend that power operation and maintenance units pay special attention to the weather resistance, electromagnetic compatibility, and continuous operation reliability of the equipment when selecting a bird deterrent solution. This product can provide technical solution design, on-site installation guidance, and free maintenance services during the warranty period. If you have specific tower type or voltage level requirements, please feel free to contact our technical team for targeted configuration suggestions. We will assist in formulating the most economical bird prevention solution based on your line corridor bird damage data and climatic conditions, and continue to provide technical upgrade support. We look forward to working with you to build a safe and reliable power operation environment.
FAQ Frequently Asked Questions
-
Q1: Can this device work normally in strong wind and heavy rain?
A: This product has an IP65 protection rating and a fully sealed design, capable of withstanding heavy rain and strong wind. Meanwhile, the rotating bearings and structure have undergone wind resistance calculations and can maintain mechanical integrity even under a Category 12 typhoon. However, extreme weather conditions may cause dust accumulation or shading on the solar panel. It is recommended to inspect and clean the panel surface after rain or snow to ensure charging efficiency. -
Q2: Will the bird deterrent cause electrical interference to power lines?
A: No. The device housing and internal circuits are made of non-ferromagnetic materials, and the control unit is designed with electromagnetic compatibility in mind, producing no high-frequency radiation or harmonics. In actual tests, at a distance of 1 meter from the equipment inside a 500kV substation, the measured background electromagnetic field showed no significant change, and it does not affect the operation of protection, monitoring, control, or communication equipment.
