Anping Xinye Metal Wire Mesh Products Co., Ltd. is a specialized manufacturer of engineered wire mesh products for industrial filtration and separation. Our Flower Roll Net in 316L stainless steel is produced with a precise 0.2mm wire diameter and a 20 micron filter rating, making it a reliable choice for original equipment manufacturers, filtration system builders, and maintenance departments. The roll format enables efficient handling, cutting, and conversion into custom filter elements, while the 316L grade offers the durability needed for continuous operation. In the following sections, we explain the product construction, key specifications, and practical applications to help you select the right filter mesh.
Product Overview
The Flower Roll Net is an industrial-grade stainless steel wire cloth that comes in a roll to support downstream processing. It combines the corrosion resistance of 316L material with a fine 20 micron filtration level, ensuring stable performance across a wide temperature range and in many chemical environments. Since it is supplied as a roll, manufacturers can slit it into narrow strips, punch it into gaskets, or pleat it into cartridges with minimal waste.
- Material: 316L stainless steel, featuring low carbon content and good resistance to stress corrosion cracking.
- Wire Diameter: 0.2 mm, providing a balanced combination of mechanical strength and flow area.
- Filtration Rating: 20 micron, designed for fine particle retention in process streams.
- Roll Form: Available in versatile roll dimensions for simple handling and conversion.
- Industrial Grade: Suitable for high-frequency-use filter elements in machinery and processing lines.
Technical Specifications
| Parameter | Value |
|---|---|
| Material | 316L Stainless Steel |
| Wire Diameter | 0.2 mm (standard) |
| Filtration Rating | 20 micron |
| Product Form | Roll net / filter element material |
| Surface Condition | Clean, uniform weave; oil-free surface available upon request |
| Roll Width | Customizable, typical widths available upon request |
| Roll Length | Customizable according to application |
| Custom Weave | Available upon request |
| Export Packing | Seaworthy export packaging with moisture protection |
Key Features and Benefits
- Good corrosion resistance: The 316L alloy performs well in humid, marine, and chemical environments, reducing replacement frequency.
- Fine filtration capability: The 20 micron mesh opening is suitable for removing sand, rust, resin fines, and other small contaminants from liquids and gases.
- High mechanical strength: 0.2mm wire provides the rigidity needed for pleated elements and support layers.
- Good flow characteristics: The open mesh area allows for lower pressure drop compared with more dense filter media.
- Easy processing: The roll form is compatible with automatic slitting machines, die-cutting, and welding processes.
- Flexible customization: Width, length, edge treatment, and further fabrication can be tailored to your production needs.
Applications
- Water treatment and wastewater filtration systems
- Chemical and petrochemical process filtration
- Petroleum, oil and fuel filtration
- Food and beverage processing
- Pharmaceutical and biological liquid filtration
- Industrial air and gas filtration
- Filter press support screens and protective layers
Quality Assurance and Export Support
As a manufacturer located in Hengshui, Hebei, China, Anping Xinye Metal Wire Mesh Products Co., Ltd. has been producing metal wire mesh since 2020. Our team consists of 51–100 employees working in a dedicated factory area of 5,000–10,000 square meters. We carry out dimensional and visual checks throughout the rolling and cutting process to ensure that each shipment meets the agreed specifications. For international customers, we offer flexible shipment arrangements from Tianjin, Qingdao, or Shanghai ports, and we serve markets across North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, the Middle East, East Asia, Western Europe, Central America, Northern Europe, Southern Europe, South Asia, and the domestic market. If your project requires specific test reports or compliance documents for export, please contact our sales team. We will check applicable requirements and provide the necessary technical documentation when available.
Frequently Asked Questions
1. What is the Flower Roll Net mainly used for?
It is primarily used as a filter element or filtration support layer in liquid and gas systems. Industries include water treatment, chemical processing, oil purification, and food processing. The 20 micron opening helps remove small particles while maintaining a good flow rate.
2. Can the roll be cut into custom sizes?
Yes, the roll format allows easy slitting and die-cutting. We can supply narrow rolls or pre-cut sheets according to your drawings. Please let our sales team know your required width and length.
3. Is 316L stainless steel compatible with seawater or acidic liquids?
316L stainless steel has good resistance to chloride corrosion and many acidic environments, but compatibility depends on concentration and temperature. For severe conditions, we can discuss more suited alloys or surface treatments.
4. Do you provide both mesh rolls and finished filter elements?
We can supply plain rolls, slit rolls, or further processed filter elements such as stamped discs and pleated cartridges, depending on your production need. Custom fabrication is available upon request.
5. What is the minimum order quantity?
The MOQ depends on material specification and roll width. In many cases, we can accept small trial orders and then scale up with regular supply. Please contact us for the exact MOQ.
6. How is the product packaged to avoid damage?
The mesh is wound neatly on a core, protected with moisture-resistant paper and foam board, and packed in strong export cases or standard wooden crates according to your requirements.
7. Can we request an oil-free and clean surface for food or pharmaceutical use?
Yes, an oil-free and clean surface is available upon request. Our production team can also provide additional cleaning treatment if required by your application.
