Help CenterFRP Round Tube 76mm OD 6mm Wall Fiberglass 70% Glass Content 6m Length for Corrosive Chemical Rack
Product Spotlights
Related Products
-
G10 FRP Round Tube 40mm OD 10mm Bore Compression-Molded 5000kN/m2 Strength for Busbar Insulating FrameNegotiableMOQ: 300 Square Meters -
Custom FRP Round Tube 25mm-300mm ID 10mm Thickness Heat-Resistant 150°C High-Stiffness Pultruded Profiles forNegotiableMOQ: 300 Square Meters
-
Pultruded Fiberglass U-Channel 50x50x5mm Flame-Retardant LOI 30% for Cable Tray SupportNegotiableMOQ: 300 Square Meters
-
Pultruded Fiberglass Channel 100x50x6mm, 30% Glass Fiber Content, UV-Stabilized Outdoor ProfileNegotiableMOQ: 300 Square Meters
-
Fiberglass Channel Profile - Non-Conductive Pultruded Section, -40°C to 150°C Working TemperatureNegotiableMOQ: 300 Square Meters
Hengshui Ruibin New Materials LLC is proud to present our high-performance FRP Round Tube 76mm OD 6mm Wall, specifically engineered for demanding corrosive environments. As a dedicated manufacturer since 2019, we have focused on producing fiberglass composite products that combine structural integrity with exceptional chemical resistance. This 70% glass content round tube is designed to replace traditional steel or PVC piping in chemical rack systems, offering a longer service life and lower maintenance costs. With a 6-meter length and 76mm outer diameter, this pultruded FRP tube delivers consistent quality and reliable performance for industrial applications.
Our FRP round tube is manufactured using high-strength E-glass fibers and corrosion-resistant resin systems. The high glass content of 70% ensures superior mechanical strength, while the 6mm wall thickness provides excellent stiffness and impact resistance. This combination makes the tube ideal for chemical storage racks, plating line supports, and other structures that are constantly exposed to acids, alkalis, and solvents.
Key Product Features
- High Glass Content (70%) – ensures maximum tensile strength and load-bearing capacity.
- Corrosion Resistant – excellent performance against most chemicals, acids, and alkalis.
- Lightweight yet Strong – about 75% lighter than steel while maintaining comparable strength.
- Low Thermal Conductivity – reduces condensation and thermal loss.
- Non-Conductive – safe for electrical applications and anti-static requirements.
- UV Resistant (optional finish) – available with UV protected surface for outdoor use.
- Easy to Fabricate – can be cut, drilled, or machined on site.
- Consistent Dimensions – pultruded process ensures tight tolerances and uniform wall thickness.
Typical Technical Specifications
| Outer Diameter | 76mm (3.0 inches) |
| Wall Thickness | 6mm (±0.3mm) |
| Glass Content | 70% ± 5% |
| Length | 6 meters (customizable) |
| Tensile Strength | ≥ 250 MPa |
| Flexural Strength | ≥ 300 MPa |
| Density | 1.9 – 2.1 g/cm³ |
| Color | Grey / White / Custom |
| Surface Finish | Smooth, matte, or veil mat |
Advantages for Chemical Rack Applications
Chemical racks often face severe corrosive attack from spilled acids, alkaline solutions, and solvent vapors. Standard metal racks rust quickly, and even coated steel can fail within months. Our FRP round tube solves this problem permanently:
- Long service life – no rust, rot, or peel-off. Average lifespan can reach 20+ years in most chemical environments.
- Zero maintenance – no repainting or anti-corrosion treatment required.
- Cost effective – lower overall life-cycle cost compared to stainless steel or exotic alloys.
- High load capacity – the 6mm wall provides robust support for heavy chemical containers and piping.
- Safe handling – non-slip surface available, and no sharp edges when properly cut.
Why Choose Hengshui Ruibin New Materials LLC?
With our factory covering 1,000-3,000 square meters and a dedicated team of 101-200 employees, we control quality at every stage of production. Our annual export value of US$2.5 million to US$5 million demonstrates strong acceptance from global buyers. We also offer flexible logistics solutions from Port of Tianjin and Port of Qingdao, ensuring timely delivery to North and South America, Europe, Southeast Asia, Africa, Oceania, the Middle East, and other regions.
Each FRP tube is produced under strict quality management. We understand that chemical environments demand defect-free products – that is why we perform dimensional checks and visual inspections before packing. Whether you need a single batch or a large container load, we are prepared to meet your specifications with consistent quality.
Contact us today to discuss your project requirements. Our engineering team can recommend the optimal resin system and surface finish for your specific chemical exposure. We welcome OEM and ODM orders, and we can customize lengths, colors, and packaging to fit your logistics needs. Choose Hengshui Ruibin for durable, reliable FRP round tubes that work where others fail.
Frequently Asked Questions
Q1: Can this FRP tube be used for outdoor chemical racks under sunlight?
Yes. Standard FRP has good UV resistance, but for extremely sunny climates we recommend a UV protected surface veil. We can provide this as an option to prevent fiber bloom and surface degradation over time.
Q2: What is the maximum load capacity of a single 6m tube?
Actual load capacity depends on the support spacing and mounting arrangement. For a simply supported beam with a span of 1 meter, this tube can typically carry several hundred kilograms. For precise engineering data, please provide your load and span details so we can calculate accordingly.
Q3: Do you offer cutting or machining services?
Yes, we can pre-cut tubes to your specified lengths at the factory. However, on-site cutting is also easy with standard carbide-tipped tools. We can supply tubes with or without pre-drilled holes.
Q4: What is the minimum order quantity?
Our MOQ is generally 100 meters, but for sample orders we can discuss smaller quantities depending on stock availability. For large projects, we offer volume discounts.
Q5: Are these tubes electrically conductive?
No. FRP is an excellent electrical insulator. This is a major advantage for chemical rack applications where accidental contact with live wires or static discharge must be avoided.
Q6: Can you provide custom colors or surface patterns?
Yes. We offer multiple color options and surface configurations, including a smooth gel coat or a textured matte finish. Custom colors such as yellow, blue, or orange are possible for safety marking.
Q7: Is your product certified for quality?
We follow our internal quality control procedures and can provide a Mill Test Certificate with each shipment. The product has passed our standard tests, and we can support customer-specific third-party inspections if requested.
Q8: How long is the production lead time?
For standard size tubes, production typically takes 10-15 days after deposit confirmation. For custom lengths or special resin systems, allow 20-25 days. We will confirm exact lead time when you place the order.
