Integrated Monitoring Station Round Dome FRP Radome is a high-performance transparent wave cover specially engineered for radar/navigation band radar and antenna systems. Featuring a round dome shell with a smooth curved profile, this radome is manufactured from low-dielectric fiberglass composite to deliver excellent electromagnetic wave permeability and minimal signal attenuation across the operating band.
The reinforced composite construction for higher mechanical strength provides increased rigidity and impact resistance, ensuring stable and reliable protection in demanding environments. Its streamlined dome geometry is designed to reduces wind load while protecting the antenna, making it suitable for all-in-one GNSS, lightning detection and environmental monitoring stations. Good weather resistance, anti-aging and waterproof properties guarantee long-term outdoor service with low maintenance.
Available with custom dimensions, wall thickness, mounting flanges, surface color and logo printing to match different antenna configurations and site requirements. Widely applied in communication, radar, navigation, detection and monitoring antenna systems.
Product Details
Serial number |
Project |
Features and Specifications |
Serial number |
Project |
Features and Specifications |
Serial number |
Project |
Features and Specifications |
1 |
Name |
Type A Integrated Monitoring Station |
8 |
Appearance |
Natural resin color |
15 |
Dielectric constant |
4.2-4.9 |
2 |
Specifications |
1550*4010㎜ |
9 |
Resin |
Modified epoxy resin |
16 |
Operating frequency |
1 MHz - 4 GHz |
3 |
Housing wall thickness |
5 mm |
10 |
fiber |
E-glass fiber |
17 |
Transmittance (or insertion loss) |
≥90% |
4 |
Weight |
185 kg ± 5 kg |
11 |
Nomex honeycomb |
/ |
18 |
Operating temperature |
-40℃--80℃ |
5 |
Structure |
Single-layer |
12 |
Insertion part |
/ |
19 |
Service life |
≥15 years |
6 |
Material |
Fiberglass |
13 |
Accessories |
/ |
20 |
Detailed dimensions |
See the drawing. |
7 |
Color |
Blue and white |
14 |
Packaging |
/ |
