Help CenterHandheld Beidou Positioning Wireless 3G/4G Video Recorder
Related Products
-
12V 1080P H.264 4G Equipment Transmitter With Antenna 4G and WifiUS$ 1 - 6,000MOQ: 1 Unit -
H.264 Video Compression 1080P Portable 4G Wifi Transmitter Made in ChinaUS$ 1 - 1,500MOQ: 1 Unit
-
High Performance 4G Portable Wifi Transmitter and Receiver Made in ChinaUS$ 1 - 1,500MOQ: 1 Unit
-
RS485 PTZ 1080P 4G Transmitter Support Wifi and 3G With Quick StartUS$ 1 - 6,000MOQ: 1 Unit
-
Hisilicon H.264 Wifi Video Transmitter Support Manual AlarmUS$ 1 - 1,500MOQ: 1 Unit
Features:
1. Separate design;
2. External camera can be flexibly configured;
3. Support button camera, badges cameras and others;
4. Built-in 3G, GPS, WIFI function;
5. Built-in 2.4 # TFT screen;
6. Use Lithium battery, long working hours> 8 hours;
7. Support dual Beidou / GPS baseband chip (option);
8. The latest audio and video compression technology;
9. ASF video file format standard.
10. Support 1pcs Micro-SD card, the maximum capacity can support 64G
11. IP call function (option)
12. Mobile monitoring center of platform management software (option).
Technical Parameters:
Item |
Description |
||
Separate Design |
Use main and auxiliary engines separate design to flexibly meet various application scenarios |
||
Video & Preview |
Video Input |
External camera |
|
OSD |
Characters superimposed functions, time and date, device ID, GPS and other image super positions |
||
Video Compression Formats |
H.264 compression encoding |
||
Dual-stream |
Support |
||
Resolution |
Default D1, CIF option |
||
Rate |
CIF: 400 Kbps~1.5Mbps, class 4 rate is optional |
||
D1:1000 Kbps~2Mbps, class 4 rate is optional | |||
Preview Function |
Real-time video preview |
||
Audio Frequency |
Audio Input |
Built-in MIC |
|
Audio Output |
Earphone output |
||
Compression Formats |
G.726 |
||
Video |
Storage Media |
SD card, support 1G ~ 64G |
|
File Format / System |
ASF/ FAT32 |
||
Video Strategy |
Default boot record, support timer recording |
||
Video Search |
Search according to the recording date and recording type |
||
Video Playback |
Support fast forward, fast rewind, play, pause control, support 2, 4, 8, 16 times of the speed of fast forward and fast rewind, and support the election playback control |
||
Wireless Transmission |
Built-in 3G wireless transmission module, WCDMA, CDMA2000, TD-SCDMA standard are optional; compatible with GPRS, EDGE |
||
GPS |
built-in GPS |
||
Screen Parameter |
Size: 2.4 inches; Type: TFT; Resolution: 480 * 234 |
||
System Upgrade |
Support Micro-SD card upgrade |
||
Power supply and consumption |
Power Management |
Manual switch, support manual off-screen, off-screen timeout automatically |
|
Battery Capacity |
4200mAh,7.4V |
||
Charging time |
<3hours |
||
Working time |
>8 hours |
||
Work Environment |
Temperature |
–20°C ~ +50°C |
|
Humidity |
20% to 95% |
||
Size |
80(W)×140(H)×35(D)mm |
||
Net weight |
475g |
||
