Help CenterCustomized Cosmetics Emlusifying Production Line
Related Products
Main Structure:
Cosmetic Complete Production Line consists of following parts:
(1) Homogenizing Emulsifying Main Kettle (Lifting together with the kettle cover, Turnover kettle body), water phase kettle.
(2) oil phase kettle.
(3) Dual Agitator with scraper.
(4) vacuum system.
(5) electric heating or steam heating temperature control system.
(6) electric control etc.
Main Features:
(1) Main Emulsifying process is carried out under completely closed condition to avoid dust and microbial pollution.
(2) The materials in the water phase kettle and oil phase kettle go to the main emulsifying kettle is through vacuum.
(3) The main kettle is turnover type for discharging materials.
(4) Electric heating or steam heating to heat up the materials inside the kettle.
(5) The automatically controlled heating temperature can be set at will.
(6) Input cooling water into the jacket to cool the materials down.
(7) The materials inside the kettle are sheared, dispersed and emulsified through high-speed interior circulation of the Emulsifier, and they are also mixed Forward and Backward two directions: Frame with scraper mixing (Clockwise Direction), Propeller Mixing(Anticlockwise Direction).
(8) Centrifugation generated by the rotation scraper agitator makes the PTFE scraper cling to the wall closely, which solve the materials-sticking-to-wall problem, without dead corner.
(9) Various speed control with Frequency Converter.
(10) Emulsifier and Propeller agitator can work independently or together.
(11) Required materials dispensing, emulsifying, homogenizing, mixing can be obtained within a short period.
(12) Kettle cover is equipped with lamp sight glass (One unit) so inside working condition can be checked at any time.
(13) The main kettle structure: Two jackets, heating and cooling can be finished in one jacket. And outside the jacket is covered with alumina silicate to preserve temperature. It can prevent operators from scalded and ensure production safety.
(14) Kettle cover is equipped with various quick-connection interfaces for optional according to requirements. (axenic breathing apparatus, materials inlet, vacuum pump interface, cleaning ball, CPI interface, micro quantity materials inlet, sight glass(one unit), vacuum gauge).
(15) The part contacting with materials is excellent stainless steel (For medical use, adopt SS316L, interior mirror polished. Mixing device is clean and manufactured complying with GMP standard.)
Technology Parameter:
| Model | Emulsifier | Emulsifier Speed (rpm) | Mixer | Mixer Speed(rpm) | Water Phase(L) | Oil Phase(L) |
| (kw) | (kw) | |||||
| VHES-10 | 0.55 | 0-2880 | 0.18 | 0-120 | 5 | 5 |
| VHES-50 | 1.5 | 0-2880 | 0.75 | 0-100 | 35 | 25 |
| VHES-100 | 2.2 | 0-2880 | 1.1 | 0-100 | 60 | 40 |
| VHES-200 | 4 | 0-2880 | 2.2 | 0-70 | 120 | 80 |
| VHES-300 | 5.5 | 0-2880 | 2.2 | 0-70 | 180 | 120 |
| VHES-500 | 7.5 | 0-2880 | 3 | 0-50 | 300 | 200 |
| VHES-1000 | 11 | 0-2880 | 7.5 | 0-30 | 500 | 500 |
| VHES-1500 | 22 | 0-2880 | 11 | 0-30 | 800 | 800 |
Remarks:
*The above listed Max. processing capacity is calculated as per water as medium. The model selection should depend on the comprehensive factors such as materials viscosity, specific gravity etc.
*If works under special environment such as high temperature, high pressure, explosive, combustible, corrosive etc, correct data is required for correct model selection.
*The above data and picture is subject to change without notice. The accurate parameter should be subject to the object.
*Not all products are listed. For more, please contact with our sales engineer.
Optional:
Materials: The part contacting with materials is SS304 or SS316L.
Heating: Electric heating, steam heating, hot water heating/heat transfer oil circulation heating.
Height Adjustment: Hydraulic Lifting, Electric Lifting.
