Vacuum High-Shear Emulsifier is non-standard designed and manufactured according to customer's production
processing. It is suitable for materials requiring for being emulsified and mixed under vacuum condition. Low-speed scraper isrecommended to work together when emulsifying and mixing materials with high viscosity. It can work
together with inline high shear emulsifier to carry out dispersing, emulsifying, homogenizing and mixing processes.
Following systems are optional according to requirement: Batching System, Discharging System, Cooling/Heating Temperature
Control System, Vacuum System, Nitrogen Protection System, Condensation and Recovery System, PH Value On-line
Measurement and Control System, CIP Cleaning System etc.
It is with wide application range and the processes are controllable.
It can be up to Sanitary Grade at request for mid batch or industrial production in industries such as medicine, food, cosmetic etc.
Applicable Materials: Applicable for production process for solution, gel, suspension or emulsion of solid - liquid, liquid- liquid materials such as juice, soup bases, milk production, tissue homogenate, cosmetics, surfactants, asphalt, emulsifier, oil field chemicals etc.
Production Capacity: 2-2000L
Technology parameters:
| Model | Design volume (L) |
Capacity (L) |
Blending power (kw) |
Blending speed (rpm) |
Emulsifying power (kw) |
Emulsifying speed (rpm) |
Electrical heating power (kw) |
Vacuum pump power (kw) |
Lifting |
| VHE-5 | 5 | 5 | 0.37 | 0-100 | 0.75 | 0-2880 | 2 | 0.37 | Manual |
| VHE-10 | 10 | 8 | 0.37 | 0-100 | 0.75 | 0-2880 | 2 | 0.37 | Manual |
| VHE-30 | 30 | 25 | 0.75 | 0-86 | 1.5 | 0-2800 | 2 | 0.37 | Electric |
| VHE-50 | 50 | 40 | 1.5 | 0-86 | 2.2 | 0-2880 | 2 | 0.37 | Electric |
| VHE-100 | 100 | 80 | 1.5 | 0-86 | 4 | 0-2880 | 6 | 0.37 | Electric |
| VHE-150 | 150 | 120 | 2.2 | 0-86 | 5.5 | 0-2800 | 6 | 0.75 | Electric |
| VHE-200 | 200 | 160 | 2.2 | 0-86 | 5.5 | 0-2880 | 8 | 0.75 | Electric |
| VHE-250 | 250 | 200 | 4 | 0-86 | 7.5 | 0-2880 | 12 | 0.75 | Hydraulic |
| VHE-350 | 350 | 280 | 4 | 0-86 | 7.5 | 0-2800 | 12 | 1.5 | Hydraulic |
| VHE-500 | 500 | 400 | 5.5 | 0-65 | 11 | 0-2880 | 15 | 1.5 | Hydraulic |
| VHE-650 | 650 | 520 | 5.5 | 0-65 | 15 | 0-2880 | 18 | 3 | Hydraulic |
| VHE-850 | 850 | 680 | 7.5 | 0-65 | 18.5 | 0-1440 | 18 | 3 | Hydraulic |
| VHE-1000 | 1000 | 800 | 7.5 | 0-65 | 18.5 | 0-1440 | 24 | 3 | Hydraulic |
| VHE-1300 | 1300 | 1000 | 11 | 0-45 | 22 | 0-1440 | 24 | 4 | Hydraulic |
| VHE-2000 | 2000 | 1600 | 15 | 0-45 | 30 | 0-1440 | 36 | 5.5 | Hydraulic |
