Specifications
1.High yield2.low energy consumption
3.Variety of raw materials
4.Easy maintenance
HJK-45 Red brick making machine,HJK Series Double stage vacuum extruder
This machine is used to produce solid bricks and hollow bricks with great quantities of holes and large section in all size of hole style.It is applicable to many sorts of materials.Its features are novel structure,advanced technology,high extrusive pressure,high production and high vacuum degree.It adopts pneumatic clutch to control.It is sensitive,convenient and reliable.the following is the detailed information of the clay brick making machine:
1.Fired and Energy-saving Clay Brick Machine Supplier:
Clay/Red Brick Making Machine, a type of patented product, is advanced by introducing the first-class technology of the same type of machine, which makes it popular both at home & abroad.
2.Main Use of Fired and Energy-saving Clay Brick Machine Supplier:
The machine applies to clay, shale, coal gangue, fly ash, slag, mountain mud, silt, etc. as raw materials to carry out a strong mixing, vacuum processing, and then the screw auger extrusion system to produce provisions cross-section of ordinary solid bricks, hollow bricks, and other products.
3. Features of Fired and Energy-saving Clay Brick Machine Supplier:
The trowel of this machine uses wear-resistant metallization technology; mixer shaft in above stage, main shaft of trowel and the body of machine are worked over by the aging, quenching and tempering; gears of reducer are hard tooth surfaces; clutch adopts screw press patented technology, which improves the service life of our equipments. At the same time, with reasonable design, compact structure, this machine can operate stably without having to install anchor bolt and greatly reduce the power consumption in the operating process due to shave. Utilizing the equipment and technologies can make the waste profitable as well as saving energy with obvious economic and social benefits.
Technology data of brick making machine :
Yield |
Block/h |
10000-12000pcs per hour |
Reamer Diameter |
mm |
450mm |
Extrusion Pressure |
Mpa |
3.0 |
Vacuum Degree |
Mpa |
92 % |
Motor Power |
Kw |
110+45 |
Exterior dimension |
mm |
5572*2054*2504 |
Pictures:
If you have any question about the machine,please contact with me.
