HM6820 8.2 m China Supplier Diesel Fuel Manual 17-30 Seats City Bus

Name: HM6820 8.2 m China Supplier Diesel Fuel Manual 17-30 Seats City Bus
Brand: HUAXIN
SKU: 109271989

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Seats:

21 - 40

Emission Standard:

Euro 3

Transmission Type:

Manual

Wuxi Huace Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Seats 21 - 40

Emission Standard Euro 3

Transmission Type Manual

Max Speed 51 - 70 km/h

Steering Position LHD

Fuel Type Diesel

Dimensions (L x W x H) (mm) 8160*2440*3100

Place of Origin Jiangsu, China

Brand Name HUAXIN

Model Number HM6820

Name: Hot Sale HM6820 8.2 m 17-30 seats City buses

Specifications
Model			HM6820
DIMENSIONS & WEIGHTS
Overall dimension (mm)		Length	8160
		Width	2440
		Height	3100
Wheelbase (mm)			3800
Thread (mm)		Front/rear	1920/1896
Gross vehicle weight (kg)			10500
Seating capacity (persons)			17-28/50
ENGINE
Model			CA4DF3-17E3
Type			4-cylinder, in line, water-cooled, direct injection, diesel, turbocharged, inter-cooling
Displacement (cc)			4752
Max. Power (hp/rpm)			180/2300
Max. Torque (N-m/rpm)			600/1400
Fuel tank (liter)			150
DRIVE TRAIN
Clutch			Hydraulic, Single plate
Gearbox			5 speed manual ,CA5-85
Max. gradeability (%)			25
CHASSIS
Frame			Ladder shaped, ‘] ’ section
Suspension, front/rear			Leaf springs
Shock absorber, front/rear			Double action shock absorbers
Steering			Recirculating-ball,power steering
Brake	Type		Air brake
	Front/rear		Drums
Power steering			With
Tires			7.50-20 14PR, Without spare tire
FOB SHANGHAI
