Brief Introduction
R-510-B is a two component encapsulate resin which is formed by modified epoxy resin, modifying agent, filler and auxiliaries etc. It’s heat-resistant grade is H, and it corresponds the RoHS environmental protection requirement.
Features
Fast cure, high mechanical strength, good heat resistance.
Applications
It is fit for the encapsulating of small size series motor(such as electric tool motor) rotor end, insulation of motorcycle cranking motor rotor, and pouring, encapsulating, and filling of other parts.
There are several colors of R-510-B, like white, red, green and blue etc. we could provide the product as customers’ need.
Qualification (as the Q/R 101-2010 company standard)
No. |
Test Item |
Test Method |
Unit |
Value |
1 |
Appearance |
Test Tube |
- |
Component A is thick liquid with color, while component B is yellowish-brown liquid |
2 |
Gel Time |
130±2°C |
min |
≤8 |
3 |
Dielectric Strength |
Normalcy |
MV/m |
≥20 |
4 |
Volume Resistivity |
Normalcy |
Ω·m |
≥1×1012 |
After immersion in water |
≥1×1010 |
|||
5 |
Pot life |
no gel,23°C |
h |
≥8
|
Established in 1992, Rota Group is one of the most professional manufacturers of impregnating varnish, mica tape, potting resin and embedding resin in China. Most products have been approved by ISO9001, 14000, UL, TUV, FDA, RoHS and REACH, widely used in high-voltage motors, wires and cables, household appliances, industrial pumps, and metallurgy equipments etc. We win the trust of the majority of well-known manufactures, like BOSCH, BLACK & DECKER, Fujitsu, Shibaura, REGAL, Siemens, EPCOS, N.P.V. and so on.
Professional quality, creating value for customers. Rota Group lead in the aspects of industry scale, product technology and innovation capacity, we will provide quality products and professional services for you. Welcome you!
