Home > Chemicals > Paint & Coating > Building Coating > Fast Dry Epoxy Dipping Varnish, Insulating Varnish, Insulation Varnish

Fast Dry Epoxy Dipping Varnish, Insulating Varnish, Insulation Varnish

Name: Fast Dry Epoxy Dipping Varnish, Insulating Varnish, Insulation Varnish
Brand: Rota
SKU: 109944957

Fast Dry Epoxy Dipping Varnish, Insulating Varnish, Insulation Varnish thumbnail-1

Fast Dry Epoxy Dipping Varnish, Insulating Varnish, Insulation Varnish photo-1

US$ 3.55 - 3.55 MOQ: 500 Kilograms

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Main Raw Material:

Epoxy

Usage:

Appliance Paint, Electrical Insulating Varnish

Contact Supplier Request Quote Chat Now

Jiaxing Rota-Ropa Insulating Material Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Main Raw Material Epoxy

Usage Appliance Paint, Electrical Insulating Varnish

Application Method Brush

State Liquid Coating

Brand Name Rota

Model Number R-305

Brief Introduction

R-305 is a two-component dipping varnish which is formed by epoxy resin, curing agent and thinner.Component A/B is 1/1 by weight ratio. It’s heat-resistant grade is B (130°C).

Features

Low curing temperature, good dipping manufacturability, bright film, fast dry, excellent mechanical strength and insulating property.

Application

This paint is fit for the continuous dipping technology and fast-dry dipping insulating operate of small-scale and micro motor, electrical equipment coil.

Qualification (as the Q/R 101-2010 company standard)

No.	Test Item	Test Method	Unit	Value
1	Appearance	Test Tube	-	Component A is colorless transparent liquid, component B is light yellow uniform liquid
2	Viscosity	4#cup, 23±1°C	s	11-13
3	Curing in thick layer	100°C,1h		No less than S1U1I4.2
4	Power Frequency Electric Strength	Normalcy	MV/m	≥70
5	Volume Resistivity	Normalcy	Ω·m	≥1×10¹²
		130°C		≥1×10⁷
		After immersion in water		≥1×10¹¹
6	Pot life	After mixed, no gel	d	8

Established in 1992, Rota Group is one of the most professional manufacturers of impregnating varnish, mica tape, potting resin and embedding resin in China. Most products have been approved by ISO9001, 14000, UL, TUV, FDA, RoHS and REACH, widely used in high-voltage motors, wires and cables, household appliances, industrial pumps, and metallurgy equipments etc. We win the trust of the majority of well-known manufactures, like BOSCH, BLACK & DECKER, Fujitsu, Shibaura, REGAL, Siemens, EPCOS, N.P.V. and so on.

Professional quality, creating value for customers. Rota Group lead in the aspects of industry scale, product technology and innovation capacity, we will provide quality products and professional services for you. Welcome you!
