QX1030 Technical parameter
Engine Engine model:ISUZU tech JX493ZQ4A
Maximum output according to DIN:62KW/3600r/mm 85hp
Bore*Stroke:93*102mm
Displacement:2.771L
Compression ratio:17.221
Min.fuel consumption:240g/kwh
Displacement criterion:EUR II
Idle speed:760±25r/min
Dimensions:663*705*717(without fan)
Clutch Model:Φ250 diaghragm clutch,single-plate dry clutch
Type:hydraulic operating,compressed air assisted
Transmission Model: 5MTI210L(Germany GETRAG)
Operating type:soft cable operator
Type:With constant-mesh-gear synchronizer
Constant-mesh:5 forward & 1 reverse
Ratio:5.016 2.672 1.585 1.00 0.77 4.783(R)
Dry weight:65kg
Wheels Tyres:6.50-16LT
Tyres Number:6+1
Front axle 2000kg
Rear axles 2720kg
suspension Type:Non-separate suspension
Type:Non-separate suspension
Front suspension:Parabola longitudinal steel leaf springs,with Telescopic cylinder shock absorber,steel spring No.:3pcs
Rear suspension:parabola longitudinal steel leaf springs,with anti-roll bars and Telescopic cylinder shock absorber;steel spring No.:4pcs
Steering system Model:6401QF18-001
Type:Steering with total power assisted
Ratio:17.3:1
Max.Pressure of teering oil pump(Mpa):9.5
Braking system Service brake:double circuit hydraulic brake,with vacuum power assisted
Driver's cab seats:2+1
Cab size(mm):L*W*H 1530x1780x1770
Electrics Operating voltage:12V negative grounded
Starter:12V 2.8kw
Alterator:14V 80A
Batteries:1*12V
Dimensions Wheel base(mm) 2600
Front tread(mm) 1498
Rear tread (mm) 1475
Front overhang(mm) 1155
Rear overhang(mm) 1155
Approach angle(mm) 22°
Departure angle(mm) 18°
Overall length(mm) 4910
Overall width(mm) 1780
Overall height(mm) 2200
Weight in kg Rated loading capacity 1500kg
Dead weight 2170kg
Gross vehicle weight 3670kg
Front axle capacity 1795kg
Rear axle capacity 2025kg
Performance Maximum drving speed(km/h) 105km/h
Fuel tank capacity 80L
Maximum grade abillity(%) 30%
Minimum ground clearance(mm) 175mm
Fuel consumption (L/100km) 12
Min.turning diameter(m) 11.5
