small square 12-24V dc PNP retro-reflective photoelectric sensor with reflector
Feature of CR series photoelectric sensor
1.Retro-reflective photoelectric sensor detection distance can reach 2
2.Through-beam photolectric sensor detection distance can reach 10
3.Mannual setting normal open or normal close funcation.
4.Good anti-interference ability.
Part Number and Output Method
| Model | Output Status | Output Method | Operating Voltage | Sensing distance | Connecting method |
| CR-200 | NO+NC | NPN |
10-30 VDC |
2M | Pre-wired 2m cable |
| CR-200P | NO+NC | PNP | |||
| CR-200/15D | NO+NC | NPN | Pre-wired 150mm cable and M8 connector | ||
| CR-200P/15D | NO+NC | PNP |
Product Specification
small square 12-24V dc PNP retro-reflective photoelectric sensor with reflector
| Model | CR-200P |
| Output Method | PNP NO+NC |
| Detection Type | Retro-reflective |
| Standard Detection Objec | diameter 5mm opaque object |
| Detection Distance | 2m |
| Light Source | 630nm Red modulated light |
| Operating Voltage | 12-24 VDC |
| Response Time | 0.5ms Max. |
| Protection Degree | IP66 |
| Operating Temperature | -10℃-50℃ (No Icing) |
| Reverse Polarity Protection | Yes |
| Short Circuit Protection | Yes |
| Material | ABS |
| Wire Method | dia 4mm*2M/-4wires |
| Weight | 107g |
Product display
Dimension Drawing
NPN NO+NC
PNP NO+NC
