Antenna Manufacturer 1.2Ghz 15dBi Directional Yagi Directive Outdoor Antenna

Name: Antenna Manufacturer 1.2Ghz 15dBi Directional Yagi Directive Outdoor Antenna
Brand: AMEISON
SKU: 126217341

Negotiable MOQ: 500 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

AMEISON

Model Number:

AMXY-1200-15

Shenzhen Ameison Communication Equipment Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen or HongKong

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name AMEISON

Model Number AMXY-1200-15

Type Outdoor

Frequency Range 1100-1300 MHz

Specifications

High gain;Aluminum alloy framework;Full day working;Optimized dimension;Vertical or Horizontal Mounting way;Factory Price.

Antenna Manufacturer 1.2GHz 15dBi directional Yagi directive outdoor antenna

1200Mhz 15dBi directional yagi antenna
Gain is 15dBi
Antenna has 13 elements
Material: aluminum alloy framework

AMXY-1200-15

Feature:

High gain

Aluminum alloy framework

Full day working

Optimized dimension

Mounting way can be Vertical or Horizontal

Application:

1.2GHz system

Point-to-point,point-to-multipoint system

Wireless bridging,client termination antenna

AMXY-1200-15 Electrical Specifications
Frequency range(MHz)	1100-1300
Bandwidth(MHz)	200
Gain(dBi)	15
Element	13
Half-power beam width(°)	H:40 V:37
Front-to-back ratio(dB)	≥16
VSWR	≤2.0
Input Impedance(Ω)	50
Polarization	Horizontal or Vertical
Maximum input power(W)	100
Lightning protection	DC Ground
Input connector type	N female or others
Mechanical Specifications
Dimensions(mm)	81013056
Cable length(m)	0.3
Antenna weight(kg)	0.45
Operating temperature(°c)	-40~60
Rated Wind Velocity(m/s)	60
Clamp	U-shape
Mounting hardware(mm)	Φ35~Φ50
