Help CenterSimple Hydraulic Cut to Length Line
Related Products
-
PLC Servo System Control Steel Plate Cutter for Metal PlateUS$ 5,500 - 7,000MOQ: 1 Set -
Sheet Metal /Plate/Bebar Shearing MachineUS$ 50,000 - 100,000MOQ: 1 Set
-
Silicon Steel Coil Rewinding Machine Line JQ-0.5-2x1300NegotiableMOQ: 1 Set
-
ZJX-2*1500 Mechanical Middle Thickness Coil Slitting LineNegotiableMOQ: 1 Set
-
Flat Bar Coil Uncoiling Straithening and Cut to Length LineUS$ 50,000 - 150,000MOQ: 1 Set
Specifications
Hydraulic system controlThickness Range 0.25-2.0 mm
Width Range 200-1300 mm
Cutting speed10cuts/ min
Precision cutting 0.05
Hydraulic control coil cutter for cut to length line
Technical Parameter
l Application
carbon steel plate, galvanized sheet, color plate, stainless steel, Hot rolled ,cold rolled etc. δb≤450Mpa;δS ≤260Mpa,
l Thickness of coiled plate δ=3.0mm;
l Width of coiled plate 500-1300 mm;
l Precision of cutting width tolerance: ±0.05mm;
l Cutting speed 8cuts/min ;
l Shearing Angle 3 degrees
l Opening height 30 mm
l Shear strip 100 mm
l The blade : 1300 mm x50mmx 20 mm;
l Material of slitting blade 9SiCr;
l Hardness of blade HRC58°—60°;
l Motor power 7.5 Kw
l The system pressure 6.3-16Mpa
l Weight of machine 1Ton
l Machine appearance Height 1800mm Width 800mm Length 1350mm
Features
Hydraulic Shearing Machine
1) Cutting mode Double Hydraulic pillar structure ,hydraulic brake up to down cutting.
2) Automatical cut according to the signal order , which send by the feeder.
3) Driven by the φ180 hydrocylinder.
4) Adjustable gap design to meet different thickness plate.
5) Cutting machine set spring pressure loading device, ensure the shear surface without a
scratch, scratch and flanging phenomenon ,can be safe shear to 1 X13500 steel plate .The
main frame used welding structure, easy to maintenance.
Hydraulic system
Hydraulic system working pressure:6.3-16Mp
Function: Adopt 24V safe voltage to control the hydralic control element, finish the control action with the electrical equipment and coordinate the line be automation.
The whole line adopt centralized control, main operation has the feature of length setting, digital display, automatic counting, high or low speed adjustment, manual
material guiding, autofeeding, continuous cutting, failure warning,ect. Use digital blending control,PLC control system to control the machine, the operation panel adopt
touch screen control.
