Help CenterLoad Cell 10kg
Related Products
Product Characteristics:
Aluminum Load Cell AM6GZ Colorless anodized; Hermetically sealed with glue to IP65. The Aluminum Load Cell is a low profile single point load cell designed for direct mounting of low cost weighing platforms. Its small physical size, combined with high accuracy and low cost, makes this load cell ideally suited for floor scale ,electronic floor scale,low profile floor scale ,digital floor scale, floor weighing scale, floor balance scale, frameless floor,frame type floor scale, explosion-proof floor scale, moveable floor scale, bench scale, cattle scales, pit scale, track scale, digital platform balances, digital weight balance,digital scale balance,digital precision balance,digital counting balance,digital electronic balance,digital body balance, platform balances, platform scale, baby scale.
Technical Parameter:
Rated Load: |
50kg~1000kg |
Sensitivity: |
(2.0±0.1%) mV/V |
Combined Error: |
±0.03% F.S |
Creep Error(30min): |
±0.03% F.S |
Zero Balance: |
±1% F.S |
Temp. Effect On Zero: |
±0.02% F.S/10°C |
Temp. Effect On Span: |
±0.02% F.S/10°C |
Input Resistance: |
385±5Ω |
Output Resistance: |
353±2Ω |
Insulation Resistance: |
≥5000MΩ |
Operating Temperature Range: |
-30~+70°C |
Maximum Safe Over Load: |
150%F.S |
Ultimate Over Load: |
200%F.S |
Recommend Excitation Voltage: |
10~12V DC |
Maximum Excitation Voltage: |
15V DC |
Sealing Class: |
IP65 |
Element Material: |
Aluminum |
Cable: |
Length=L:3m |
Citation: |
GB/T7551-2008/ OIML R60 |
