Low Voltage Aerial Bundled Cable/ Overhead ABC cable
Description:
1. Conductor: Aluminum,Aluminum Alloy,Aluminum Conductor Steel Reinforced etc.
2. Insulation: XLPE/PVC 3.Standard: According to IEC,also can do by standard of ASTM,BS,GB,DIN and AS/NZS or other standards.
4. Rated Voltage:0.6/1kv
5. Conductor shield" semi-conducting
5. Bare Conductor may be made of AAC,ACSR,AAAC etc.
7. Cores:Single,Duplex.Triplex,Quadruplex
Type & Description & Application:
Type |
Description |
Main application |
|
JKV-0.6/1 JKYJ |
0.6/1KV Copper core,PVC insulated cable for overhead 10KV Copper core,XLPE insulated cable for overhead |
Overhead fixed installation and service drop etc. |
|
JKLV-0.6/1 JKLYJ |
0.6/1KV Aluminium core,PVC insulated cable for overhead 10KV Aluminium core,XLPE insulated cable for overhead |
|
|
JKY-0.6/1 JKY |
0.6/1KV Copper core,PE insulated cable for overhead 10KV Copper core,PE insulated cable for overhead |
|
|
JKLY-0.6/1 JKLY |
0.6/1KV Aluminium core,PE insulated cable for overhead 10KV Aluminium core,PE insulated cable for overhead |
|
|
JKYJ-0.6/1 JKLGYJ |
0.6/1KV Copper core,XLPE insulated cable for overhead 10KV Aluminium-copper core,XLPE insulated cable for overhead |
|
|
JKLYJ-0.6/1 JKLYJ/Q |
0.6/1KV Aluminium core,XLPE insulated cable for overhead 10KVAluminium core,light-duty ,XLPE insulated cable for overhead |
|
|
JKLGYJ-0.6/1 JKLGYJ/Q |
0.6/1KV Aluminium core,steel-reinforced,XLPE insulated cable for overhead 10KV Aluminium-steel core,light-duty,XLPE insulated cable for overhead |
Advantages:
a. Excellent electric and mechanical characteristics.
b. Best Resistance chemical corrosion and heat-ageing,environment stress.
c. Simple in structure,Convenient to use.
